OMRON PHOTOELECTRIC SENSOR,E3FA-DP13, E3FA-DN15

OMRON PHOTOELECTRIC SENSOR,E3FA-DP13, E3FA-DN15 Specification

Features
Easy installation, visible red LED light source, indicator for operation

Cable Length
2m pre-wired cable

Measurement Range
0.1m to 1m (diffuse reflective)

Power Consumption
Max. 25mA (without load)

Sensitivity
Adjustable (via sensitivity adjuster)

Response Time
1 ms

Interface
3-wire connection

Application
Object detection in material handling, packaging, and conveyor lines

IP Rating
IP67

Mounting Type
Panel or bracket mounting, M18 threaded barrel

Wireless
No

Operating Temperature
-25C to +55C

Sensor Type
Diffuse reflective photoelectric sensor

Signal Type
Digital (On/Off switching output)

Product Type
Photoelectric Sensor

Material
Plastic housing

Input
12-24V DC

Output
PNP (E3FA-DP13), NPN (E3FA-DN15)

Function
Detection of objects using light beam; models for PNP (E3FA-DP13) and NPN (E3FA-DN15) output

Usage
Industrial automation, object detection, conveyor systems

Accuracy
High, precise detection capability

Resolution
Standard for photoelectric sensors

Voltage
12-24V DC

Weight
Approx. 50g (including cable)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Shock Resistance
500 m/s2 (approx. 50G)

Short-circuit Protection
Yes

Connector Type
Pre-wired (standard), connector models available

Emission Light Source
Red LED (660 nm)

Reverse Polarity Protection
Yes

Model Numbers
E3FA-DP13 (PNP), E3FA-DN15 (NPN)

Ambient Humidity
35% to 85% (non-condensing)

Residual Voltage
1.8V at 100mA load

Indicator
LED output operation indicator, stability indicator

Maximum Load Current
100mA max. at 30V DC

Size/Dimensions
M18 x 67.7mm (Diameter x Length)

About OMRON PHOTOELECTRIC SENSOR,E3FA-DP13, E3FA-DN15

Jump on kingly precision for your industrial automation needs with the OMRON PHOTOELECTRIC SENSOR, E3FA-DP13 (PNP) and E3FA-DN15 (NPN). Personalise your detection setup with potent sensitivity adjustments for high accuracy object sensing. With valiant vibration and shock resistance, plus robust IP67 protection, these sensors excel in demanding environments. Featuring a visible red LED and easy installation, act noworder today from our China-based supplier. Ideal for conveyors and packaging, these sensors provide exceptional reliability and versatility.

Applications and Usage Methods

The OMRON PHOTOELECTRIC SENSOR, E3FA-DP13 and E3FA-DN15, is used extensively in object detection for material handling, packaging, and conveyor systems. Application involves mounting via bracket or panel and wiring the 3-wire connection for digital output. Its diffuse reflective function allows standard resolution detection of objects from 0.1m to 1m. Other applications include counting, sorting, and presence verification within various automation and process control scenarios.

Freight, Handover and Certifications

FOB port options ensure smooth charge and freight management for both local and international buyers of OMRON PHOTOELECTRIC sensors. Handover procedures are timely, with main domestic market support provided across industrial segments. Certifications substantiate the sensors safety and performance standards, helping users meet compliance in demanding automation environments. Each shipment includes necessary credentials and documentation, easing customs and end-use transitions.

FAQs of OMRON PHOTOELECTRIC SENSOR,E3FA-DP13, E3FA-DN15:

Q: How do I select between the E3FA-DP13 and E3FA-DN15 models?

A: Choose E3FA-DP13 for a PNP output or E3FA-DN15 for NPN output, depending on your control circuit requirements in your industrial automation application.

Q: What is the process for installing the OMRON photoelectric sensor?

A: Mount the sensor using the M18 threaded barrel on panels or brackets, then connect the pre-wired 2m cable to your system using the 3-wire interface. Adjust sensitivity as needed for your application.

Q: Where is this sensor commonly used in industry settings?

A: It is widely deployed in conveyor lines, packaging machinery, and material handling systems, where precise object detection is necessary for automation efficiency.

Q: When should I consider using this sensor for my application?

A: Utilize this sensor when accurate, non-contact object detection is required, especially in environments demanding vibration and shock resistance and robust protection (IP67).

Q: What advantage does the visible red LED light source offer?

A: The visible red LED simplifies sensor alignment and operation status checks, enhancing the ease of setup and monitoring during everyday use.

Q: How does reverse polarity and short-circuit protection benefit the user?

A: Built-in protections safeguard the sensor and connected equipment from wiring errors or electrical faults, reducing downtime and maintenance costs.
