DELTA ELECTRONIC SENSOR , DPA10P-P

DELTA ELECTRONIC SENSOR , DPA10P-P Specification

Application
Air Pressure Measurement, Pneumatic Equipment, Control Panels

Operating Temperature
0 to 50C (No Condensation or Freezing)

Features
Compact design, Easy setting, Multi-output, Overpressure Protection, Reverse Polarity Protection

Signal Type
Digital + Analog

Mounting Type
Panel or DIN Rail Mounting

Sensitivity
High, Adjustable via Panel

Response Time
2.5 ms (Selectable up to 5000 ms)

Sensor Type
Digital Pressure Sensor

Measurement Range
-0.1 to 1.0 MPa

IP Rating
IP40

Interface
LCD Digital Display with Keypad

Cable Length
2 Meters

Wireless
No

Power Consumption
40mA

Product Type
Electronic Sensor

Material
ABS/Engineering Plastic Housing

Input
Pressure (Air/Non-corrosive gas)

Output
NPN/PNP Open Collector, 2 Outputs + Analog Output (1-5V)

Function
Pressure Detection and Monitoring

Usage
Industrial Automation, Pneumatic Systems

Accuracy
1% F.S.

Resolution
0.01 MPa

Voltage
12-24V DC 10%

Weight
Approx. 60g (without fittings)

Setting Method
Push Button (with Lock Function)

Shock Resistance
1,000 m/s2 (approx. 100G), 3 times each in X, Y, Z directions

Hysteresis
Adjustable

Withstand Voltage
AC 1000V 60Hz for 1 min (between case and terminal)

Repeatability
0.2% F.S.

Pressure Port
Rc(PT) 1/8, M5 Female Thread

Insulation Resistance
Over 50M (at 500VDC between case and terminal)

Storage Temperature
-10C to 60C

Display Type
3-Digit 7-Segment LCD Display (with Red/Green Switchable)

Operating Humidity
35-85% RH (Non-condensing)

About DELTA ELECTRONIC SENSOR , DPA10P-P

Purchase the DELTA DPA10P-P Electronic Sensor at the lowest price with rarefied features tailored for industrial automation and pneumatic systems. Boasting a 3-digit, 7-segment LCD display with switchable red/green, this compact device delivers optimum accuracy (1% F.S.) and unprecedented repeatability (0.2% F.S.). Customizable via a push-button interface with lock, its high-sensitivity and adjustable hysteresis guarantee adaptable performance. The robust ABS housing ensures reliable operation in demanding environments, while multi-output (NPN/PNP + analog) enhances flexibility across diverse applications. Opt for this advanced sensor to elevate your process control.

Versatile Usage & Targeted Application Areas

The DELTA ELECTRONIC SENSOR, DPA10P-P, is expertly engineered for use in pneumatic equipment, air pressure measurement, and industrial control panels. Its high sensitivity and customizable settings make it an optimum choice for monitoring air and non-corrosive gases in automated manufacturing, process industries, and machinery. With a measurement range from -0.1 to 1.0 MPa, this sensor excels in environments demanding precise control and rapid response, ensuring consistent and reliable performance across a spectrum of industrial sectors.

Sample Policy, Delivery Excellence & Market Reach

Our sample policy for the DELTA ELECTRONIC SENSOR, DPA10P-P, is flexible for both domestic and export markets, prioritizing supplier transparency and customer valuation. We offer quick dispatch on orders, ensuring the fastest possible delivery time across the main domestic market and to international clients. Rigorous packaging standards are maintained for safe transit, fostering dedicated trader and wholesaler relationships, whether you are evaluating a new application or placing bulk orders for ongoing projects.

FAQ's of DELTA ELECTRONIC SENSOR , DPA10P-P:

Q: How can I customize the DELTA DPA10P-P sensor settings?

A: The DELTA DPA10P-P sensor allows easy customization via its push-button interface, equipped with an adjustable hysteresis and lock function, permitting fine-tuning according to your specific operational requirements.

Q: What applications benefit most from using this electronic sensor?

A: This sensor is particularly beneficial in industrial automation, pneumatic equipment, control panels, and air pressure monitoring systems where both precision and rapid response are critical for optimal performance.

Q: What is the process for purchasing and receiving the sensor?

A: To purchase, simply contact our sales team for the lowest price quotation. Once ordered, the product is quickly dispatched and delivered, whether for domestic or export markets, ensuring minimal waiting times.

Q: Where is the DELTA DPA10P-P sensor commonly applied?

A: It is commonly integrated into automated manufacturing lines, process industries, pneumatic control panels, and wherever accurate air or non-corrosive gas pressure monitoring is essential.

Q: What are the main benefits of the multi-output feature?

A: The sensor offers NPN/PNP open collector outputs and an analog output (1-5V), providing flexibility for users needing digital or analog signal integration for varied system designs.
