AUTONICS AREA SENSOR, BWP20-12

AUTONICS AREA SENSOR, BWP20-12 Specification

IP Rating
IP40

Features
Slim Design, Fast Response, Easy Installation

Operating Temperature
-10°C to +55°C

Response Time
20ms Max.

Power Consumption
Max. 36mA

Mounting Type
Bracket Mounting

Measurement Range
0.2m to 7m (Detection Distance)

Interface
3-wire DC

Sensitivity
Fixed (Cannot be Adjusted)

Wireless
No

Signal Type
Digital

Sensor Type
Photoelectric Array

Application
Part Counting, Position Sensing, Safety Guarding

Cable Length
2m Built-in Cable

Product Type
Area Sensor

Material
Polycarbonate Housing

Input
12-24V DC

Output
NPN Open Collector

Function
Object Detection

Usage
Industrial Automation, Safety Barriers

Accuracy
Reliable Detection with Minimal False Alarms

Resolution
20mm Beam Pitch

Voltage
12-24V DC (Ripple P-P max. 10%)

Weight
Approx. 250g

Connection Type
Standard cable

Light Source
Infrared LED (wavelength: 940nm)

Number of Optical Axes
12

Length of Sensing Part
Approx. 270mm

Alignment
Visible LED indicator for beam alignment

Protection Circuit
Reverse polarity, Output short-circuit, Surge protection

Case Color
Black

Ambient Illumination
Incandescent lamp: Max. 3,000 lux, Sunlight: Max. 10,000 lux

Output Current
Max. 100mA

Detection Method
Through-beam array

AUTONICS AREA SENSOR, BWP20-12 About

Access the kingly performance of the AUTONICS AREA SENSOR, BWP20-12an imposing, top-rated solution trusted in industrial automation. With potent 12-beam infrared detection (940nm) and a robust polycarbonate build, it delivers precise object detection from 0.2m to 7m. The sensors slim design, fast response (20ms max.), and visible LED alignment offer straightforward installation and superior accuracy with minimal false alarms. Integrated protective circuits and high output current reinforce its durability, making it in demand for safety barriers, part counting, and position sensing across industrial domains.

Broad Application and Versatile Use

Designed for both specific and general use, the AUTONICS AREA SENSOR, BWP20-12 excels on a variety of application surfacesfrom conveyor belts to factory safety zones. Its reliable performance benefits plant applications that require dependable part counting, object detection, and safety guarding. As an industrial automation cornerstone, it adapts seamlessly to dynamic environments, maintaining efficiency and safety throughout your production lines with robust through-beam technology and a manageable form factor.

Favorable Trade Terms & Reliable Shipping

We offer AUTONICS AREA SENSOR, BWP20-12 with a sample policy tailored for initial proposals or bulk tests. Benefit from highly competitive, lowest price quotes based on proposal amount. Express Shipping is available for urgent delivery, ensuring minimal disruption to your workflow. The item is shipped FOB China ports, and we accommodate flexible payment terms, enabling a smoother procurement experience for suppliers, traders, and wholesalers seeking reliability and speed.

FAQs of AUTONICS AREA SENSOR, BWP20-12:

Q: How does the AUTONICS AREA SENSOR, BWP20-12 enhance industrial safety?

A: By providing reliable object detection and accurate position sensing with minimal false alarms, the sensor is instrumental in creating dependable safety barriers and guarding personnel from machinery risks.

Q: What applications is this area sensor best suited for?

A: It excels in industrial automation tasks such as part counting, position sensing, and safeguarding equipment. Its versatility allows effective use across manufacturing plants, assembly lines, and logistics facilities.

Q: When should I consider using a 12-axis sensor like the BWP20-12?

A: Choose the BWP20-12 when your operation demands precise detection across a wide area, such as in multi-position monitoring, material handling, and where consistent throughput and accurate object tracking are essential.

Q: Where can I install the AUTONICS BWP20-12 area sensor?

A: The sensor can be bracket-mounted on machinery, safety enclosures, or conveyors within indoor industrial environments, provided ambient illumination and temperature recommendations are observed.

Q: What is the process for aligning the sensor beams during installation?

A: Installation is straightforward due to the visible LED indicator for beam alignment, ensuring the sensor is precisely tuned for optimal detection performance.

Q: What are the key benefits of using this sensors through-beam array detection?

A: Through-beam array detection provides high resolution (20mm beam pitch), robust immunity to ambient light interference, and fast response times, making it ideal for demanding industrial environments.
