PANASONIC, PHOTOELECTRIC SENSOR, LX-111-P

PANASONIC, PHOTOELECTRIC SENSOR, LX-111-P Specification

Sensitivity
Adjustable

Application
Object detection, position sensing, counting

Wireless
No

Measurement Range
0.1 m to 7 m (typical)

Power Consumption
Approximately 30 mA

Features
Compact size, Easy installation, Red LED indicator

IP Rating
IP66

Cable Length
2 meters (integrated)

Operating Temperature
-25°C to +55°C

Signal Type
Digital (ON/OFF)

Interface
Cable connection

Sensor Type
Through-beam

Response Time
1 ms or less

Mounting Type
Panel/Surface Mount

Product Type
Photoelectric Sensor

Material
Plastic Housing

Input
DC 12-24V

Output
PNP Output

Function
Detection/Presence Sensing

Usage
Industrial Automation

Accuracy
High

Voltage
12-24 V DC

Weight
Approx. 50 g

Operation Mode
Light ON/Dark ON selectable

Hysteresis
Minimal, factory-adjusted

Indicator
Operation indicator (LED)

Emitter/Receiver Type
Separate units

Shock Resistance
500 m/s², 3 times each in X, Y, Z directions

Enclosure Material
Polycarbonate

Ambient Humidity
35% to 85% RH (non-condensing)

Protective Circuit
Reverse polarity protection, overcurrent protection

Connection Type
Pre-wired cable

Vibration Resistance
10 to 55 Hz, 1.5 mm amplitude

Light Source
Red LED (visible)

Control Output
NPN/PNP transistor output (model specific)

About PANASONIC, PHOTOELECTRIC SENSOR, LX-111-P

Introducing the gilt-edged PANASONIC PHOTOELECTRIC SENSOR LX-111-P, where technology meets superlative efficiency. Driven by a vivid Red LED, this compact sensor boasts an ineffable combination of accuracy, minimal hysteresis, and robust protection circuits. Its dual NPN/PNP output ensures universal application, while IP66 rating, factory-adjusted sensitivity, and durable polycarbonate build promise reliability in the most demanding industrial automation settings. Personalise your detection needs-Add to Cart now and seize an exclusive price cut, making innovation accessible yet elite. Ideal for object detection, position sensing, or counting tasks, this sensor sets the standard.

Widely Used Across Industrial Applications

The PANASONIC PHOTOELECTRIC SENSOR LX-111-P finds its place in multiple industrial automation sectors, being relied upon by manufacturers, suppliers, and automation professionals worldwide. Its superb resistance to shock, vibration, and broad humidity tolerance, complemented by panel or surface mounting, makes it perfect for dynamic object detection on various surfaces-plastic, metal, or painted lines. Enhanced safety and operational indicators ensure secure and seamless performance wherever sensor precision is paramount.

Prompt Delivery and Efficient Global Supply

With streamlined packing & dispatch processes, the LX-111-P reaches customers swiftly. Valuation and quality checks ensure that each unit meets our superlative standards. Available across the main domestic markets as well as key export destinations, this sensor is supplied by leading traders and wholesalers in China, ensuring timely delivery and reliable after-sales support globally. Our dedicated distribution network guarantees the sensor's prompt arrival to your facility, no matter where you are located.

FAQ's of PANASONIC, PHOTOELECTRIC SENSOR, LX-111-P:

Q: How does the PANASONIC LX-111-P enhance object detection efficiency in industrial settings?

A: It utilises a visible Red LED and minimal hysteresis circuitry, offering high accuracy and fast response times, making it ideal for dynamic object detection, position sensing, and counting.

Q: What are the mounting and connection options for the LX-111-P sensor?

A: The sensor supports panel or surface mounting and features a convenient pre-wired 2-meter cable, ensuring simple and secure installation across diverse setups.

Q: Where can this photoelectric sensor be effectively used?

A: It's widely used in industrial automation, manufacturing lines, robotic assembly, and wherever reliable object detection and presence sensing are required.

Q: What protective features does the LX-111-P include?

A: It is equipped with reverse polarity and overcurrent protection, and the IP66 rating ensures resilience against dust and water ingress, supporting use in challenging environments.

Q: How long does it take to receive the LX-111-P after ordering?

A: With efficient packing & dispatch processes, and a reliable supply chain, delivery is prompt both domestically and to international markets, ensuring minimal downtime.

Q: What are the main benefits of using a gilt-edged sensor like the LX-111-P?

A: The sensor offers superlative detection precision, a compact and durable build, simple installation, and broad environmental resistance, all contributing to enhanced process reliability.
