OMRON LIMIT SWWITCH, D4V-8108Z-N

OMRON LIMIT SWWITCH, D4V-8108Z-N Specification

Automation Grade
Industrial Automation

Mechanical Life
10,000,000 operations min.

Rated Voltage
250V AC, 30V DC

Protection Level
IP66

Circuit Type
SPDT (Snap Action)

Number of Module
Single

Finish Type
Powder Coated/Metal

Max. Current
10A

Temperature Range
-10C to +80C

Response Time
Instantaneous

Product Type
Limit Switch

Material
Zinc Alloy Die-cast; Head/Actuator: Metal

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
25 m max. (initial)

Max. Voltage
250 VAC

Operating Temperature
-10C to +80C

Stoke
Roller Lever Arm, Adjustable stroke

Size
Approx. 30.5 mm (W) x 59 mm (H) x 30 mm (D)

Color
Gray Body, Black Actuator

Weight
Approx. 160g

Mounting Type
Panel Mount

Current Rating
10A at 250V AC

No Of Poles
1 NO + 1 NC (Double Pole)

Model Number
D4V-8108Z-N

Actuator Type
Adjustable Roller Lever

Service Voltage
125/250 VAC, 8A; 30 VDC, 5A

Cable Entry
PG13.5 Conduit

Application
Industrial Machinery, Safety Installations, Control Panels

Electrical Life
500,000 operations min.

Operating Speed
0.1 mm/s to 1 m/s

Contact Configuration
1NO+1NC Snap Action

Body Construction
Durable Metal Housing with Plastic Terminal Cover

About OMRON LIMIT SWWITCH, D4V-8108Z-N

Reserve the famed OMRON LIMIT SWITCH, D4V-8108Z-N, a dazzling choice for modern industrial automation. This superlative device is highly popular among control panel designers and machinery integrators due to its adjustable roller lever, robust zinc alloy die-cast body, and superior protection (IP66 rated). With limited stock available, this high-performance switch handles up to 10A, offers a swift snap action (1NO+1NC), and boasts a mechanical life exceeding 10 million operations, making it the ideal solution for critical safety installations and demanding industrial environments.

Versatile Application for Industrial Excellence

The OMRON LIMIT SWITCH, D4V-8108Z-N, excels in a vast range of industrial applications. It is specifically utilized in safety installations, control panels, and heavy-duty machinery where reliable switching and operator safety are paramount. General use includes automation in assembly lines, conveyors, and packaging units. It is widely used by electrical engineers, automation specialists, and equipment manufacturers seeking efficiency and dependable operation in challenging environments.

Packaging, Sampling, and Certification Details

Each OMRON D4V-8108Z-N is carefully packaged to prevent damage during shipment via trusted transport services. Handover is prompt, ensuring swift delivery to your location. Sample units are available on request for evaluation and testing before bulk order handover. The product holds relevant industrial certifications for quality and compliance, underscoring its reliability and adherence to stringent standards in automation and safety applications.

FAQ's of OMRON LIMIT SWWITCH, D4V-8108Z-N:

Q: How does the OMRON D4V-8108Z-N limit switch benefit industrial automation?

A: The OMRON D4V-8108Z-N provides reliable operation, fast response, and unmatched durability, which enhances safety and efficiency in automated systems such as conveyors and control panels.

Q: What is the process for installing the D4V-8108Z-N limit switch?

A: The unit is designed for panel mounting, with a PG13.5 conduit cable entry for easy wiring. Its adjustable roller lever and metal housing simplify integration into a range of machinery.

Q: Where is this limit switch commonly used?

A: It finds common use in industrial machinery, safety installations, and factory automation panels, supporting both general and specific applications demanding robust performance.

Q: What certifications does the OMRON limit switch carry?

A: The product is certified to meet leading industrial standards, ensuring safety, consistent quality, and compliance for critical applications.

Q: When are sample units available for customers?

A: Sample units can be provided upon request before making a bulk purchase to allow evaluation and testing for suitability in your specific environment.

Q: How does the D4V-8108Z-N ensure long-lasting performance?

A: Built with a durable zinc alloy body and high-quality actuator, it boasts a mechanical life of over 10 million operations and superior electrical insulation, providing reliable operation in demanding settings.
