OMRON LIMIT SWITCH,HL-5072

OMRON LIMIT SWITCH,HL-5072 Specification

Circuit Type
Snap Action

Response Time
20 ms Max.

Protection Level
IP67

Rated Voltage
250 VAC / 125 VDC

Mechanical Life
10,000,000 operations min.

Finish Type
Painted / Coated

Automation Grade
Industrial

Temperature Range
-10C to +80C

Max. Current
5A

Number of Module
Single

Product Type
Limit Switch

Material
Die-cast Zinc Alloy Body / Resin Head

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
25 m max. (initial)

Max. Voltage
250 VAC

Operating Temperature
-10C to +80C

Stoke
10 mm

Size
50 mm x 28 mm x 50 mm (approx.)

Color
Gray Body, Black Head

Weight
Approx. 230 g

Mounting Type
Panel / Surface Mount

Current Rating
5A at 250 VAC

No Of Poles
Single Pole Double Throw (SPDT)

Electrical Life
500,000 operations min.

Type of Actuation
Momentary

Ingress Protection
IP67 (Oil, Water, Dust Proof)

Contact Configuration
1NO + 1NC

Actuator Type
Rod Lever

Shock Resistance
1,000 m/s2

Model Number
HL-5072

About OMRON LIMIT SWITCH,HL-5072

Unlock exceptional industrial performance with the popular OMRON LIMIT SWITCH, HL-5072-a first-string essential for precise automation. Designed with a gorgeous gray body and classic black resin head, this device showcases a robust die-cast zinc alloy build. Equipped with a rod lever actuator and a 1NO + 1NC configuration, it ensures reliable, momentary actuation. Benefit from a stellar mechanical life of over 10 million operations and IP67-level resistance against oil, water, and dust. Procure this premium, highly trusted model now to elevate your automation systems to new standards.

Versatile Features, Reliable Surface Applications

The OMRON LIMIT SWITCH, HL-5072 stands out with its superior material construction and IP67 grade, making it thoroughly oil, water, and dustproof. Its classic snap action circuit and sturdy rod lever actuator enable precise use on automation and control equipment. Typically used for position sensing and limit control, it can be surface or panel mounted on machinery in industrial settings, ensuring long-term, accurate operation across diverse surfaces.

Packaging, Supply, and Streamlined Delivery

Estimates for packaging include standard protection to ensure the HL-5072's integrity during transit. We handover bulk consignments swiftly, utilizing trusted transport services for secure and timely shipment. With a consistent supply ability to meet high-volume demands, our flexible payment terms simplify procurement. Rest assured, whether as a supplier, trader, or wholesaler, you'll experience efficient order processing and fast delivery from China to your destination.

FAQ's of OMRON LIMIT SWITCH,HL-5072:

Q: How is the OMRON LIMIT SWITCH, HL-5072 installed?

A: The HL-5072 limit switch can be mounted on panel or surface settings, making it adaptable to a range of industrial machinery and automation systems.

Q: What benefits does the IP67 protection confer?

A: IP67 protection ensures the device is resistant to oil, water, and dust ingress, making it ideal for harsh industrial environments and guaranteeing consistent operation.

Q: When should this limit switch be used?

A: It is best employed when you require reliable, momentary limit control or position detection in high-cycle machinery where extended mechanical and electrical lifespans are necessary.

Q: Where can this switch be effectively applied?

A: The HL-5072 accommodates diverse industrial sectors, such as manufacturing, automation lines, machinery, and equipment that demand precise operational feedback and durability.

Q: What is the process for ordering and receiving the HL-5072?

A: First, submit a procurement request. We estimate packaging needs, process your order, and then arrange for handover to trusted transport services, ensuring safe and prompt delivery.
