OMRON LIMIT SWITCH,D4NL-1DFA-BS-F

OMRON LIMIT SWITCH,D4NL-1DFA-BS-F Specification

Circuit Type
NC + NO (Normally Closed + Normally Open)

Finish Type
Smooth

Rated Voltage
AC 240V

Response Time
ms-level

Protection Level
IP67

Number of Module
1

Temperature Range
-25C to 55C

Max. Current
10A

Automation Grade
High

Mechanical Life
1000000 operations

Product Type
Door Switch

Material
Metal/Plastic

Insulation Resistance
>100 M

Contact Resistance
Under 100 m

Max. Voltage
240V AC

Operating Temperature
-25C to 55C

Stoke
Defined Stroke Length

Size
Compact

Color
Silver/Blue

Weight
Approximately 200g

Mounting Type
Panel Mount

Current Rating
10A

No Of Poles
2

OMRON LIMIT SWITCH,D4NL-1DFA-BS-F About

The OMRON LIMIT SWITCH, D4NL-1DFA-BS-F, is a reliable panel mount switch designed for high automation grade applications. With a silver/blue color, this switch offers a unique blend of metal and plastic materials ensuring durability. It features a NC + NO circuit type, a defined stroke length, and a 1000000 operations mechanical life. With a smooth finish and compact size, it provides a max. voltage of 240V AC and max. current of 10A. The switch has an IP67 protection level and operates efficiently in temperatures ranging from -25C to 55C. Weighing approximately 200g, it offers excellent insulation resistance (>100 M) and a quick response time at the ms-level.
