OMRON FLOATLESS LEVEL SWITCH, 61F-LS-CP08-NRA

OMRON FLOATLESS LEVEL SWITCH, 61F-LS-CP08-NRA Specification

Sensors Specification
Electrodes (Floatless, not bundled)

Power Supply
220-240 VAC, 50/60 Hz

Power Source
AC Supply

Components
Main Unit, Socket (included)

IP Rating
IP20 (Enclosure)

Display Type
LED Indicator (Operation Status)

Output
Relay Contact (SPDT)

Features
Floatless operation, LED status indication, Compact design, High reliability

Usage
Water Level Management in Tanks and Reservoirs

Input
Electrode Probes (not included)

Interface
Relay Output, Socket Connection

Operating Temperature
-10C to +55C

Response Time
Max 150 ms (Operation), Max 400 ms (Release)

Product Type
Floatless Level Switch Relay

Application
Water Supply, Drainage Control, Pump Control

Rated Voltage
220V AC

Supply Voltage
220V AC

Size
Compact

Dimension (L*W*H)
Approx. 77 x 50 x 120 mm

Function
Liquid Level Control (Floatless)

Color
Grey and Black

Weight
Approximately 170 g

Current Rating
5A at 220V AC Resistive Load

Thickness
Standard (Refer to Dimensions)

Capacity
Up to 5A Relay Output

Frequency
50/60 Hz

Humidity Tolerance
35% to 85% RH (Non-condensing)

Maximum Electrode Length
Up to 100 meters using 600 V Vinyl-insulated Cable

Control Range
Adjustable via external electrodes

Life Expectancy (Mechanical)
10,000,000 Operations (min.)

Material
High-grade Polycarbonate Casing

Life Expectancy (Electrical)
500,000 Operations (min.)

Min. Water Conductivity
10 S/cm

Mounting Type
DIN Rail or Surface Mount

Contact Configuration
SPDT

Insulation Resistance
100 M min. (at 500 VDC)

Model Number
61F-LS-CP08-NRA

Dielectric Strength
2,000VAC, 50/60 Hz for 1 min

About OMRON FLOATLESS LEVEL SWITCH, 61F-LS-CP08-NRA

Ending soon, the OMRON FLOATLESS LEVEL SWITCH, 61F-LS-CP08-NRA is an ephemeral opportunity for those seeking peerless water level management solutions. This laureate device astounds with high-grade polycarbonate casing, a control range adjustable via external electrodes, and the capacity to manage electrode lengths up to 100 meters. Its value is heightened by floatless operation, robust insulation, and LED operation status indication. Designed for DIN Rail or surface mounting, this compact relay outputs up to 5A, delivering astounding reliability for water level control in tanks, reservoirs, and pump systems.

Astounding Features and Competitive Edge

The OMRON FLOATLESS LEVEL SWITCH, 61F-LS-CP08-NRA features floatless operation, a compact frame, LED status indicators, and a high-grade polycarbonate shell. Its peerless performance includes easy installation (DIN Rail or surface mount), adjustable control range, and an impressive electrode length capacity. Primary advantages are high reliability, minimal maintenance, and astounding operational life. Ideal for water supply, pump, and drainage control, its versatility shines in both industrial and domestic water management applications.

Certifications, Market Reach & Seamless Delivery

Certified for robust operation, this device meets industry standards for safety and quality. Omron ensures an extensive domestic market presence with local support for traders, suppliers, and wholesalers across Japan. Secure shipping protocols guarantee safe arrival, and customers benefit from swift handover with typical delivery times averaging between 3-7 days, ensuring continuity and reliability in every order.

FAQ's of OMRON FLOATLESS LEVEL SWITCH, 61F-LS-CP08-NRA:

Q: How does the OMRON FLOATLESS LEVEL SWITCH, 61F-LS-CP08-NRA operate without a float?

A: The device uses electrode probes to detect liquid levels, eliminating the need for a traditional mechanical float, resulting in fewer moving parts and reduced maintenance.

Q: What primary benefits does this level switch offer over conventional models?

A: Its high reliability, compact design, floatless operation, and ability to manage long electrode lengths make it more efficient, durable, and suitable for various applications.

Q: Where can the 61F-LS-CP08-NRA be installed?

A: It can be easily mounted on a DIN Rail or a surface, making it adaptable for industrial or residential tanks, reservoirs, and pumping systems.

Q: What is the process for adjusting the control range?

A: The control range can be fine-tuned by adjusting the external electrode length and placement according to your application's requirements.

Q: When can customers expect delivery after ordering?

A: After order placement, secure shipping is arranged, and customers can typically expect the device to arrive within 3 to 7 days, followed by a prompt handover.
