61F-GP-N8 Float Less Level Switch

61F-GP-N8 Float Less Level Switch Specification

IP Rating
IP40 (panel), IP20 (terminals)

Features
Electrode-based operation, no moving float, compact design, LED indicator, easy installation

Power Source
Electric

Usage
Industrial

Output
Relay Output

Operating Temperature
-10C to +55C

Interface
Screw terminal connections

Response Time
Below 10 ms

Display Type
Indicator LED

Sensors Specification
Works with stainless or copper electrodes

Input
Electrode (Water) level signals

Resolution
Level Control (On/Off switching)

Power Supply
AC

Components
Main Controller, Electrode Holder (not included)

Product Type
Floatless Level Switch

Application
Commercial

Rated Voltage
200 to 230 VAC

Supply Voltage
200-230 VAC

Size
Standard Panel Mount

Dimension (L*W*H)
Approx. 85 x 50 x 100 mm

Function
Manual

Color
Black and Silver

Weight
Approx. 230 g

Warranty
Yes

Thickness
Standard Enclosure

Current Rating
5A at 220 VAC resistive load

Capacity
Detects up to 8 levels

Frequency
50/60 Hz

Mounting Type
Panel Mount

Contact Type
SPDT Relay Contacts

Model
61F-GP-N8

Control Range
Depends on electrode length and installation

Dielectric Strength
2000 VAC for 1 min between power supply and electrode

Max Cable Length to Electrode
Up to 100 meters

Insulation Resistance
100 M min. at 500 VDC

Material (Enclosure)
ABS Resin

Indication
LED On/Off Status

Operating Humidity
4585% RH non-condensing

Control Method
Electrode Sensing, Floatless

Max Number of Electrodes
8

61F-GP-N8 Float Less Level Switch Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
5-10 Days

Main Domestic Market
All India

About 61F-GP-N8 Float Less Level Switch

The 61F-GP-N8 Float Less Level Switch is a sought-after solution for precise liquid level detection. This premier panel-mount device features advanced electrode sensing-no float mechanism-ensuring reliable operation for industrial and commercial applications. Designed with SPDT relay contacts, it supports up to 8 electrode levels, with a control range determined by installation. Its ABS resin enclosure, exclusive LED On/Off display, and robust build offer the finest durability and performance. Order today to experience the efficiency of this popular, easy-to-install, floatless system-supplied by leading traders and wholesalers in India.

Industrial-Grade Application and Versatile Usage

The 61F-GP-N8 Float Less Level Switch is engineered for reliability in both commercial and industrial environments. It specializes in general liquid level monitoring and control, making it suitable for water tanks, process industries, and HVAC systems. The device operates by electrode-based sensing, accommodating up to eight different levels, ensuring superior versatility for varied applications. Designed for robust usage, it excels in accurately managing water or conductive liquid levels without mechanical floats.

Prompt Supply and Sample Policy Details

Benefit from swift supply and accurate valuation with our quick dispatch process for the 61F-GP-N8 Float Less Level Switch. Standard delivery times assure minimal waiting, and dedicated support ensures a seamless purchasing experience. Sample policy is transparent: samples can be provided upon request, enabling complete evaluation before order placement. Rely on trusted supply chains and a proven dispatch record, ensuring the right product swiftly reaches your facility for installation and operational integration.

FAQ's of 61F-GP-N8 Float Less Level Switch:

Q: How does the 61F-GP-N8 Float Less Level Switch function without a traditional float?

A: The 61F-GP-N8 uses electrode sensing technology instead of mechanical floats. When the liquid level reaches the electrode, it changes the electrical conductivity and triggers the relay output for precise On/Off control.

Q: What is the maximum number of levels the 61F-GP-N8 can detect?

A: This level switch can detect up to eight different liquid levels, depending on the number and installation of electrodes.

Q: Where can the 61F-GP-N8 be installed for optimal performance?

A: The device is designed for panel mounting and is suitable for installation in commercial and industrial environments such as water treatment plants, tanks, and process pipelines.

Q: What types of electrodes are compatible with this level switch?

A: The 61F-GP-N8 works efficiently with both stainless steel and copper electrodes, offering flexible installation options for different liquid applications.

Q: What are the benefits of using a floatless level switch like the 61F-GP-N8?

A: The floatless design eliminates mechanical failures, provides quick response, and ensures reliable long-term operation, particularly in harsh or contaminated environments.
