OMRON FIBER OPTIC SENSOR, E32-T16

OMRON FIBER OPTIC SENSOR, E32-T16 Specification

Measurement Range
Typical sensing distance of 700 mm to 1800 mm (using appropriate amplifier)

Interface
Plastic fiber cable connects to an amplifier unit

Cable Length
2 m standard Meter (m)

Signal Type
Photoelectric (optical) signal

Sensor Type
Through-beam, fiber optic

Sensitivity
Adjustable via amplifier

Mounting Type
M6 threaded mounting

Features
High flexibility, robust design, endurable in harsh environments, oil resistant fiber

IP Rating
IP67 (probe only)

Application
Robotics, packaging, assembly lines, pharmaceuticals, electronic parts presence/absence detection

Operating Temperature
-40°C to +70°C (without icing or condensation) Celsius (oC)

Wireless
No

Product Type
Fiber Optic Sensor

Material
Stainless Steel (Sensing head), Polyethylene (Fiber)

Input
Light input through fiber cable

Output
Via amplifier unit (Relay, NPN/PNP transistor open collector depending on amplifier used)

Function
Detects presence or absence of objects using fiber optic transmission

Usage
Industrial automation, object detection, positioning, counting

Resolution
Micron-level (varies by amplifier circuit)

Weight
Approx. 24 g Grams (g)

Bending Radius
25 mm minimum (static)

Head Shape
Threaded cylindrical (M6)

Shock Resistance
500 m/s2, 3 times in 6 directions

Sheath Material
Polyethylene

Minimum Detectable Object
0.01 mm (with suitable amplifier)

Fiber Diameter
2.2 mm

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude in each of X, Y, and Z directions for 2 hours

Sensing Method
Through-beam

RoHS Compliance
Yes

Protective Structure
IP67 (IEC60529)

Ambient Humidity
35% to 85% RH (no condensation)

Fiber Material
Acrylic

Compatible Amplifiers
E3X series and equivalent fiber sensor amplifiers

OMRON FIBER OPTIC SENSOR, E32-T16 About

Discover the latest marvel in object detectionthe OMRON FIBER OPTIC SENSOR, E32-T16. Famed for its high precision and IP67-rated protective structure, this sensor delivers valorous performance even in harsh environments. Featured for its flexible acrylic fiber and robust stainless-steel head, the E32-T16 can detect objects as small as 0.01 mma deal for industrial automation, assembly lines, and packaging. Compatible with E3X amplifiers, it offers adjustable sensitivity and micron-level resolution. Enjoy accuracy, resilience, and reliability in one premier detection solution.

Ideal Application Environments & Distinct Features

The OMRON FIBER OPTIC SENSOR, E32-T16, excels on robotics, packaging, pharmaceuticals, and electronics assembly lines. Its extra features include a threaded cylindrical M6 head, high shock/vibration resistance, and oil-resistant polyethylene fiber. Suited for challenging conditions, it reliably detects objects presence or absence, offering precise positioning and counting. With its through-beam sensing and micron-level resolution, this sensor thrives in automated, high-demand settings where dependability and accuracy are paramount.

Sample Availability, Packaging & Shipping Details

Premium E32-T16 sensors are stocked and ready for shipment with secure, durable packaging. Sample units can be requested to confirm suitability before large orders. Products are shipped from Chinas FOB port, ensuring swift and reliable delivery. Each sensor is shipped in protective packaging to safeguard against transit damage, maintaining the sensors integrity for immediate industrial implementation upon arrival. Choose ready inventory and prompt dispatch for your automation needs.

FAQs of OMRON FIBER OPTIC SENSOR, E32-T16:

Q: How can the OMRON FIBER OPTIC SENSOR, E32-T16 be installed in industrial automation systems?

A: The E32-T16 sensor can be easily mounted using its threaded cylindrical M6 head. Connect the 2-meter plastic fiber cable to a compatible amplifier, such as E3X series, for optimal integration within robotics, conveyor, or assembly line applications.

Q: What benefits does the IP67 protective structure offer for industrial environments?

A: The IP67 rating ensures the sensor is protected against dust, water, and oil, allowing it to function reliably in harsh conditions commonly found in manufacturing and automated production spaces.

Q: Where is the E32-T16 sensor most suitable for use?

A: This sensor is ideal for use in environments requiring precise detection, such as packaging, electronics, pharmaceuticals, and assembly lines, especially where high humidity, vibration, and industrial oils are present.

Q: When is it advantageous to request a sample of the OMRON E32-T16 sensor?

A: Requesting a sample is recommended when you need to verify the sensors performance and compatibility in your specific application before placing bulk orders. This ensures suitability and meets your automation standards.

Q: What is the process for adjusting sensitivity on the E32-T16 sensor?

A: Sensitivity can be fine-tuned through the connected amplifier (e.g., E3X series), allowing operators to tailor detection parameters according to the size, distance, and nature of target objects.
