MEANWELL POWER SUPPLY, NES-50-24 INPUT: 100-240VAC 1.3A OUTPUT: +24V 2.2A

MEANWELL POWER SUPPLY, NES-50-24 INPUT: 100-240VAC 1.3A OUTPUT: +24V 2.2A Specification

Application
Industrial automation equipment, control systems, LED lighting, instrumentation

Rated Current
2.2A

Rated Power
52.8W

Output Type
Single Output

Working Temperature
-20C to +60C

Power Factor
0.5 at 230VAC full load

Power Supply
AC-DC

Noise Level
<150mVp-p

Cooling Method
Free Air Convection

Connector Type
Screw Terminal Block

Features
Compact design, High reliability, Adjustable output voltage (21.6~28.8V), Cooling by free air convection, LED power indicator

Phase
Single Phase

Current Range
0~2.2A

Output Current
2.2A

Operating Temperature
-20C to +60C

Product Type
Switching Power Supply

Output Power
52.8W

Output Frequency
47~63Hz

Input Voltage
100~240VAC, 120~370VDC

Voltage Protection
Overload/Overvoltage/Short Circuit Protection

Efficiency
86%

Material
Metal Enclosure

Line Regulation
0.5%

Storage Temperature
-40C to +85C

Weight
0.41 kg

Dimensions
129 x 97 x 38mm (L x W x H)

Ripple & Noise
<150mVp-p

Input Frequency
47-63Hz

Hold Up Time
>50ms (230VAC/full load)

Adjustable Voltage Range
21.6~28.8V

Mounting Type
Chassis Mount

Output Voltage
+24V DC

Inrush Current
35A/115VAC; 70A/230VAC

Isolation Voltage
I/P-O/P: 3kVAC

Input Current
1.3A/115VAC; 0.7A/230VAC

Safety Standards
EN61000-3-2 Class A, EN61000-4-2,3,4,5,6,8,11, EN55022(CISPR22) Class B

About MEANWELL POWER SUPPLY, NES-50-24 INPUT: 100-240VAC 1.3A OUTPUT: +24V 2.2A

Unlock resplendent power with the MEANWELL NES-50-24 Power Supply, a top-rated solution designed for soaring industrial demands. Enjoy blue-ribbon reliability and high efficiency at a competitive pricing point, with features like adjustable output (21.6-28.8V), robust overload, overvoltage, and short-circuit protection. The compact metal chassis mount fits seamlessly into various applications, while free-air convection cooling ensures longevity. This 52.8W AC-DC single-output supply is a dependable choice for control systems, LED lighting, and automation, meeting international safety standards.

Special Features and Application Advantages

The MEANWELL NES-50-24 stands out with a compact, robust metal enclosure and a blue-ribbon adjustable output voltage. LED power indication and high reliability are ideal for industrial automation, instrumentation, LED lighting, and control systems. Its free air convection cooling and advanced protection mechanisms provide worry-free operation. The device is engineered for resplendent performance in harsh environments, ensuring soaring durability and versatility across diverse industrial media.

Export Markets, Delivery, and Pricing Offers

We offer the MEANWELL NES-50-24 to major export markets globally, including Europe, Asia, and North America. Orders ship via reliable FOB China ports, with list prices reflecting exceptional value and competitive pricing. Standard delivery times are prompt, minimizing your project's lead-time. Our charges remain transparent, ensuring customers are fully informed at all stages, while flexible supply options suit traders, wholesalers, and suppliers alike.

FAQ's of MEANWELL POWER SUPPLY, NES-50-24 INPUT: 100-240VAC 1.3A OUTPUT: +24V 2.2A:

Q: How can the adjustable voltage range benefit my specific industrial application?

A: The adjustable voltage range of 21.6 to 28.8V allows users to fine-tune output according to equipment requirements, enhancing compatibility and optimizing system performance in diverse industrial scenarios.

Q: What are the primary safety features included in the MEANWELL NES-50-24 power supply?

A: This model incorporates protections against overload, overvoltage, and short circuits. It's certified under robust safety standards like EN61000-3-2 Class A and EN55022 Class B, ensuring reliable and secure operation.

Q: Where is the MEANWELL NES-50-24 typically installed?

A: It is typically chassis mounted in control panels, industrial automation equipment, LED displays, and instrumentation setups, making it ideal for both new builds and equipment upgrades.

Q: What is the ordering process and standard lead time for delivery?

A: After placing an order and confirming details, shipment is arranged from China FOB ports. Standard delivery time is promptly managed to ensure your equipment arrives swiftly, supporting project timelines effectively.

Q: How does competitive pricing influence the decision to choose this power supply?

A: Competitive pricing provides excellent value without compromising on top-tier features, making this unit an attractive and cost-efficient solution for projects needing reliable, resplendent power supplies.
