CR30-15DP Capacitive Sensor

CR30-15DP Capacitive Sensor Specification

Application
Detection of metallic and non-metallic objects, level sensing

Wireless
No

Mounting Type
Flush Mount/Non-Flush

Power Consumption
<10 mA

Measurement Range
15 mm

Operating Temperature
-25C to +70C

Sensitivity
Adjustable

Response Time
<10 ms

Features
Short-circuit protection, Reverse polarity protection

Sensor Type
Capacitive Proximity Sensor

Cable Length
2 m

Interface
Cable 3-wire

IP Rating
IP67

Signal Type
Digital

Product Type
Capacitive Sensor

Material
Metal

Input
DC

Output
PNP/NO (Normally Open)

Function
Sensing

Usage
Commercial

Accuracy
High

Resolution
Precise

Voltage
10-30 V DC

Weight
Approx 100 g

Warranty
Yes

Shock Resistance
30 G, 11 ms

Output Current
Max 200 mA

Vibration Resistance
10-55 Hz, 1.5 mm amplitude

Protection Circuit
Overload & short circuit protection

Indicator
LED Status Indicator

Shell Diameter
30 mm

Storage Temperature
-40C to +80C

Ambient Humidity
3595% RH

Housing Material
Nickel-plated Brass

Switching Frequency
Up to 50 Hz

CR30-15DP Capacitive Sensor Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

CR30-15DP Capacitive Sensor About

Experience the elite performance of the CR30-15DP Capacitive Sensor, a stellar solution designed for precise detection of both metallic and non-metallic objects. Boasting a mighty shell diameter of 30 mm and a majestic measurement range of 15 mm, this sensor stands out with a lofty switching frequency up to 50 Hz. Housed in durable nickel-plated brass, it offers reliable overload and short circuit protection. Its LED status indicator, high accuracy, and robust IP67 rating make it a popular choice for commercial sensing needs across India.

Targeted Application & Versatile Features

The CR30-15DP Capacitive Sensor is engineered for the precise detection of a wide array of materials, both metallic and non-metallic. Easily installed via flush or non-flush mounting, it is ideal for level sensing and object detection in commercial environments. With an adjustable sensitivity and high-resolution accuracy, users benefit from stellar performance even in challenging operating conditions. Its LED indicator, robust build, and overload protection set it apart for general and specialized use.

Packing & Dispatch for Global Markets

CR30-15DP Capacitive Sensors are meticulously packed to ensure safe delivery. Exported globally, they're frequently handed over to major international clients as well as local suppliers, traders, and wholesalers across India. Each unit is individually packaged with appropriate labeling and documentation, reflecting lofty quality standards. Sample policies are customer-friendly, making it easy to assess product suitability before bulk orders. Packing & dispatch processes follow systematic guidelines, guaranteeing prompt and efficient service worldwide.

FAQ's of CR30-15DP Capacitive Sensor:

Q: How does the CR30-15DP Capacitive Sensor operate in commercial applications?

A: The CR30-15DP uses its capacitive technology to sense the presence of metallic and non-metallic objects up to 15 mm away, making it ideal for industrial automation, level sensing, and general object detection tasks.

Q: What are the main benefits of choosing the CR30-15DP over other sensors?

A: This sensor offers precise measurement, high accuracy, and built-in protections like overload and short-circuit prevention. Its robust nickel-plated brass housing and IP67 rating ensure reliable operation in harsh environments.

Q: When should I use flush mounting versus non-flush mounting?

A: Flush mounting is suitable when you need the sensor face flush with the surrounding surface, providing protection, while non-flush mounting allows for greater sensitivity in open detection zones.

Q: Where can I purchase CR30-15DP sensors in bulk?

A: You can obtain the CR30-15DP sensor through authorized suppliers, traders, and wholesalers across India. International buyers can also arrange direct export orders.

Q: What is the process for obtaining samples before placing a large order?

A: Simply contact the supplier or trader regarding your sample requirements. Sample policies are designed to be accessible, allowing you to evaluate the product before committing to wholesale quantities.
