AUTONICS CAPACITIVE SENSOR, BWP20-16

AUTONICS CAPACITIVE SENSOR, BWP20-16 Specification

Features
Short-circuit protection, surge protection, LED Indicator

Mounting Type
Panel / Flush Mount

IP Rating
IP67

Operating Temperature
-25C to +70C

Application
Packaging, food, beverage, plastic, chemical, and general automation industries

Wireless
No

Power Consumption
Max. 25mA

Response Time
Under 10ms

Measurement Range
16mm (sensing distance)

Interface
3-Wire DC

Signal Type
PNP Output

Sensor Type
Capacitive

Sensitivity
Adjustable via potentiometer

Cable Length
2m Cable

Product Type
Capacitive Proximity Sensor

Material
Polybutylene Terephthalate (PBT) Housing

Input
12-24V DC

Output
PNP, Normally Open (NO)

Function
Detects presence of solids or liquids (non-metallic)

Usage
Object detection / level sensing

Accuracy
High stability, precision controlled switching distance

Voltage
12-24V DC

Weight
Approx. 52g

Reverse Polarity Protection
Yes

Case Size
20 x 68 mm

Indicator
Red LED (operation indicator)

Rated Supply Voltage
12-24V DC ±10%

Shock Resistance
500 m/s² (50G), 3 times each in X, Y, Z direction

Sensing Object
Solids and liquids (non-metallic, conductive and non-conductive)

Cable Type
Oil, water, and chemical resistant cable

Model Number
BWP20-16

Operating Humidity
35 to 95% RH, non-condensing

Control Output
PNP, NO

Vibration Resistance
10-55 Hz, amplitude 1.5 mm for 1 hour in each X, Y, Z direction

Maximum Sensing Distance
16 mm

Housing Material
PBT (Polybutylene Terephthalate), yellow

About AUTONICS CAPACITIVE SENSOR, BWP20-16

Introducing the sizzling AUTONICS CAPACITIVE SENSOR, BWP20-16 - an in-demand, valorous solution engineered for praiseworthy performance across varied industrial domains. Detect solids and liquids with exceptional accuracy using its uncommon technology and robust PBT housing. Featuring advanced PNP, NO control output, precise 16mm sensing range, and reliable red LED indicators, this sensor thrives in harsh environments with IP67 protection, high vibration and shock resistance. Order today and secure your processes with this trusted sensor, ideal for packaging, food, beverage, plastics, and chemical industries!

Versatile Applications & Standout Features

The AUTONICS CAPACITIVE SENSOR, BWP20-16 is widely used for detecting the presence or level of non-metallic solids and liquids in automation systems. Its potent features such as adjustable sensitivity, high vibration and shock resistance, and short-circuit protection make it praiseworthy for plant applications requiring precision. Valorous against tough industrial conditions, this uncommon sensor ensures seamless object detection in packaging, food, beverage, and chemical plants, enhancing operational reliability and efficiency.

Packaging, Certifications & Supply Details

Supplied with secure, industrial-grade packaging, the AUTONICS BWP20-16 arrives ready for integration. Certified for durability and exceptional safety, it meets rigorous industry standards, reflecting its praiseworthy build. With regular, steady supply from our trusted network in China, this sensor is available at a competitive asking price, optimizing your project's expenditure. Our consistent supply ability ensures you get timely deliveries, making procurement and productivity hassle-free and cost-effective for all stakeholders.

FAQ's of AUTONICS CAPACITIVE SENSOR, BWP20-16:

Q: How does the AUTONICS BWP20-16 capacitive sensor operate in different industrial environments?

A: The sensor reliably detects non-metallic solids and liquids using precision-controlled technology, withstanding harsh environments thanks to its PBT housing, IP67 rating, and strong vibration and shock resistance.

Q: What are the benefits of using this sensor in packaging and chemical plants?

A: It enhances operational reliability and efficiency through accurate level and object detection, easy sensitivity adjustments, and protection features such as short-circuit and surge safeguards, contributing to seamless process automation.

Q: Where is the AUTONICS BWP20-16 most commonly applied?

A: This sensor is predominantly used in the packaging, food, beverage, plastics, and general automation industries where precise monitoring and automation are required.

Q: What certifications and packaging details support its industrial use?

A: The sensor is securely packaged for industrial shipment and adheres to industry standards, ensuring safety and durability during transport and deployment in demanding environments.

Q: How can I order and what is the supply ability for the AUTONICS BWP20-16?

A: You can place your order with us today; our supply network in China guarantees a steady, reliable stream of inventory at competitive expenditure, meeting both urgent and large-scale procurement needs.
