COLMAS MAGNETIC REED SWITCH, CS1-U

COLMAS MAGNETIC REED SWITCH, CS1-U Specification

Number of Module
Single

Protection Level
IP67

Response Time
1 ms

Temperature Range
-10C to +70C

Finish Type
Glossy/Standard

Automation Grade
Automatic

Circuit Type
Normally Open (NO)

Max. Current
100 mA

Mechanical Life
over 10 million operations

Rated Voltage
5-100V DC/AC

Product Type
Magnetic Reed Switch

Material
ABS Plastic / Metal

Insulation Resistance
100 M at 500VDC

Contact Resistance
150 m

Max. Voltage
100V DC/AC

Operating Temperature
-10C to +70C

Stoke
10mm (Typ.)

Size
Standard CS1-U designation

Color
Blue/White (Label color may vary)

Weight
approx. 10g

Mounting Type
Side/Fit to standard pneumatic cylinders

Current Rating
100 mA max

No Of Poles
1

Vibration Resistance
10-55Hz, amplitude 1.5mm

Shock Resistance
300m/s2 (approx.)

Cable Type
2-wire, standard length 2m

Contact Form
SPST (Single Pole Single Throw)

Model
CS1-U

Switching Frequency
up to 1000 Hz

Application
Pneumatic Cylinder Position Detection

Operation Indicator
LED (Red)

COLMAS MAGNETIC REED SWITCH, CS1-U Trade Information

Minimum Order Quantity
2 Pieces

Delivery Time
5-7 Days

COLMAS MAGNETIC REED SWITCH, CS1-U About

Try now the highly sought-after COLMAS MAGNETIC REED SWITCH, CS1-U - an impeccable solution in demand among automation experts. Engineered for precise pneumatic cylinder position detection, this uncommon switch features a robust ABS plastic/metal body, IP67 protection, and an LED operation indicator. With industry-leading specs like a 1 ms response time, 100 mA max current, shock resistance of 300m/s2, and over 10 million operations mechanical life, the CS1-U ensures impeccable performance for automatic control. Find reliability and innovation-order the CS1-U today!

Versatile Application for Modern Automation

The COLMAS MAGNETIC REED SWITCH, CS1-U excels in application media such as pneumatic cylinders for position detection. Its main areas of application cover industrial automation, assembly lines, and factory settings where accurate and rapid sensing is crucial. Designed for high-frequency switching (up to 1000 Hz), this device is ideal for usage in robotics, packaging machinery, and equipment needing durable, repeatable cylinder presence verification.

Efficient Supply, Flexible Markets, Quick Delivery

With a strong supply ability, the COLMAS MAGNETIC REED SWITCH, CS1-U is available at a competitive sale price to buyers worldwide. It caters to exporters, suppliers, traders, and wholesalers seeking prompt order completion. Main export markets include Asia, Europe, and the Middle East. Delivery time is streamlined for exchange and fast shipping, allowing businesses to maintain inventory levels and respond quickly to industrial demand.

FAQ's of COLMAS MAGNETIC REED SWITCH, CS1-U:

Q: How does the CS1-U magnetic reed switch operate in detecting pneumatic cylinder positions?

A: The CS1-U operates by sensing the magnetic field generated as the pneumatic cylinder moves, triggering its internal SPST contact to indicate the cylinder's position. Its LED indicator lights up during operation for visual confirmation.

Q: What are the primary usage benefits of the COLMAS CS1-U switch in automation systems?

A: The CS1-U provides reliable position detection, fast 1 ms response, IP67 protection, and an extended mechanical life. These benefits make it highly effective for precise, repeatable operations in automated equipment and harsh industrial environments.

Q: Where can the COLMAS MAGNETIC REED SWITCH, CS1-U be installed?

A: It can be side-mounted or fitted to standard pneumatic cylinders across a wide range of machines in factory automation, packaging, material handling, and robotics applications.

Q: When should you consider using the CS1-U model for your machinery?

A: You should consider the CS1-U if your applications demand high-frequency switching, reliable operation in variable temperatures (-10C to +70C), or long mechanical life in repetitive-use environments.

Q: What is the order and delivery process for the COLMAS CS1-U reed switch?

A: Simply place an order through our export/trade channels. After order completion, the switches are promptly packaged and dispatched, with delivery timelines suiting domestic and major international markets.
