AUTONICS,ROTARY ENCODER, E40S6-3600-3-T-24

AUTONICS,ROTARY ENCODER, E40S6-3600-3-T-24 Specification

Rated Voltage
24V

Voltage
24V

Pressure
Not Specified

Bearing Type
Ball Bearing

Sealed Type
Not Specified

Current Type
DC

Features
Compact size, High resolution, Durable construction, Wide operating voltage range

Ambient Temperature
-10°C to +70°C

Product Type
Rotary Encoder

Protect Feature
Not Specified

Power
24V

Color
Metallic (Standard Industrial Finish)

Dimension (L*W*H)
Approx. 40 mm diameter (outer case), length approx. 40 mm

Weight
Approx. 250 g

Shaft Diameter
6 mm

Mounting Type
Clamping / Shaft Mounting

IP Rating
IP50

Output Phase
A, B, Z (3 Phase)

Torque (starting)
50 gfcm or less

Allowable Radial Load
3 kgf

Output Shaft Material
Stainless Steel

Vibration Resistance
10~55 Hz, amplitude 1.5 mm, X, Y, Z directions each 2 hours

Resolution
3600 pulses per revolution (P/R)

Case Material
Aluminum

Cable Entry
Axial

Model
E40S6-3600-3-T-24

Dielectric Strength
500VAC, 50/60 Hz for 1 minute

Connection Type
Cable type (1 m, standard)

Supply Voltage
12-24V DC 5%

Shock Resistance
490 m/s2, 3 times for each X, Y, Z direction

Output Type
NPN Open Collector

Allowable Axial Load
5 kgf

Rotational Speed (max)
5000 RPM

Response Frequency
Max. 100 kHz

Insulation Resistance
100M (at 500VDC megger)

About AUTONICS,ROTARY ENCODER, E40S6-3600-3-T-24

Introducing the AUTONICS ROTARY ENCODER E40S6-3600-3-T-24, a scarce and highly sought-after solution crafted for precise motion sensing applications. Featuring an exceptional resolution of 3600 pulses per revolution, this rare incremental encoder is engineered with a stainless steel output shaft and an aluminum case for optimum durability. Its wide voltage range (12-24V DC 5%%), robust vibration, and shock resistance guarantee reliable performance in demanding industrial environments. Compact yet powerful, the E40S6-3600-3-T-24 stands as a special choice among traders and suppliers requiring unwavering accuracy and longevity.

Outstanding Advantages and Versatile Applications

The AUTONICS E40S6-3600-3-T-24 is renowned for its compact design, high resolution, and robust stainless steel construction, making it a preferred choice for industrial automation and robotics. Its optimum torque and reliable performance are utilized by manufacturers, automation integrators, and production line managers. This encoder excels in environments where accurate position feedback is crucial, offering a special edge to users requiring stable and precise rotary measurements for their automation solutions.

Certifications, Packaging, and Export Markets

The E40S6-3600-3-T-24 is dispatched in professionally packaged, secure boxes suitable for global export. Competitive asking prices are available for this item, meeting standards expected in major international markets, including Asia and North America. All shipments are handled with care to ensure the condition and integrity of each unit upon delivery. AUTONICS products are trusted by clients who prioritize quality, reliability, and secure shipping every time.

FAQs of AUTONICS,ROTARY ENCODER, E40S6-3600-3-T-24:

Q: How is the AUTONICS E40S6-3600-3-T-24 typically installed in industrial environments?

A: The encoder is designed for clamping or shaft mounting, allowing straightforward integration into various industrial machines and systems with its compact size and standard cable connection.

Q: What are the primary benefits of using this incremental rotary encoder?

A: Key benefits include high resolution (3600 P/R) for precise positioning, exceptional durability due to its stainless steel shaft and aluminum case, and wide supply voltage compatibility, making it suitable for demanding applications.

Q: When should I choose this encoder over others in the market?

A: Choose the E40S6-3600-3-T-24 when you require a rare combination of compact dimensions, high pulse accuracy, and reliable operation under conditions involving vibration or shock, such as robotics or CNC machinery.

Q: Where can this AUTONICS rotary encoder be used?

A: It is ideal for applications in factory automation, robotics, conveyors, CNC equipment, and other scenarios demanding precise rotational measurement and feedback.

Q: What is the process for ordering and receiving this encoder internationally?

A: Orders are processed through certified suppliers and traders, with secure shipping and professional packaging, ensuring safe delivery across major global markets.

Q: How does the output type and phase configuration benefit specific applications?

A: The NPN open collector with A, B, Z (3 phase) output provides flexible pulse reading and direction sensing, supporting advanced motion control and monitoring requirements.
