OMRON ROTARY ENCODER 12 TO 24VDC, E6CP-AG5C 256 P/R 2M

OMRON ROTARY ENCODER 12 TO 24VDC, E6CP-AG5C 256 P/R 2M Specification

Ambient Temperature
-10C to 70C (no icing or condensation)

Features
Incremental encoder with line driver output, high-precision

Current Type
DC

Standard
CE, RoHS

Voltage
12 to 24 VDC

Bearing Type
Ball bearing

Sealed Type
Dustproof

Rated Voltage
12 to 24 VDC

Product Type
Rotary Encoder

Protect Feature
Reverse polarity protection

Color
Black

Dimension (L*W*H)
Approx. 50mm diameter x 50mm length

Weight
Approx. 300g

Shaft Diameter
8mm

Mounting Type
Shaft mount

IP Rating
IP50

Max. Response Frequency
100 kHz

Output Type
Line Driver

Dielectric Strength
1,000 VAC 50/60 Hz for 1 min between terminals and housing

Shock Resistance
500 m/s2, 3 times each in X, Y, Z directions

Output Phase
A, B, Z (incremental outputs)

Cable Length
2 Meters

Shaft Type
Solid Shaft

Resolution
256 pulses per revolution (P/R)

Model Number
E6CP-AG5C 256 P/R 2M

Housing Material
Metal

Insulation Resistance
100 M min. (at 500 VDC)

Storage Temperature
-25C to 85C (no icing or condensation)

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Connection Type
Pre-wired cable

About OMRON ROTARY ENCODER 12 TO 24VDC, E6CP-AG5C 256 P/R 2M

Experience the illustrious performance of the OMRON ROTARY ENCODER 12 TO 24VDC, Model E6CP-AG5C 256 P/R 2M. With a supreme resolution of 256 pulses per revolution and a valorous line driver output, this encoder guarantees precision and reliability. Its robust metal housing, dustproof build, and advanced reverse polarity protection epitomize value and durability. Secure this hot deal and try now-ideal for challenging industrial automation tasks requiring exceptional accuracy. The 2-meter pre-wired cable ensures easy setup, making it a top-tier choice for diverse environments.

Versatile Usage Across Industries

The OMRON E6CP-AG5C 256 P/R 2M Rotary Encoder is suitable for use in automated manufacturing, robotics, conveyor systems, and motor positioning applications. This incremental encoder excels in demanding environments where reliability, precision, and high speed are required. Its supreme build makes it perfect for industries such as packaging, material handling, machine tools, and more. Whether for OEMs or system integrators, this encoder delivers illustrious performance in both new and retrofit installations.

Sample Availability, Export Markets & Shipping Details

Samples of the OMRON E6CP-AG5C 256 P/R 2M Rotary Encoder are available for evaluation before making a bulk purchase. Our main export markets include Asia, Europe, and the Middle East via FOB China. Estimate shipment charges based on destination, and expect efficient handling of your order to ensure timely delivery. Request your sample and obtain an accurate estimate for charge and shipment directly from our trusted supplier and exporter.

FAQ's of OMRON ROTARY ENCODER 12 TO 24VDC, E6CP-AG5C 256 P/R 2M:

Q: How does the OMRON E6CP-AG5C rotary encoder enhance accuracy in industrial automation?

A: The encoder features 256 pulses per revolution and a line driver output, offering precise incremental feedback for accurate position and speed control in automation systems.

Q: What is the benefit of the encoder's robust mechanical and electrical design?

A: Its metal housing, shock and vibration resistance, and reverse polarity protection ensure longevity and reliability, making it suitable for demanding industrial environments.
