AUTONICS,ROTARY ENCODER, E40S6-100-3-T-24

AUTONICS,ROTARY ENCODER, E40S6-100-3-T-24 Specification

Ambient Temperature
-10C to +70C (No freezing or condensation)

Bearing Type
Ball Bearing

Rated Voltage
24V DC

Voltage
24V DC

Standard
CE Certified

Current Type
DC

Features
Incremental Rotary Encoder, Small-size, Solid shaft, High reliability

Product Type
Rotary Encoder

Protect Feature
Reverse Connection Protection

Color
Black/Silver

Dimension (L*W*H)
40 x 38 mm (Body diameter x Length)

Weight
Approx. 200g

Shaft Diameter
6 mm

Mounting Type
Servo Mount (Clamping) Type

Moment of Inertia
Max. 6 x 10 kgm

Allowable Radial Load
30 N

Output Phase
A, B, Z Output

Power Consumption
Max. 40 mA

Cable Length
2 meters

Allowable Thrust Load
20 N

Maximum Response Frequency
300 kHz

Resolution
100 PPR (Pulses per Revolution)

Output Method
NPN Open Collector

About AUTONICS,ROTARY ENCODER, E40S6-100-3-T-24

Pick yours from the exceptional selection of AUTONICS Rotary Encoders and experience matchless performance with the E40S6-100-3-T-24, an extraordinary solution for precise motion control. With an ineffable accuracy of 100 PPR, robust NPN Open Collector output, and solid shaft construction, this compact and affordable device ensures reliable feedback in demanding scenarios. The reverse connection protection, CE certification, and IP50 rating grant secure access to quality. Its lightweight, high-response design makes it the perfect fit for modern automation requirements. Access unparalleled quality-choose AUTONICS today!

Versatile Commercial Application

The AUTONICS E40S6-100-3-T-24 Rotary Encoder is widely adopted in factory automation, CNC machinery, robotics, and conveyor systems. Its solid performance and compact size make it ideal for manufacturing facilities, packaging plants, and industrial sites that require precise rotation measurement. Utilize its durability and efficiency to enhance process monitoring and position control in a variety of environments, ensuring supreme operational reliability across an array of commercial uses.

Efficient Packaging and Global Reach

Order processing for the AUTONICS E40S6-100-3-T-24 is streamlined for a hassle-free arrival at your destination. Each encoder is carefully boxed to ensure safe transit. FOB Port options include Korea North, which allows for rapid, secure shipments worldwide. Request a quotation today for main export markets including Asia, the Middle East, and Europe, and access extraordinary quality backed by prompt logistics and dedicated customer support.

FAQ's of AUTONICS,ROTARY ENCODER, E40S6-100-3-T-24:

Q: How does the E40S6-100-3-T-24 Rotary Encoder enhance industrial automation?

A: This encoder provides accurate feedback with 100 pulses per revolution, enabling precise control in automation tasks, reducing errors and improving process efficiency across various applications.

Q: What are the notable benefits of using a NPN Open Collector output in this encoder?

A: NPN Open Collector outputs offer compatibility with a range of PLCs and controllers, provide robust signal transmission, and ensure reliable operation in demanding industrial environments.

Q: Where is the AUTONICS E40S6-100-3-T-24 typically installed?

A: It's commonly installed in machinery such as CNC machines, robotics, conveyor belts, and automated assembly lines within manufacturing and packaging industries.

Q: When should the rotary encoder be replaced or maintained?

A: Regular inspection is recommended, and replacement should be considered if accuracy degrades or excessive wear occurs, especially in high-load or continuous-use environments.

Q: What is the process for placing an order and obtaining a quotation for this product?

A: Customers can request a quotation via the supplier or wholesaler. Once confirmed, streamlined order processing ensures secure packaging and prompt shipment from the designated FOB Port.

Q: How does the reverse connection protection feature improve usage safety?

A: This protection prevents potential damage due to incorrect wiring, enhancing safety during installation and extending the lifespan of the equipment.
