AUTONICS ,ROTARY ENCODER, E40H8-1024-3-T-24

AUTONICS ,ROTARY ENCODER, E40H8-1024-3-T-24 Specification

Ambient Temperature
-10°C to +70°C (Non-freezing, non-condensing)

Rated Voltage
12-24VDC Volt (V)

Features
Compact size, Incremental output, 1024 pulses/rev, NPN Open Collector output, Durable construction

Voltage
12-24VDC Volt (v)

Sealed Type
Not Specified

Current Type
DC

Bearing Type
Ball Bearing

Product Type
Rotary Encoder

Protect Feature
Not Specified

Color
Black/Silver

Dimension (L*W*H)
40 mm diameter (E40 series)

Weight
Approx. 160g

Shaft Diameter
8 mm

Mounting Type
Shaft-mount, Clamping flange

IP Rating
IP50

Power Supply
12-24VDC 5%

Output Phase
A, B, Z (3-phase output)

Encoder Type
Incremental Rotary Encoder

Pulse per Revolution (PPR)
1024

Body Material
Aluminum

Shaft Material
Stainless Steel

Output Type
NPN Open Collector

Model
E40H8-1024-3-T-24

Dielectric Strength
500VAC, 60Hz for 1 min

Vibration Resistance
5-50Hz, 1.5 mm double amplitude

Insulation Resistance
20M Min. (at 500VDC)

Shock Resistance
50G, 11 ms duration

Starting Torque
Max. 70 gfcm (at 20C)

Max. Response Frequency
300 kHz

Connection Type
Cable

Cable Type
Axial, 2 m length

Maximum Allowable Revolution
5000 rpm

About AUTONICS ,ROTARY ENCODER, E40H8-1024-3-T-24

Buy the AUTONICS Rotary Encoder E40H8-1024-3-T-24an outstanding, top-rated choice for precise motion control applications. This top-notch incremental rotary encoder boasts 1024 pulses per revolution, delivering splendiferous accuracy and robust reliability. With its valiant stainless steel shaft and aluminum body, it withstands demanding environments, vibration, and shock. Enjoy NPN open collector output and axial 2m cabling for flexible installation. Shop now to experience AUTONICS engineeringcompact, durable, and perfect for suppliers, traders, and wholesalers seeking high-performance in every revolution.

Versatile Application Across Industries

The AUTONICS Rotary Encoder E40H8-1024-3-T-24 is suitable for automation, robotics, and industrial machinery. Used by OEMs, system integrators, and maintenance professionals, it excels in precision feedback for motor control, conveyor systems, and assembly lines. Its incremental output and compact design make it ideal for space-limited environments requiring dependable signal transmission and accuracy. This encoder adapts seamlessly to modern manufacturing, laboratory, and packaging processes, ensuring consistent operational excellence.

Efficient Order Processing & Delivery

Serving the main domestic market with quick dispatch options, this encoder is available at competitive proposal amounts. Orders ship from designated FOB ports in China, ensuring rapid order completion and reliable supply chain management. Packaging detailsincluding robust protectionensure safe delivery, minimizing transit damage for the E40H8-1024-3-T-24. Customers benefit from streamlined procurement and outstanding support throughout the ordering process, ideal for wholesalers, suppliers, and traders seeking efficiency.

FAQs of AUTONICS ,ROTARY ENCODER, E40H8-1024-3-T-24:

Q: How is the AUTONICS E40H8-1024-3-T-24 rotary encoder installed?

A: The encoder features a shaft-mount design with an 8 mm shaft diameter and clamping flange for secure installation in various machinery. Its axial cable (2 m length) simplifies electrical connections during setup.

Q: What specific environments are suitable for this rotary encoders usage?

A: The E40H8-1024-3-T-24 operates efficiently in ambient temperatures from -10C to +70C, withstanding vibration, shock, and industrial conditions in manufacturing, robotics, and laboratory automation.

Q: When should I consider upgrading to this encoder model?

A: If your application demands precise incremental feedback, high response frequency, and reliability in tough environments, upgrading to the E40H8-1024-3-T-24 enhances performance and operational accuracy.

Q: Where can I order the AUTONICS rotary encoder and what is the delivery process like?

A: You can place orders through authorized suppliers, traders, and wholesalers in China. Quick dispatch and robust packaging ensure order completion and safe delivery to your specified location.

Q: What are the main benefits of using this AUTONICS rotary encoder?

A: The encoder delivers high-resolution pulse output, durable construction, resistance to shock and vibration, and easy integration for automated control, making it a top-choice for industrial and factory automation.
