AUTONICS, ROTARY ENCODER, E40H8-1024-3-T-24

AUTONICS, ROTARY ENCODER, E40H8-1024-3-T-24 Specification

Standard
CE conformity

Sealed Type
IP50

Bearing Type
Ball bearing

Features
Incremental rotary encoder, Compact size, Metal housing

Ambient Temperature
-10C to +70C (non-freezing)

Rated Voltage
DC 524V

Voltage
DC 524V 5%

Product Type
Rotary Encoder

Protect Feature
Reverse connection protection, Overcurrent protection

Speed
Max. response frequency: 300 kHz

Color
Black & Silver

Dimension (L*W*H)
40 mm diameter, approx. 35 mm length (housing)

Weight
Approximately 150 g

Shaft Diameter
8 mm

Mounting Type
Clamp flange

IP Rating
IP50

Max. Response Frequency
300 kHz

Dielectric Strength
AC 500V, 60 Hz for 1 min

Material
Aluminum case, stainless steel shaft

Rotational Direction
Bi-directional

Insulation Resistance
Over 100 M (at 500 VDC) between live part and case

Output Phase
A, B, Z (3 Phase Output)

Sensing Method
Incremental

Output Method
NPN Open Collector

Connection Type
Cable Type (2 m length)

Resolution
1024 P/R (Pulses per Revolution)

Vibration Resistance
1055 Hz, 1.5 mm double amplitude

Shock Resistance
490 m/s (approx. 50G)

Allowable Shaft Load
Radial: 30 N Max., Thrust: 20 N Max.

Model
E40H8-1024-3-T-24

About AUTONICS, ROTARY ENCODER, E40H8-1024-3-T-24

Add to Cart the acclaimed AUTONICS ROTARY ENCODER, model E40H8-1024-3-T-24, a glorious and radiant instrument engineered for peak precision. Featuring a best-in-class 1024 pulses per revolution and triple phase output (A, B, Z), this encoder boasts an incremental sensing method within a robust aluminum case. Enjoy bi-directional rotation, cable connection, and speed up to 300 kHz. Shop Now to secure your compact, metal-housed encoder with CE conformity and comprehensive protection features-perfect for demanding industrial automation applications.

Versatile Applications & Competitive Edge

The AUTONICS E40H8-1024-3-T-24 Rotary Encoder is used as a feedback device in motion control systems, including robotics, CNC machines, and automated assembly lines. Its competitive advantages include a compact size, robust metal body, and high-resolution output, making it ideal for precise bi-directional control and positioning. Direction of use: Mount the encoder on a rotating shaft, connect the cable, and utilize its triple phase output for precise signal acquisition and operational reliability.

Flexible Sample Policy & Certified Delivery

Shipped goods from authorized suppliers come with competitive sample policies for evaluation at the lowest price. Certified to CE standards, this encoder assures quality and reliability. Estimate delivery time ranges from prompt dispatch to several business days, depending on order volume and location. Buyers receive goods securely packaged and with full technical support, ensuring seamless integration into existing systems and worry-free installation.

FAQ's of AUTONICS, ROTARY ENCODER, E40H8-1024-3-T-24:

Q: How is the AUTONICS E40H8-1024-3-T-24 Rotary Encoder typically used in industrial applications?

A: This rotary encoder is used for precise position and speed feedback in automation, robotics, and CNC machinery, aiding in controlling motor and axis movements.

Q: What competitive advantages does the AUTONICS E40H8-1024-3-T-24 offer over other rotary encoders?

A: It delivers high-resolution output, robust metal housing, triple phase signaling, and comprehensive protection features, giving it outstanding performance and durability in harsh environments.

Q: When can customers expect shipped goods after placing an order for the E40H8-1024-3-T-24?

A: Orders are usually processed promptly. Delivery estimates vary according to supplier and destination but are generally within a few business days, with tracking available on request.

Q: Where is the AUTONICS E40H8-1024-3-T-24 sourced from, and does it meet certification standards?

A: The encoder is supplied, traded, and wholesaled from China by authorized vendors. It conforms to CE certification, with rigorous quality assurance processes in place.

Q: What is the recommended process for installing and using the E40H8-1024-3-T-24 rotary encoder?

A: Mount the encoder securely using the clamp flange, connect the supplied cable, and ensure correct voltage. Utilize output phases A, B, and Z to integrate into your control system for real-time feedback.

Q: How does the compact size of the rotary encoder benefit system integration?

A: Its small diameter and lightweight build allow easy installation even in limited spaces, while maintaining performance and reducing overall equipment footprint.
