AUTONICS ROTARY ENCODER,E40H8-1024-3-T-24

AUTONICS ROTARY ENCODER,E40H8-1024-3-T-24 Specification

Rated Voltage
12-24V DC

Voltage
12-24V DC

Bearing Type
Ball Bearing

Features
Incremental Rotary Encoder, Durable Aluminum Housing, Compact Size

Ambient Temperature
-10C to +70C

Current Type
DC

Standard
CE Certified

Product Type
Rotary Encoder

Protect Feature
IP50

Phase
3 Phase (Output: A, B, Z) / Square Wave Output

Speed
6000 RPM Max.

Color
Black / Silver

Dimension (L*W*H)
Diameter 40mm x Shaft Length 30mm (approx.)

Weight
Approx. 120g

Shaft Diameter
8mm

Mounting Type
Clamping / Servo Mount

IP Rating
IP50

Cable Length
2 meters (Shielded PVC)

Output Phase
A, B, Z channels

Output Type
NPN Open Collector

Sensing Method
Optical

Response Frequency
300kHz

Model Number
E40H8-1024-3-T-24

Resolution
1024 PPR (Pulses Per Revolution)

Allowable Radial Load
30N

Storage Temperature
-25C to +85C

Output Voltage
High: Min. (Vcc - 2.5V), Low: Max. 0.4V

Connection Type
Cable (Radial Type)

Allowable Axial Load
20N

About AUTONICS ROTARY ENCODER,E40H8-1024-3-T-24

Grab the triumphant AUTONICS ROTARY ENCODER, E40H8-1024-3-T-24 and unlock kingly precision at a superlative price cut! This industrial-grade encoder boasts a remarkable resolution of 1024 PPR, engineered with robust ball bearings and an 8mm shaft. Its optical sensing method and incremental output (A, B, Z phases) deliver accuracy for high-speed applications up to 6000 RPM. The durable, shielded 2-meter cable ensures reliability, while its compact, CE-certified aluminum housing promises lasting performance. Secure your edge-choose the encoder that reigns supreme in plant automation!

Exceptional Features and Versatile Plant Applications

The AUTONICS ROTARY ENCODER, E40H8-1024-3-T-24 stands out with its incremental, three-phase output and durable aluminum housing. Compact yet powerful, it supports up to 6000 RPM-ideal for assembly lines, packaging machines, and conveyor systems. Its high-resolution sensing and shielded wiring guarantee reliable, accurate feedback in complex manufacturing environments. With CE certification and wide voltage support, this encoder unlocks kingly efficiency for automation, robotics, and motion-control applications across a range of industries.

Packaging, Delivery, and Payment-Lowest Price, Fast Arrival

Each AUTONICS encoder is meticulously packed to ensure its safe arrival, ready for immediate installation. As top suppliers and wholesalers catering to the main domestic markets, we guarantee swift and secure delivery. Enjoy the lowest price without compromise on quality. Payment terms are customer-friendly and adaptable, making the purchasing process smooth and worry-free. Choose us for prompt delivery and peace of mind on your industrial automation components.

FAQ's of AUTONICS ROTARY ENCODER,E40H8-1024-3-T-24:

Q: How does the AUTONICS ROTARY ENCODER, E40H8-1024-3-T-24 enhance automation systems?

A: This encoder delivers high-resolution signal feedback (1024 PPR), improving positioning accuracy and control in industrial automation, robotics, and conveyor systems.

Q: What type of output does the E40H8-1024-3-T-24 provide?

A: It offers an NPN open collector output with three phases (A, B, Z), generating a square wave signal suitable for incremental positioning.

Q: Where can the AUTONICS rotary encoder be used?

A: It is commonly applied in machine tools, packaging machinery, factory conveyors, robotics, and other plants requiring precise motion feedback.

Q: What is the process for installing this rotary encoder?

A: Install the encoder using either the clamping or servo mount provided. Connect the shielded PVC cable (2 meters) directly to your control system, ensuring proper orientation of the A, B, and Z output channels.

Q: What is the benefit of the IP50-rated durable aluminum housing?

A: The IP50 rating and robust aluminum construction provide reliable protection against dust and moderate environmental factors, ensuring long-term stability.
