AUTONICS PROXIMTY SWITCH,PRT18-8DO

AUTONICS PROXIMTY SWITCH,PRT18-8DO Specification

Number of Module
Single

Circuit Type
NPN Normally open (3-wire)

Temperature Range
-25C to +70C

Finish Type
Nickel-plated

Rated Voltage
12-24V DC

Max. Current
200 mA

Response Time
2 ms

Protection Level
IP67

Automation Grade
Standard

Mechanical Life
10,000,000 operations min.

Product Type
Proximity Switch

Material
Nickel-plated brass

Insulation Resistance
50 M (at 500 VDC megger)

Contact Resistance
100 m

Max. Voltage
250V AC

Operating Temperature
-25C to +70C

Size
18 x 60 mm

Color
Metallic Grey

Weight
70 g (approx.)

Mounting Type
Flush (shielded)

Current Rating
200 mA (max)

No Of Poles
3-wire type

Supply Voltage
12-24V DC 10%

Additional product specifications

Storage Temperature
-30C to +80C

Voltage Drop
1.5V

Sensing Distance
8 mm

Reverse Polarity Protection
Yes

Housing Material
Nickel-plated brass

Control Output
NPN NO

Frequency
500 Hz (max.)

Cable Length
2 meters

Output Type
Open collector

Short Circuit Protection
Yes

Operating Humidity
35% to 95% RH

Leakage Current
0.8 mA

Indicator
LED (Operation indicator)

AUTONICS PROXIMTY SWITCH,PRT18-8DO About

Jump on unbeatable instant savings with the AUTONICS Proximity Switch, PRT18-8DOa world-class sensor crafted for precision. Benefit from a price cut and secure a noble upgrade for your automation systems. Experience virtuoso-level performance with an 8 mm sensing distance, NPN NO open collector output, and rapid 500 Hz frequency. Designed with nickel-plated brass housing, LED indicator, and IP67 protection, this proximity switch ensures reliability in the harshest environments. Elevate your process with short circuit and reverse polarity protection. Seize optimum value now!

Versatile Application and Methodology

AUTONICS PROXIMITY SWITCH, PRT18-8DO excels on metallic or conductive surfaces, making it ideal for commercial automation, safety controls, and assembly lines. Its flush mount and robust nickel-plated brass construction deliver reliable results on diverse installation surfaces. The 2-meter cable and 3-wire configuration ensure easy connection. Suitable for use in factories, warehouses, and process automation environments, this sensor is your trusted partner for smooth, repeatable detection in any commercial or industrial context.

Packaging, Express Shipping, and Convenient Terms

Each AUTONICS PROXIMITY SWITCH, PRT18-8DO comes securely packaged for safe handling and shipment. We offer express shipping options from our FOB China port to ensure timely delivery. Payment terms are flexible and can be discussed per your requirements, including exchange arrangements. The asking price is competitive to deliver maximum value. We accommodate bulk, wholesale, and single-item orders to seamlessly fit your supply chain or procurement plan.

FAQs of AUTONICS PROXIMTY SWITCH,PRT18-8DO:

Q: How is the AUTONICS PROXIMITY SWITCH, PRT18-8DO typically used in commercial applications?

A: The PRT18-8DO is commonly implemented for object detection, position sensing, and control automation in manufacturing, conveyor belt systems, and quality assurance stations.

Q: What are the main benefits of using this proximity switch for industrial automation?

A: It delivers rapid response times, robust durability, and high reliabilityeven in challenging environments. Its IP67 rating ensures it withstands dust and water, making it perfect for consistent operation.

Q: Where can the AUTONICS PRT18-8DO be installed?

A: This proximity switch is suitable for installation on metallic or conductive surfaces, within control panels, machinery, automated lines, and various industrial environments.

Q: When should I consider upgrading to this proximity switch model?

A: Upgrade when you require higher precision in detection, enhanced protection against short circuits and reverse polarity, or a more resilient sensor for demanding operating conditions.

Q: What is the process for exchanging or returning this product if needed?

A: Please contact your supplier or trader to initiate an exchange. Review their specific policy for returns and ensure all packaging and included materials are intact for a hassle-free process.

Q: How does the payment procedure work and what shipping terms are available?

A: Payment can be arranged based on mutual agreement, such as advance payment or credit terms. Express shipping is available, and FOB China is the standard port for dispatch.
