OMRON PHOTOELECTRIC SWITCH, EE-SX772A

OMRON PHOTOELECTRIC SWITCH, EE-SX772A Specification

Circuit Type
NPN Output

Rated Voltage
5 to 24 VDC

Max. Current
50 mA

Mechanical Life
20 million operations min.

Number of Module
Single

Finish Type
Standard Molded

Response Time
1 ms max.

Protection Level
IP50

Automation Grade
Automatic

Temperature Range
-25C to +55C (with no condensation or icing)

Product Type
Photoelectric Switch

Insulation Resistance
100 M min. (at 500 VDC)

Contact Resistance
100 m max.

Max. Voltage
26.4 VDC

Operating Temperature
-25C to +55C

Size
13 x 30 x 10.8 mm (W x H x D)

Color
Black

Weight
Approx. 5g

Mounting Type
Panel Mount

Current Rating
50 mA max.

Supply Voltage
5 to 24 VDC

Application
Position detection, limit switch, automation systems

Lead Wire
Pre-wired (Standard Cable, approx. 1m)

Detection Slot Width
5 mm

RoHS Compliance
Yes

Indicator
Built-in Operation LED

UL Recognition
Yes

Sensing Method
Transmissive (Photointerrupter)

Short-circuit Protection
Yes

Operating Humidity
5% to 85% RH

Emitter Type
Infrared LED

Reverse Polarity Protection
Yes

Storage Temperature
-30C to +70C

Output Type
Open Collector

About OMRON PHOTOELECTRIC SWITCH, EE-SX772A

Featured for its extraordinary precision, the OMRON PHOTOELECTRIC SWITCH, EE-SX772A allows users to capitalise on reliable position detection in demanding automation environments. With a spectacular sensing method using a transmissive photointerrupter and a reduced detection slot width of 5 mm, it provides enviable accuracy. This switch operates on a supply voltage of 5 to 24 VDC, supports an open collector output, and ensures operational safety through short-circuit and reverse polarity protection. Rated for a mechanical life of 20 million operations, its automatic grade and robust construction deliver reduced downtime and enviable efficiency for any industrial application.

Versatile Applications & Installation

The OMRON PHOTOELECTRIC SWITCH, EE-SX772A delivers outstanding performance for automation systems, acting as a reliable position detector and limit switch in panel-mounted setups. Its sturdy build ensures operation in challenging environments like industrial assembly lines, packaging machinery, and material handling systems. Used as a critical sensing component, it excels on metallic, plastic, or composite surfaces, providing accurate and consistent feedback for control processes in a variety of places ranging from factories to warehouses.

Exceptional Supply Terms & Value

Benefit from the lowest price and competitive market value when ordering the EE-SX772A from leading suppliers, traders, or wholesalers in China. Payment terms are flexible, including options for advance payment and immediate delivery, ensuring your project faces no delays. Sample policies allow for cost-effective evaluation before full purchase, and supply ability remains steady to meet large-scale requirements. List prices are always kept transparent, ensuring the best value in every transaction.

FAQs of OMRON PHOTOELECTRIC SWITCH, EE-SX772A:

Q: How does the OMRON EE-SX772A Photoelectric Switch operate?

A: The OMRON EE-SX772A utilizes a transmissive photointerrupter, where an infrared LED emitter and detector are aligned across a 5 mm slot. When an object interrupts the light beam, the sensor detects the change and sends a signal through its open collector output.

Q: What environments is the EE-SX772A suitable for?

A: With an operating humidity of 5%% to 85%% RH and an operating temperature range of -25C to +55C, the EE-SX772A is ideal for various industrial environments, including automation systems, assembly lines, and material handling areas.

Q: Where can I use the EE-SX772A switch in automation?

A: This switch is best used on control panels for position detection and limit switch applications, especially in systems requiring fast response, dependable sensing, and robust protection measures.

Q: What is the process for ordering samples of the EE-SX772A?

A: To order a sample, contact your supplier or wholesaler. Most vendors offer sample policies, allowing you to evaluate the product at a reduced cost before committing to larger purchases.

Q: When should the EE-SX772A be used for maximum benefit?

A: Utilize the EE-SX772A when precise and reliable object detection is critical, particularly in fast-paced automation lines or equipment requiring frequent position monitoring and limit setting.

Q: Is there any benefit to the built-in operation LED on the EE-SX772A?

A: Yes, the built-in operation LED provides quick visual confirmation of the sensors status, helping troubleshoot malfunction scenarios and maximizing system uptime.
