AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-5DN

AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-5DN Specification

Cable Length
2 Meters

Signal Type
NPN Open Collector

IP Rating
IP67

Response Time
<2ms

Features
Reverse polarity protection, Surge protection, LED operation indicator

Wireless
No

Measurement Range
Sensing Distance: 5mm 10%

Power Consumption
Max. 15mA

Sensitivity
Adjustable not available (factory set)

Application
Industrial automation, material handling, conveyors

Sensor Type
Inductive

Mounting Type
Panel / flush mounting

Operating Temperature
-25C to +70C

Interface
Pre-wired, 3-wire DC

Product Type
Inductive Proximity Sensor

Material
PBT Plastic (Housing), Nickel-plated Brass (Sensing face)

Input
12-24V DC

Output
NPN Normally Open (NO)

Function
Object detection without physical contact

Usage
Automation equipment, position sensing, counting systems

Accuracy
10% of sensing distance

Resolution
High resolution for metal object detection

Voltage
12-24V DC

Weight
Approx. 70g

Housing Dimensions
17mm diameter, cylindrical type

Shock Resistance
500m/s2 (approx. 50G) for 3 times in each X, Y, Z direction

Control Output Current
Max. 200mA

Vibration Resistance
10-55Hz, 1.5mm amplitude

Control Output Voltage
Max. 30V DC (load)

LED Indicator
Red LED (Operation status)

Ambient Humidity
35-95% RH, non-condensing

About AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-5DN

Experience the eminent performance of the AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-5DN at an unbeatable price-Try Now and discover why this top-ranking sensor is the preferred choice in industrial automation. With remarkable accuracy (10% of sensing distance) and a robust build-IP67 housing, panel/flush mounting, and advanced reverse polarity/surge protection-this featured sensor ensures reliable detection without physical contact. The 5mm sensing distance, high resolution for metal object detection, and visible red LED indicator reinforce its supremacy. Elevate your automation systems with this industry-leading solution from China, available through trusted suppliers, traders, and wholesalers.

INDUSTRIAL APPLICATIONS & PERFORMANCE

AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-5DN is primarily used as a non-contact object detector in automation equipment, material handling, and counting systems. It is ideal for site applications such as conveyors and position sensing operations. This sensor features a durable PBT plastic housing, nickel-plated brass sensing face, and a prominent red LED operation indicator, ensuring reliability in challenging environments. Its robust construction allows for seamless industrial integration, delivering precise results and enduring performance.

DOMESTIC MARKET, SHIPPING & HANDOVER DETAILS

This remarkable proximity sensor serves the main domestic market with efficient packing & dispatch services directly from China. The FOB Port simplifies logistics and ensures smooth transaction exchanges when the product is handed over to your carrier. Ready samples are available to evaluate before large orders, bolstering buyer confidence. With streamlined operations, buyers can anticipate prompt delivery and minimal hassle, ensuring your project deadlines are met with consistency and integrity.

FAQ's of AUTONICS PROXIMITY SENSOR 12-24VDC, PSN17-5DN:

Q: How does the AUTONICS PSN17-5DN proximity sensor operate?

A: The AUTONICS PSN17-5DN operates by detecting metal objects within a 5mm range without physical contact, using its high-resolution inductive sensing technology and indicating operation status via a red LED.

Q: What benefits does the PSN17-5DN proximity sensor provide in automation systems?

A: This sensor enhances automation systems with precise metal detection, rapid response times under 2ms, and robust reliability due to its IP67 rating, shock/vibration resistance, and built-in surge/reverse polarity protection.

Q: Where is the AUTONICS PSN17-5DN commonly used?

A: The sensor is widely used in industrial environments such as automation, material handling, conveyor systems, and counting applications where accurate, contact-free object detection is essential.

Q: What is the process for obtaining a sample of this proximity sensor?

A: Samples for the AUTONICS PSN17-5DN are available on request. After confirming your requirements, efficient packing & dispatch will ensure your sample is handed over for delivery or exchange at the designated FOB port.

Q: When should I use this sensor for position sensing?

A: Use the PSN17-5DN when contactless, reliable, and high-precision detection of metal objects is required-especially in environments with dust, moisture, or demanding operational conditions.
