AUTONICS, AREA SENSOR, BWPK25-05P

AUTONICS, AREA SENSOR, BWPK25-05P Specification

Features
Multi-point detection, LED indicator, Overcurrent Protection, Reverse Polarity Protection

IP Rating
IP50

Wireless
No

Mounting Type
Screw Mounting

Application
Area Sensor

Measurement Range
500 mm; Sensing Height: 266 mm

Power Consumption
Max. 2.6W

Sensitivity
High (capable of detecting small objects)

Sensor Type
Area Sensor

Interface
Cable

Response Time
10 ms or less

Signal Type
Digital

Operating Temperature
-10C to +55C (non-freezing)

Cable Length
2m (pre-wired)

Product Type
BWPK25-05P

Input
12-24V DC

Output
PNP Open Collector

Function
Detection of objects within specified area range

Usage
Industrial safety, automation, area detection

Accuracy
10% of object position

Resolution
25 mm (beam pitch)

Voltage
12-24V DC 10%

Weight
Approx. 510g

Max Load Current
100 mA

Max Load Voltage
30V DC

Minimum Detectable Object Size
30 mm diameter

Protection Circuit
Short-circuit protection, Overload protection

Storage Temperature
-25C to +70C

Isolation Resistance
20 M (minimum at 500V DC test)

Indicator
Operation LED (Red), Stability LED (Green)

Shock Resistance
500 m/s (for 3 times in X, Y, Z directions)

Light Source
Infrared LED (940 nm)

Ambient Humidity
3585% RH

Additional Product Specifications

Max Detection Distance
5 m (using standard target)

Body Color
Black

Vibration Resistance
10-55 Hz, amplitude 1.5 mm (for 2 hrs in X, Y, Z directions)

Output Current
Max. 100 mA

Number of Beam Channels
25

About AUTONICS, AREA SENSOR, BWPK25-05P

The AUTONICS AREA SENSOR BWPK25-05P is a must-have solution for world-class industrial safety and automation. Featuring a masterful 25 beam channel design, it uses a lofty infrared LED (940 nm) to achieve precise detection up to 5 meters. Capitalise on instant checkout with robust output and advanced protection circuits, ensuring seamless operation even in rigorous conditions. Boasting a compact black body and high vibration and shock resistance, it delivers exceptional reliability. Designed for high-accuracy area detection, this sensor sets a benchmark with its multi-point detection and superior sensitivity, making it ideal for demanding applications.

Optimised Usage & Applications

The AUTONICS AREA SENSOR BWPK25-05P is suitable for industrial safety, automation, and area detection on production floors, conveyors, and warehousing surfaces. It excels in detecting objects with a minimum diameter of just 30 mm, making it perfect for high-precision applications. With multi-point detection, robust LED indicators, and advanced protection features, this sensor enhances operational efficiency across diverse machine types and environments.

Supply Ability & Export Expertise

Order completion is prompt with premium packaging ensuring safe transportation. The AUTONICS AREA SENSOR BWPK25-05P is supplied efficiently to major export markets including China and beyond. Secure cable mounting and a pre-wired interface simplify installation. Wholesalers, suppliers, and traders benefit from reliable delivery and comprehensive packaging details tailored to guarantee product integrity throughout shipment.

FAQs of AUTONICS, AREA SENSOR, BWPK25-05P:

Q: How does the AUTONICS BWPK25-05P area sensor benefit industrial automation?

A: The sensor enhances automation by providing accurate, multi-point object detection over a wide area, improving safety and efficiency in industrial environments.

Q: What are the main usage scenarios for the BWPK25-05P?

A: It is commonly used for industrial safety, area monitoring, conveyor systems, and automated warehousing, where precise object presence detection is essential.

Q: When should I choose the BWPK25-05P for my application?

A: Select this sensor when you require high-speed, reliable detection of small objects (down to 30 mm), robust protection circuits, and superior performance in harsh or vibrating conditions.

Q: Where can the BWPK25-05P be installed?

A: It can be screw-mounted onto various machine surfaces or safety gates in industrial sites, factories, and warehouses for area detection purposes.

Q: What is the process for installing the AUTONICS AREA SENSOR BWPK25-05P?

A: Installation involves secure screw mounting and connecting its pre-wired cable interface. The process is straightforward, with LED indicators guiding operational setup.

Q: How does multi-point detection improve operational reliability?

A: Multi-point detection allows the sensor to track multiple objects simultaneously, reducing the risk of missed detections and enhancing process accuracy.
