PEPPERL FUCHS ULTRASONIC SENSOR, UC6000-30GM-IUR2-V15

PEPPERL FUCHS ULTRASONIC SENSOR, UC6000-30GM-IUR2-V15 Specification

IP Rating
IP67

Power Consumption
2.2 W Watt (W)

Operating Temperature
-25...+70 C Celsius (oC)

Signal Type
Analog and Digital (Push-Pull)

Wireless
No

Mounting Type
Threaded barrel, M30 x 1.5

Measurement Range
120...6000 mm (adjustable)

Application
Industrial Automation, Process Control, Logistics, Packaging

Sensor Type
Ultrasonic Proximity Sensor

Interface
M12 5-pin connection

Sensitivity
Adjustable sensitivity via teach-in

Features
Short blind zone, IO-Link support, LED indication, Synchronisation/Multiplex capability

Product Type
Ultrasonic Sensor

Material
Metal Housing (Brass, nickel-plated)

Input
10...30 V DC

Output
Analog 4...20 mA / 0...10 V, 1 Push-Pull (PNP/NPN) Switching Output

Function
Distance Measurement, Object Detection

Usage
Positioning, level detection, presence detection

Accuracy
1% %

Resolution
0.18 mm

Voltage
10...30 V DC Volt (v)

Weight
Approx. 170 g Grams (g)

Blind Zone
0...120 mm

Adjustment
Teach-in via button or external input

Number of Teach-In Points
2

Protection Circuit
Reverse polarity, surge, and short-circuit protection

Max Output Current
< 150 mA (switching output)

Repetition Accuracy
0.15%

Transducer Frequency
80 kHz

Hysteresis
20 mm typ.

Connection Type
M12 plug, 5-pin

Enclosure Material
Brass, nickel-plated; plastic parts: PBT, TPU; ultrasonic transducer: epoxy resin with glass

Thread Size
M30 x 1.5

PEPPERL FUCHS ULTRASONIC SENSOR, UC6000-30GM-IUR2-V15 Trade Information

Minimum Order Quantity
30 Number

Supply Ability
1000 Per Month

Delivery Time
7 Days

About PEPPERL FUCHS ULTRASONIC SENSOR, UC6000-30GM-IUR2-V15

Jump on the opportunity to elevate your automation with the PEPPERL FUCHS ULTRASONIC SENSOR, UC6000-30GM-IUR2-V15. Preeminent in reliability, this gilt-edged sensor offers commanding performance for positioning, level, and presence detection. With a limited-time supply, its robust brass housing and IP67 rating ensure longevity in industrial, logistics, and packaging processes. Explore precision with adjustable teach-in points, high accuracy (1%), and versatile analog/digital outputs. Designed for seamless integration through its M12 plug, this sensor sets a benchmark for smart measurement and object detection.

Versatile Functions and Seamless Operation

The PEPPERL FUCHS UC6000-30GM-IUR2-V15 excels in various applications such as process control, industrial automation, logistics, and packaging. Features like adjustable sensitivity, multiplex capability, and IO-Link support significantly expand its usability. For effective operation, mount securely using the threaded barrel and initiate the teach-in process via button or external input. Its short blind zone and LED indication further streamline setup and detection.

Availability, Sample Requests, and Export Markets

Sample availability for the PEPPERL FUCHS UC6000-30GM-IUR2-V15 supports evaluation and customization. Main export markets include regions across China. The current supply ability accommodates bulk and wholesale orders, subject to list price and freight terms. For detailed asking price quotes, contact the supplier directly to discuss arrangements, including international shipments, tailored to your operational requirements.

FAQs of PEPPERL FUCHS ULTRASONIC SENSOR, UC6000-30GM-IUR2-V15:

Q: How does the teach-in adjustment process work for this ultrasonic sensor?

A: You can adjust the sensor either via the built-in button or an external input. The teach-in process allows fine-tuning of sensitivity and measurement points, enabling flexible setup and optimization for specific detection needs.

Q: What applications are best suited for the UC6000-30GM-IUR2-V15 sensor?

A: This sensor is ideal for industrial automation, process control, logistics, and packaging, where accurate distance measurement, object positioning, and presence detection are crucial.

Q: What are the main features that enhance its performance and reliability?

A: Notable features include a short blind zone, IO-Link support, multiplex capability, adjustable sensitivity, and robust protection circuits. The brass, nickel-plated enclosure ensures durability, while the high accuracy and resolution guarantee dependable results.

Q: Where can I request a sample or obtain pricing information?

A: Samples and pricing details, including list prices and freight charges, are available directly from the supplier, trader, or wholesaler in China. Reach out to discuss your project and supply needs.

Q: What benefits does the IP67 rating offer for industrial environments?

A: An IP67 rating ensures the sensor is protected against dust and temporary water immersion, providing dependable operation in harsh and demanding environments.
