TELEMECANIQUE , LIMIT SWITCH, XCKM2023LC

TELEMECANIQUE , LIMIT SWITCH, XCKM2023LC Specification

Circuit Type
Snap Acting

Automation Grade
Industrial

Number of Module
Single

Rated Voltage
240V AC / 250V DC

Protection Level
IP66

Mechanical Life
15,000,000 operations

Temperature Range
-25C to +70C

Response Time
20 ms

Max. Current
Ith: 10A

Finish Type
Protective Coated

Product Type
Limit Switch

Material
Plastic and Metal

Insulation Resistance
100 M (at 500VDC)

Contact Resistance
25 m

Max. Voltage
Ui: 500V AC/DC

Operating Temperature
-25C to +70C

Stoke
10 mm (Plunger travel)

Size
31 x 64 x 30 mm (approx)

Color
Blue and Black

Weight
Approx. 160g

Mounting Type
Panel Mounting / Surface Mount

Current Rating
6A (AC-15), 0.25A (DC-13)

No Of Poles
1 NO + 1 NC

Enclosure Material
Zamak Body and Head

Vibration Resistance
10-55 Hz, amplitude 1 mm

Electrical Life
5,000,000 operations

Terminal Type
Screw clamp terminals

Ambient Humidity
35% to 95% RH

Head Type
Plunger, Spring Return

Standards
IEC 60947-5-1, EN 60947-5-1

Actuator Type
Top Plunger

Shock Resistance
IEC 68-2-27

About TELEMECANIQUE , LIMIT SWITCH, XCKM2023LC

Discover the ultimate in switching technology with the TELEMECANIQUE LIMIT SWITCH XCKM2023LC. This rarefied industrial component boasts a customizable design and has garnered favorable reviews for its reliability and unassailable performance. Built to IEC 60947-5-1 standards with a robust Zamak body and head, this limit switch provides 15,000,000 mechanical operations and a 5,000,000 electrical life. Personalise your automation setup with its dual mounting types and versatile terminal connections. The IP66 protection, wide operating temperature range, and snap acting circuit type ensure dependable, long-lasting performance in demanding environments.

Key Features & Versatile Usage

The TELEMECANIQUE LIMIT SWITCH XCKM2023LC is engineered for industrial-grade applications, offering extra features such as a durable plunger head, spring return, and high vibration and shock resistance. Equipped with screw clamp terminals for secure wiring, users can easily install this switch on panels or surfaces according to their requirements. Its snap acting mechanism ensures rapid response, making it ideal for precision automation, machinery interlocking, and safety circuits.

Supply Ability and Logistics Excellence

TELEMECANIQUE LIMIT SWITCH XCKM2023LC is available at a competitive sale price with prompt packing & dispatch from China to various export markets. Traders and wholesalers can count on reliable logistics, ensuring timely delivery. The product is securely packed to prevent damage during transit. Samples are available upon request, facilitating evaluation prior to larger orders. The company's efficient supply chain covers main export regions with the ability to fulfill substantial demand consistently.

FAQ's of TELEMECANIQUE , LIMIT SWITCH, XCKM2023LC:

Q: How can I install the TELEMECANIQUE LIMIT SWITCH XCKM2023LC in my setup?

A: You can mount the XCKM2023LC using either panel or surface mounting. Its screw clamp terminals allow for secure and flexible wiring, making installation straightforward for various industrial configurations.

Q: What are the key benefits of using this limit switch in automation systems?

A: The TELEMECANIQUE LIMIT SWITCH XCKM2023LC offers high mechanical and electrical life, rapid response time, robust protection against dust and moisture (IP66 rating), and reliable operation under challenging temperatures, ensuring minimized downtime and enhanced system safety.

Q: Where is the TELEMECANIQUE LIMIT SWITCH XCKM2023LC commonly used?

A: This switch is primarily used in industrial automation, machinery safety circuits, conveyor systems, and interlocking applications requiring precision monitoring and control.

Q: What is the process to request a sample before making a bulk purchase?

A: To request a sample, you may contact the supplier, trader, or wholesaler directly. Samples are available and can be dispatched promptly for evaluation prior to placing larger orders.

Q: What makes the XCKM2023LC stand out from other limit switches?

A: Its rare combination of extensive mechanical life, customizable mounting options, high vibration and shock resistance, and favorable reviews for reliability sets it apart as an unassailable choice in industrial environments.
