SCHNEIDER SMART RELAY, SR2-B121BD

SCHNEIDER SMART RELAY, SR2-B121BD Specification

Mechanical Life
10,000,000 operations

Ambient Temperature
-20C to +55C

Power Consumption
<2 W

Working Temperature
-20C to +55C

Contact Material
AgSnO2

Coil Power
<2 W

Dielectiric Strength
2,500 V AC, 50/60 Hz for 1 min

Contact Form
2 NO + 2 NC

Contact Resistance
<100 m

Coil Voltage
12 V DC

Protect Feature
Short circuit and overload protection

Product Type
Smart Relay

Insulation Resistance
>500 M at 500 V DC

Theory
Microcontroller based logic relay

Usage
Industrial Automation, Control Panels

Contact Load
8 A @ 250 V AC

Operate Time
Typically <10 ms

Terminal Type
Screw terminals

Rated Voltage
12 V DC

Supply Terminal
Top and bottom supply terminals

Size
Compact

Color
Grey

Dimension (L*W*H)
71.2 mm x 90 mm x 61.6 mm

Weight
Approximately 0.23 kg

Rated Frequency
50/60 Hz

Max Switching Voltage
250 V AC

Number of Outputs
4 relay outputs

Response Time
<20 ms

Ingress Protection
IP20

Display
LCD display, monochrome

Mounting Type
DIN Rail

Model
SR2-B121BD

Series
Zelio Logic

Programming Interface
Programming via USB or dedicated cable

Number of Inputs
8 digital inputs

About SCHNEIDER SMART RELAY, SR2-B121BD

Experience crackerjack performance with the SCHNEIDER SMART RELAY, SR2-B121BD-an industrial automation gem designed for kingly efficiency. Featuring 8 digital inputs, 4 relay outputs, and a glorious monochrome LCD display, this compact device supports programming via USB or dedicated cable. Mount it easily on DIN Rail and enjoy robust short circuit and overload protection. With a response time of less than 20 ms and a power consumption under 2 W, this in-demand relay is perfect for modern control panels. Add to Cart and order today for assured reliability!

Versatile Application Scope of SCHNEIDER SMART RELAY

The SCHNEIDER SMART RELAY, SR2-B121BD, excels in various industrial and commercial automation settings. Its application surface ranges from complex control panels to streamlined automation solutions. Ideal for industries that demand precision and reliability, this model finds use in assembly lines, process management, and machine control. Additionally, its compact design allows integration into limited spaces while retaining optimal performance. The relay's adaptability ensures that it complements a wide range of operational tasks, making it suitable for diverse and dynamic environments.

Sample Policy, Packaging, and Supply Details

Sample policies for the SCHNEIDER SMART RELAY, SR2-B121BD, require a nominal charge based on the proposal amount and client specifications. We ensure premium packaging to protect the relay during transit and delivery. Robust, shock-resistant materials safeguard the unit's integrity. Supply ability is steady, supported by reliable sourcing channels to fulfill both bulk and urgent orders. Our focus is customer satisfaction through meticulous handling, competitive proposal terms, and consistent replenishment as per your automation requirements.

FAQ's of SCHNEIDER SMART RELAY, SR2-B121BD:

Q: How do you program the SCHNEIDER SMART RELAY SR2-B121BD?

A: Programming the SR2-B121BD is straightforward. You can use either a USB interface or a dedicated programming cable to connect the relay to your computer. The device also features a user-friendly monochrome LCD display that facilitates setup and monitoring during programming.

Q: What are the main applications for this smart relay?

A: The SCHNEIDER SMART RELAY SR2-B121BD is primarily designed for industrial automation and control panels. It suits a variety of uses including machine operation management, process control, and integration into electrical systems requiring reliable logic relay controls.

Q: When should you consider using the SR2-B121BD relay?

A: You should consider using this relay when you require a compact, efficient, and reliable logic relay with fast response times in your automation setup. It's ideal for environments needing frequent switching and programmable operations.

Q: Where is the recommended installation area for the SR2-B121BD?

A: The SR2-B121BD is designed for DIN Rail mounting within industrial control panels. Its compact build makes it ideal for spaces where size is a constraint while still demanding robust control capabilities.

Q: What benefits does the SCHNEIDER SR2-B121BD offer in industrial environments?

A: Its benefits include kingly reliability, low power consumption, high mechanical life of up to 10,000,000 operations, quick response, and adaptable programming options, all of which contribute to improved operational efficiency and reduced downtime.

Q: How does the SCHNEIDER SMART RELAY ensure protection against electrical faults?

A: The relay is equipped with short circuit and overload protection mechanisms. It also features high insulation resistance and dielectric strength, offering safe operation even in demanding environments.
