PEPPERL FUCHS ULTRASONIC SENSOR, UC2000-30GM-IUR2-V15

PEPPERL FUCHS ULTRASONIC SENSOR, UC2000-30GM-IUR2-V15 Specification

IP Rating
IP67

Signal Type
Analog and Switching Output

Sensor Type
Diffuse mode sensor with adjustable detection range

Power Consumption
70 mA

Mounting Type
Threaded barrel, M30 x 1.5

Sensitivity
Adjustable sensitivity

Application
Compatible with all Pepperl+Fuchs ultrasonic evaluation units; object detection and distance measurement

Wireless
No

Features
Teach-in function, LED status display, reverse polarity protection, short-circuit protection

Response Time
< 320 ms

Interface
V15 connector, 5-pin

Cable Length
V15 connector (Cable not integrated)

Operating Temperature
-25 C to 70 C

Measurement Range
120 mm to 2000 mm

Product Type
Ultrasonic Sensor

Material
Nickel-plated brass

Input
10-30 V DC

Output
4-20 mA, 0-10 V, switchable

Function
Object detection, level monitoring

Usage
Industrial Automation

Accuracy
1% of final value

Resolution
0.18 mm

Voltage
10-30 V DC

Weight
Approx. 90 g

Transducer Frequency
Approx. 120 kHz

Max Switching Frequency
3 Hz

Protection
Overload and short-circuit protection, reverse polarity protection

Approval/Conformity
CE, cULus, EAC

Light Indicator
Yellow/green LED for status and alignment

Enclosure Material
Nickel-plated brass, plastic

Clamp Torque
50 Nm

Connection Type
Connector M12 x 1, 5-pin

Size/Dimensions
Diameter 30 mm, length 91 mm

Temperature Drift
0.17%/K

Repeat Accuracy
0.15% of full scale

PEPPERL FUCHS ULTRASONIC SENSOR, UC2000-30GM-IUR2-V15 About

Spotlight your operations with the PEPPERL FUCHS ULTRASONIC SENSOR, UC2000-30GM-IUR2-V15-a rarefied choice in industrial automation. Crafted with imposing nickel-plated brass and robust plastic, this sensor is designed for redoubtable reliability in demanding settings. Boasting a fresh 120 mm to 2000 mm measurement range, it delivers special precision with 0.18 mm resolution and 1% accuracy. Advanced features such as overload, reverse polarity protection, and LED status indicators assure seamless integration. Ideal for object detection and level monitoring, this sensor stands out for its trustworthiness and rare performance.

Application Areas and Utility of the UC2000-30GM-IUR2-V15 Sensor

The PEPPERL FUCHS ULTRASONIC SENSOR, UC2000-30GM-IUR2-V15 is expertly suited for industrial automation, providing dynamic object detection and accurate level monitoring. This diffuse mode sensor, compatible with all Pepperl+Fuchs ultrasonic evaluation units, is designed for use in both demanding and precise environments. Its adjustable detection range and multiple output options make it versatile for numerous application areas, ensuring enhanced operational efficiency and reliable usage across various industrial domains.

Domestic and Export Supply of the UC2000-30GM-IUR2-V15 Sensor

This sensor is regularly handed over across China's main domestic market and supplied to clients with robust efficiency. Our supply ability ensures consistent product availability for traders, wholesalers, and suppliers. Furthermore, significant export volumes are routinely handed over to international markets, meeting diverse requirements and maintaining a steady pipeline of fresh deliveries worldwide. This supports global automation projects, strengthening both domestic and export sales channels with timely handovers.

FAQ's of PEPPERL FUCHS ULTRASONIC SENSOR, UC2000-30GM-IUR2-V15:

Q: How does the UC2000-30GM-IUR2-V15 sensor benefit industrial automation applications?

A: The UC2000-30GM-IUR2-V15 sensor delivers high accuracy object detection and level monitoring, ensuring precise control and enhanced efficiency in automated processes. Its robust construction and protective features contribute to reliable performance even in demanding environments.

Q: What process should I follow for integrating this sensor with existing evaluation units?

A: To integrate the sensor, connect it using the 5-pin M12 V15 connector to compatible Pepperl+Fuchs ultrasonic evaluation units, utilize the teach-in function for setup, and adjust sensitivity and detection range to align with your application requirements.

Q: Where is the UC2000-30GM-IUR2-V15 sensor commonly used?

A: This sensor is commonly used in factories, warehouses, and production lines where precise distance measurement and object detection are critical for maintaining high levels of automation and safety.

Q: When is the sensor's teach-in function especially useful?

A: The teach-in function becomes particularly valuable during initial installation or when altering monitoring parameters, allowing quick adaptation to new operational settings and object types within the automation process.

Q: How can I confirm the sensor's operational status?

A: You can check the yellow/green LED indicators on the sensor for status and alignment, providing instant visual feedback on proper functioning and alignment without the need for additional equipment.
