PEPPERL+FUCHS PROXIMITY SENSOR , NBB5-18GM50-E2-V1

PEPPERL+FUCHS PROXIMITY SENSOR , NBB5-18GM50-E2-V1 Specification

IP Rating
IP67

Measurement Range
5 mm (Sn - Nominal Sensing Distance)

Power Consumption
15 mA (No Load)

Features
Short-circuit protected, Reverse polarity protected, LED status indicator

Interface
M12 Connector, 4-pin

Mounting Type
Flush (Embeddable)

Response Time
1 ms

Wireless
No

Application
Factory Automation, Assembly Lines, Conveyors, Machine Tools

Operating Temperature
-25 C to +70 C

Cable Length
Connector type (No fixed cable, M12 Connector)

Sensor Type
Inductive

Sensitivity
Factory Set

Signal Type
Digital

Product Type
Inductive Proximity Sensor

Material
Metal Housing (Brass), Nickel-plated

Input
DC 3-wire

Output
PNP, Normally Open (NO)

Function
Object Detection/Non-contact Sensing

Usage
Detection of metallic objects

Accuracy
High

Resolution
Discrete On/Off Output

Voltage
10-30 V DC

Weight
Approx. 65 g

Housing Length
50 mm

Protection Type
Short-circuit and overload protected

Housing Size
M18 x 1 (Threaded Cylinder)

EMC Compliance
EN 60947-5-2

Switching Frequency
800 Hz

Operating Voltage Drop
2 V

Approvals/Markings
CE, cULus

Repeat Accuracy
5% of Sn

Output Current
Max. 200 mA

Shock/Vibration Resistance
IEC 60068-2-6/IEC 60068-2-27

Active Surface Material
Plastic (PBT)

Indication
Yellow LED

PEPPERL+FUCHS PROXIMITY SENSOR , NBB5-18GM50-E2-V1 About

Unlock prime detection performance with the PEPPERL+FUCHS PROXIMITY SENSOR NBB5-18GM50-E2-V1, a top-drawer inductive sensor ideal for factory automation and machine tools. Take advantage of astonishing affordability with the lowest price available for a limited time! This PNP, normally open sensor ensures high accuracy and reliability, offering a remarkable response time of 1 ms and robust protection through its metal, nickel-plated housing. Enjoy short-circuit and overload resilience, superb repeat accuracy, and clear indication via a yellow LED. Secure this premium German-engineered sensor while stocks last!

Versatile Use and Reliable Application

The PEPPERL+FUCHS NBB5-18GM50-E2-V1 Proximity Sensor is designed for industrial use, particularly within factory automation, assembly lines, and conveyor systems. Its discrete on/off sensing is perfect for detecting metallic objects in demanding environments. Suitable for repetitive and rigorous industrial operations, this sensor provides non-contact object detection with high accuracy, making it an excellent choice for enhancing productivity and maintaining efficient workflow in modern plants.

Payments, Certifications & Strong Logistics

With flexible payment terms and prompt order processing, acquiring the NBB5-18GM50-E2-V1 is streamlined for domestic and international buyers. Certified with CE and cULus markings, this sensor adheres to stringent quality standards. Shipped from Germany's prime logistics hubs for fast delivery, our list price ensures exceptional value. Whether for domestic markets or global enterprises, our comprehensive logistics network guarantees timely and secure shipping, reinforcing your business's competitive advantage.

FAQ's of PEPPERL+FUCHS PROXIMITY SENSOR , NBB5-18GM50-E2-V1:

Q: How does the PEPPERL+FUCHS NBB5-18GM50-E2-V1 proximity sensor operate?

A: This inductive sensor operates by emitting an electromagnetic field to detect nearby metallic objects without physical contact, delivering a digital on/off signal for factory automation tasks.

Q: What are the main application areas of this sensor?

A: It is primarily used in factory automation, assembly line monitoring, conveyors, and machine tools, where reliable and precise object detection is required.

Q: Where can this sensor be installed in a plant?

A: The flush-mountable, M18 threaded cylinder design allows installation on machinery, conveyor frames, and robotic assemblies, offering flexibility across industrial environments.

Q: What are the key benefits of using this PEPPERL+FUCHS sensor?

A: Users benefit from its robust construction, short-circuit and overload protection, quick response time, and high repeat accuracy, ensuring dependable performance and minimal maintenance.

Q: How is product delivery and payment handled for this sensor?

A: Orders can be placed with accommodating payment options. Shipping is managed through efficient logistics partners in Germany, with delivery to both domestic and international locations.
