PEPPERL FUCHS PHOTOELECTRIC SENSOR,OBT500-18GM60-E5

PEPPERL FUCHS PHOTOELECTRIC SENSOR,OBT500-18GM60-E5 Specification

Features
Short-Circuit Protection, Polarity Reversal Protection, LED Status Indicator

Cable Length
2 m, PUR Cable

Wireless
No

Mounting Type
Threaded, M18 x 1

Sensor Type
Diffuse Sensor

Power Consumption
Max. 30 mA (No Load)

Signal Type
Digital

Sensitivity
Adjustable

Measurement Range
0-500 mm

Response Time
< 1 ms

Operating Temperature
-25C to +55C

Application
Industrial Automation, Packaging, Conveyor Systems

Interface
3-Wire System

IP Rating
IP67

Product Type
Photoelectric Sensor

Material
Nickel-Plated Brass Housing

Input
10-30 V DC

Output
PNP, NO/NC

Function
Diffuse Mode Sensor

Usage
Object Detection

Accuracy
High

Resolution
Standard

Voltage
10-30 V DC

Weight
Approx. 80 g

Shock Resistance
30 g (11 ms) per EN 60068-2-27

Light Source
LED, Red Light

Ambient Light Limit
50000 Lux

Protection Class
III (EN 61140)

Sensing Distance Adjustment
Potentiometer

Switching Frequency
500 Hz

Vibration Resistance
10-55 Hz, 0.5 mm amplitude per EN 60068-2-6

Housing Diameter
18 mm

Connection Type
Cable, 3-Pin

EMC Standards
EN 60947-5-2

Max Load Current
100 mA

Repeat Accuracy
< 0.5 mm

PEPPERL FUCHS PHOTOELECTRIC SENSOR,OBT500-18GM60-E5 About

In demand and trending within the industrial automation market, the PEPPERL FUCHS PHOTOELECTRIC SENSOR, OBT500-18GM60-E5 stands as a monumental solution for object detection. This heroic device incorporates an advanced red LED light source, a sensing distance adjustable via potentiometer up to 500 mm, and inestimable repeat accuracy under 0.5 mm. Housed in robust nickel-plated brass and meeting rigorous EMC standards, it offers superior shock and vibration resistance. The sensor's inestimable advantages and short response time make it an indispensable asset for applications such as packaging and conveyor systems.

Unmatched Versatility and Robustness

The PEPPERL FUCHS PHOTOELECTRIC SENSOR, OBT500-18GM60-E5 is suitable for diverse industrial settings, from packaging to complex conveyor systems. Special features such as IP67 protection, LED status indicators, and easy sensing distance adjustment set it apart. Its primary competitive advantages include monumental high accuracy, heroic reliability, and inestimable longevity, ensuring dependable object detection in demanding environments. The sensor's robust housing and advanced EMC compliance secure optimal performance even in harsh conditions.

Domestic Market Availability and Fast Delivery

Our offer for the PEPPERL FUCHS PHOTOELECTRIC SENSOR extends across the main domestic markets in India and is available for rapid dispatch. Customers enjoy sale price benefits during promotional periods, and we provide quick dispatch for urgent orders. Sample requests are accommodated for product evaluation, and each unit is safely packaged to prevent damage during drop-off. As a trusted supplier, trader, and wholesaler, we ensure every order meets the highest standards before it reaches you.

FAQ's of PEPPERL FUCHS PHOTOELECTRIC SENSOR,OBT500-18GM60-E5:

Q: How does the PEPPERL FUCHS PHOTOELECTRIC SENSOR adjust its sensing distance?

A: The OBT500-18GM60-E5 sensor uses a potentiometer for easy and precise adjustment of its sensing distance, allowing users to fine-tune detection up to 500 mm as needed for different applications.

Q: What are the main benefits of using this sensor in industrial automation?

A: This sensor offers high repeat accuracy, fast response time, and reliable protection even in demanding environments, making it invaluable for ensuring efficient and accurate object detection in automated processes.

Q: Where can this sensor be effectively deployed?

A: The device is ideal for use in packaging lines, conveyor systems, and various industrial automation setups requiring reliable object detection and robust environmental resistance.

Q: What unique features distinguish this product from others in the market?

A: Key features include a nickel-plated brass housing, adjustable sensitivity, protection against short circuits and polarity reversal, and compliance with global EMC and safety standards, offering durability and consistent performance.

Q: How is the sensor packaged and delivered to buyers?

A: Each sensor is securely boxed to prevent damage, with quick dispatch available for prompt delivery. Sample units can also be requested, and sale prices may apply during promotions to offer added value.
