PEPPERL & FUCHS PHOTOELECTRIC SENSOR,OBT200-18GM60-E5-V1

PEPPERL & FUCHS PHOTOELECTRIC SENSOR,OBT200-18GM60-E5-V1 Specification

Operating Temperature
-25C to +55C

Mounting Type
Threaded barrel, M18

Application
Industrial automation, Packaging, Material handling

Response Time
1 ms

Interface
V1 M12 connector, 4-pin

IP Rating
IP67

Wireless
No

Signal Type
Digital (PNP output)

Sensor Type
Optical sensor, Diffuse reflection

Features
Short-circuit protection, Reverse polarity protection, LED status indicator

Measurement Range
10...200 mm adjustable

Sensitivity
Adjustable

Cable Length
No cable (connector version)

Power Consumption
35 mA

Product Type
Photoelectric Sensor

Material
Metal housing, Plastic components

Input
10-30 V DC

Output
PNP, NO (Normally Open)

Function
Diffuse mode sensor

Usage
Object detection, Position monitoring

Accuracy
High accuracy switching

Resolution
Standard resolution

Voltage
10-30 V DC

Weight
Approx. 90 g

Connection Type
Plug, M12 x 1

Alignment Aid
Light spot visible

Standards Compliance
IEC 60947-5-2

Adjustment Type
Potentiometer, 270

Design
Cylindrical, barrel type

Maximum Switching Capacity
100 mA

Degree of protection
IP67 (IEC 60529)

Light Source
LED, red light (660 nm)

Protection Class
II, rated isolation voltage > 50 V

Control Output Type
PNP (single output, NO)

Housing Thread
M18 x 1

Ambient Light Immunity
10,000 lux

Switching Frequency
500 Hz

About PEPPERL & FUCHS PHOTOELECTRIC SENSOR,OBT200-18GM60-E5-V1

Experience the crowning achievement in photoelectric sensing with the PEPPERL & FUCHS PHOTOELECTRIC SENSOR, OBT200-18GM60-E5-V1. This acclaimed sensor boasts matchless performance, earning favorable reviews for its resplendent accuracy and robust industrial design. Featuring a fresh LED light source with superior ambient light immunity, it delivers high switching frequency for reliable object detection and position monitoring. Its adjustable sensitivity and potent metal housing ensure versatility and longevity in demanding applications. Backed by IEC compliance and comprehensive protection features, it stands as a peerless choice for modern automation needs.

Versatile Application Areas and Advanced Features

Ideal for industrial automation, packaging, and material handling, the PEPPERL & FUCHS OBT200-18GM60-E5-V1 offers specialized functions such as diffuse mode sensing and high accuracy switching. Its visible light spot aids alignment while the adjustable detection range and sensitivity enhance operational flexibility. With short-circuit protection, reverse polarity protection, and a robust IP67-rated housing, this sensor is engineered for reliably seamless integration into varied industrial machines and assemblies.

Certifications, Market Reach, and Sample Terms

Complying with IEC 60947-5-2 standards, this photoelectric sensor meets stringent quality benchmarks for global acceptance. The main domestic market includes Germany and Europe, with transport services available for international consignments. Sample policies are flexible, with samples available upon outlay agreement or specific asking price discussions. Buyers can expect a straightforward order process and robust after-sales support, facilitating effortless procurement and deployment.

FAQ's of PEPPERL & FUCHS PHOTOELECTRIC SENSOR,OBT200-18GM60-E5-V1:

Q: How does the OBT200-18GM60-E5-V1 photoelectric sensor aid in object detection?

A: The sensor uses a red LED light source and diffuse reflection technology to detect objects with high accuracy, making it ideal for position monitoring and automation.

Q: What are the main benefits of choosing this sensor for industrial applications?

A: Its matchless precision, favorable reviews from industrial users, and uncompromising protection features ensure reliable operation even in harsh environments, minimizing downtime and enhancing productivity.

Q: Where can the PEPPERL & FUCHS OBT200-18GM60-E5-V1 be installed?

A: With an IP67 rating and sturdy cylindrical metal housing, it is suitable for use in packaging, material handling, and a broad range of industrial automation systems.

Q: What certifications does this sensor meet?

A: It complies with IEC 60947-5-2, signifying adherence to international electrical safety and switching device standards, ensuring safe and reliable performance.

Q: How adjustable is the sensor's detection range and sensitivity?

A: Users can conveniently modify the sensing range (10-200 mm) and sensitivity using an easy-to-access 270 potentiometer, catering to diverse application needs.

Q: What is the process for obtaining a sample of this sensor?

A: Samples can be arranged based on an agreed outlay or specific asking price, with prompt transport options available for domestic and international clients.
