PEPPERL +FUCHS PHOTOELECTRIC SENSOR,NBN4-12GM50-E2,NBN4-12GM60-A2-V1

PEPPERL +FUCHS PHOTOELECTRIC SENSOR,NBN4-12GM50-E2,NBN4-12GM60-A2-V1 Specification

Sensor Type
Inductive Proximity Sensor

Interface
3-wire, M12 Connector or Prewired Cable

Cable Length
2 m (cable version) or M12 connector, model dependent

Signal Type
Digital

Measurement Range
0...4 mm (sensing distance)

Response Time
< 1 ms

Sensitivity
Adjustable via potentiometer (model-dependent)

Operating Temperature
-25C to +70C

Power Consumption
< 10 mA (no load)

Mounting Type
Flush-mountable, Threaded Cylindrical (M12)

Application
Position Sensing, Presence Detection, Counting Applications

Wireless
No

Features
Short-circuit protection, Polarity reversal protection, LED status indicator

IP Rating
IP67

Product Type
Photoelectric Sensor / Proximity Sensor

Material
Stainless Steel Housing, Plastic Cap

Input
DC 3-wire

Output
PNP Normally Open (NBN4-12GM50-E2); NPN Normally Open (NBN4-12GM60-A2-V1)

Function
Detection of Metallic and Non-Metallic Objects

Usage
Industrial Automation, Object Sensing

Accuracy
High Switching Accuracy

Resolution
Standard

Voltage
10-30 V DC

Weight
Approx. 50-100 g

Indicator
LED for Output State

Hysteresis
Approx. 5-15% of switching distance

Switching Frequency
Max. 2 kHz

Protection Circuits
Reverse polarity, surge and short-circuit protected

Connection Type
Cable or Connector (V1: M12 Connector)

EMC Standards
EN 60947-5-2

Operating Humidity
35...95% RH

Repeat Accuracy
0.1 mm

Max Switching Current
200 mA

Enclosure Material
Nickel-plated Brass / Stainless Steel

Housing Diameter
12 mm (M12)

Standards Compliance
CE, cULus

Model Numbers
NBN4-12GM50-E2, NBN4-12GM60-A2-V1

About PEPPERL +FUCHS PHOTOELECTRIC SENSOR,NBN4-12GM50-E2,NBN4-12GM60-A2-V1

Experience the acclaimed PEPPERL+FUCHS inductive proximity sensorsNBN4-12GM50-E2 and NBN4-12GM60-A2-V1engineered for extraordinary detection in industrial environments. Realise instant savings with their prodigious efficiency and robust design. Personalise your sensing solution with selectable PNP or NPN outputs, high sensitivity adjustment, and repeat accuracy up to 0.1mm. Boasting a crowning achievement in reliability, these sensors feature CE/cULus compliance, IP67 protection, and advanced protection circuits. Seamlessly suited for object sensing, positioning, and counting applications, they deliver high switching accuracy and exceptional durability.

Exceptional Features and Competitive Edge

NBN4-12GM50-E2 and NBN4-12GM60-A2-V1 sensors offer high repeat accuracy, LED output indicators, and advanced protection circuits, including reverse polarity and short-circuit safeguards. Their rugged, nickel-plated brass and stainless steel housing assures longevity, even in challenging environments. Perfect for automation, these sensors are flush-mountable in M12 threaded positions, thriving in factories and process sites demanding consistent high-precision sensing. The adjustable sensitivity and CE/cULus standards compliance further cement their market-leading advantage.

Reliable Supply, Flexible Payments, and Secure Shipment

Benefit from prodigious supply ability and market value through trusted suppliers and wholesalers in Germany. These sensors are packaged in robust, damage-resistant containers to ensure optimal shipment safety. Payment terms can be tailored for your expenditure requirements, offering flexibility such as bank transfer, online payment, or purchase order settlements. The swift supply chain ensures fast order fulfilment, enhancing your project timelines and operational productivity.

FAQs of PEPPERL +FUCHS PHOTOELECTRIC SENSOR,NBN4-12GM50-E2,NBN4-12GM60-A2-V1:

Q: How does the PEPPERL+FUCHS sensor enhance industrial automation processes?

A: The sensor offers high sensitivity, repeat accuracy, and reliable output, enabling automated systems to detect and count objects with exceptional precision and speed, improving overall workflow efficiency.

Q: What are the main benefits of using models NBN4-12GM50-E2 and NBN4-12GM60-A2-V1?

A: These models provide extraordinary reliability, advanced protection circuits, adjustable sensitivity, and high switching accuracy, suitable for a wide range of applications in industrial automation and object detection.

Q: Where can these sensors be installed for optimal performance?

A: They are designed for flush mounting in M12 threaded positions, ideally suited to harsh factory floors, assembly lines, and process automation sites requiring robust and precise sensing.

Q: What is the process for adjusting sensor sensitivity?

A: Sensitivity can be personalised via a potentiometer on specific models, allowing operators to fine-tune detection settings depending on the size and material of objects to be sensed.

Q: When is the best time to use these sensors in automation projects?

A: Deploy these sensors during the initial installation or upgrades of automated systemswhere accurate positioning, presence detection, or counting of both metallic and non-metallic objects is crucial.

Q: How are the sensors shipped and packaged for delivery?

A: Sensors are securely packaged in robust containers to protect against shipping damage and ensure they arrive in optimal condition, facilitating reliable installation upon arrival.
