PEPPERL & FUCHS, ML100-66/103/115

PEPPERL & FUCHS, ML100-66/103/115 Specification

Mounting Type
Through-hole, surface mounting

Sensitivity
Adjustable via potentiometer

Cable Length
2 m (standard cable)

Application
Industrial automation, Packaging, Conveyor systems

Operating Temperature
-25C to +55C

Signal Type
Digital

Power Consumption
20 mA

Features
Bright Spot LED, Visible red light, Compact design

Interface
Cable, M8 connector

Response Time
<1 ms

Sensor Type
Diffuse Mode Sensor

Wireless
No

Measurement Range
0-6 m (depending on model/reflector)

IP Rating
IP67

Product Type
Photoelectric Sensor

Material
Plastic housing

Input
10-30 V DC

Output
PNP/NPN, NO/NC (selectable)

Function
Light ON/Dark ON selectable

Usage
Detection of objects/position in automation processes

Accuracy
High precision detection

Resolution
Reliable small object detection

Voltage
10-30 V DC

Weight
Approx. 40 g

Maximum Output Current
100 mA

Switching Frequency
Up to 500 Hz

Adjustment
Manual Potentiometer or Teach-in

Enclosure Material
ABS Plastic

Alignment Aid
Highly Visible Spot for Easy Alignment

Protection Circuits
Short Circuit Protection, Reverse Polarity Protection

Connection Type
Cable, Connector

Light Source
Red LED (visible, 660 nm)

Housing Dimensions
21.8 mm 11.4 mm 34.2 mm

About PEPPERL & FUCHS, ML100-66/103/115

Discover the wondrous PEPPERL & FUCHS ML100-66/103/115, now available in a noteworthy offer directly from Chinas top suppliers and wholesalers. This sensor features a visible red LED light source (660 nm), a lofty switching frequency up to 500 Hz, and high precision detection. Housing dimensions are compact, at just 21.8 mm 11.4 mm 34.2 mm, and the robust ABS plastic enclosure guarantees durability. With selectable Light ON/Dark ON modes, an easily adjustable potentiometer, and IP67 protection, this clearance-priced sensor is ideal for automation and conveyor systems, offering remarkable reliability and adaptability.

Extra Features & Commercial Applications

The ML100-66/103/115 sensor from PEPPERL & FUCHS boasts special features such as a highly visible alignment spot, adjustable sensitivity via potentiometer, and selectable output logic (PNP/NPN, NO/NC). Its compact, lightweight design ensures flexible placement, while its IP67 rating allows usage in harsh industrial environments. Commercially, it shines in packaging lines, conveyor systems, and various automation applications, providing lofty performance with minimal power expenditure.

Sample Policy, Availability & Certifications

Samples of the ML100-66/103/115 sensor are readily supplied upon request to facilitate your evaluation process. Delivered with proper certification and compliance, each sample involves minimal expenditure for buyers prioritizing quality assurance. Our streamlined policy ensures that samples are dispatched promptly, helping partners in making informed decisions for bulk procurement and commercial integration.

FAQs of PEPPERL & FUCHS, ML100-66/103/115:

Q: How can the sensitivity of the ML100-66/103/115 sensor be adjusted?

A: The sensitivity of the ML100-66/103/115 can be finely tuned using its manual potentiometer or the teach-in function, ensuring accurate detection of various object sizes.

Q: What is the typical commercial use for this PEPPERL & FUCHS sensor?

A: This sensor is extensively used in industrial automation, including packaging, conveyor systems, and position/object detection tasks where reliable automation is essential.

Q: When is it most beneficial to use the ML100-66/103/115s selectable Light ON/Dark ON feature?

A: This feature is particularly beneficial when the sensor needs to adapt to different detection requirements in changing lighting or operational environments, maximizing flexibility in usage.

Q: Where can the ML100-66/103/115 sensor be installed and how is it mounted?

A: It can be installed in various locations, including through-hole or surface mounting positions in industrial settings, using standard cables or M8 connectors.

Q: What certifications accompany the supplied ML100-66/103/115 sensor samples?

A: Supplied sensors come with all relevant certifications, ensuring compliance with industrial standards for safety, protection, and performance.

Q: How does the alignment aid improve the installation process?

A: The highly visible spot alignment aid streamlines installation, allowing users to quickly and accurately position the sensor for optimal performance.
