PANASONIC PROXIMITY SENSOR, NA2-N16

PANASONIC PROXIMITY SENSOR, NA2-N16 Specification

Cable Length
3 m

Sensitivity
Adjustable via potentiometer

Sensor Type
Through-beam (area) sensor

Signal Type
Digital

Operating Temperature
-10°C to +55°C

Wireless
No

IP Rating
IP64

Mounting Type
Surface or bracket mounting

Features
Slim body, Easy alignment, Multi-beam design

Power Consumption
Emitter: 720mW or less, Receiver: 960mW or less

Interface
Cable

Application
Part counting, Presence detection, Automatic assembly lines

Response Time
10 ms or less

Measurement Range
0.2 m to 5 m (sensing distance between emitter and receiver)

Product Type
Proximity Sensor

Material
Polycarbonate housing

Input
12-24V DC

Output
NPN open collector

Function
Object detection using light beams

Usage
Industrial automation, Machine safety

Accuracy
High

Resolution
2 mm (minimum detectable object diameter)

Voltage
12-24V DC

Weight
Approx. 140g (including mounting brackets and cable)

Number of Axes
16 pairs

Light Source
Infrared LED

Series
NA2-N

Vibration Resistance
10 to 55 Hz, amplitude 1.5 mm, in X, Y, Z directions for 2 hours each

Sensing Distance
16 m (maximum)

Connection Method
Pre-wired (standard cable 2 m)

Minimum Detectable Object
Opaque object of 13 mm dia. or more

Ambient Humidity
35 to 85% RH

Indicator
Operation indicator (Red LED)

Supply Voltage Tolerance
+10%, -15%

Shock Resistance
500 m/s2, in X, Y, Z directions for 3 times each

PANASONIC PROXIMITY SENSOR, NA2-N16 About

Capitalise on the outstanding capabilities of the PANASONIC PROXIMITY SENSOR, NA2-N16, designed for sublime precision in industrial automation. For an uncommon opportunity, this limited-time offer lets you order a sensor that features a remarkable 16 m sensing distance using infrared LEDs and a highly visible red operation indicator. Its multi-beam, slim-profile design ensures easy alignment while maintaining resistance to both vibration and shocks. Constructed with a robust polycarbonate housing, this sensor excels in object detection, part counting, and machine safety applications, making it an essential addition for those seeking superior industrial performance.

Exceptional Advantages and Material Excellence

The PANASONIC PROXIMITY SENSOR, NA2-N16, stands out due to its high-resolution detection and easy-to-use multi-beam configuration. As a through-beam sensor, it is ideal for precise object detection in automated settings. Its polycarbonate housing offers durability, ensuring longevity even in demanding environments. With a compact, slim body, the sensor is straightforward to mount, while its adjustable sensitivity and advanced vibration resistance provide overall reliability and operational flexibility, making it a wise choice for modern industrial applications.

Global Supply, Flexible Payment, and Broad Market Reach

The PANASONIC PROXIMITY SENSOR, NA2-N16, is available for supply in prominent export markets across Europe, Asia, and North America, with flexible payment terms to accommodate varied customer requirements. The list price ensures optimal value for your expenditure, catering to both large-scale and regional distributors. Main domestic markets include China and adjacent industrial hubs, where the products reliability and competitive pricing have set a new standard in proximity sensing technology for automation and safety solutions.

FAQs of PANASONIC PROXIMITY SENSOR, NA2-N16:

Q: How does the PANASONIC NA2-N16 proximity sensor achieve accurate detection?

A: The NA2-N16 utilises a sophisticated through-beam infrared sensing method with 16 pairs of axes and multi-beam alignment, providing reliable detection of opaque objects as small as 13 mm and ensuring high-resolution accuracy with a 2 mm minimum detectable object diameter.

Q: What are the primary usage scenarios for this sensor?

A: This proximity sensor is commonly used in industrial automation for part counting, presence detection, and safeguarding automatic assembly lines, thanks to its rapid response time, easy alignment, and robust vibration and shock resistance.

Q: Where can the NA2-N16 sensor be installed effectively?

A: The slim design and mounting versatility of the NA2-N16 allow for surface or bracket installation, making it suitable for integration into a variety of machinery layouts and automated system infrastructures.

Q: What benefits does the polycarbonate housing provide in the NA2-N16?

A: The polycarbonate housing contributes to the sensors outstanding durability and resistance to harsh environmental conditions, protecting internal components from dust, humidity, and mechanical impacts.

Q: How is the sensitivity of the sensor adjusted during installation?

A: The NA2-N16 is equipped with an easily accessible potentiometer, allowing users to fine-tune sensitivity for optimal detection performance during setup or maintenance.
