PANASONIC PHOTOELECTRIC SENSOR EX-23-PN

PANASONIC PHOTOELECTRIC SENSOR EX-23-PN Specification

Measurement Range
Detection Distance: 500 mm max.

Power Consumption
30 mA or less

Sensor Type
Photoelectric

Mounting Thread
M3

Application
Industrial Automation, Position Sensing

Interface
3-wire connection

Sensitivity
Adjustable via Potentiometer

Features
Compact Size, High Reliability, Easy Installation

Ingress Protection
IP67

Response Time
1 ms or less

Housing Material
PBT (Polybutylene Terephthalate)

Mounting Type
Panel Mount / Side Mount

Signal Type
PNP, Digital (ON/OFF)

IP Rating
IP67

Wireless
No, No

Operating Temperature
-25C to +55C

Spectral Range
Visible Red LED (Approx. 650 nm)

Cable Length
2 m built-in cable

Product Type
Photoelectric Sensor

Material
Plastic

Input
DC 12-24V

Output
PNP Open Collector

Function
Diffuse Reflective Detection

Usage
Object Detection, Automation Systems

Accuracy
High Precision Sensing

Resolution
Standard

Voltage
12-24V DC

Weight
Approx. 10g

Polarity Protection
Reverse polarity protection

Indicator
Operation indicator (red LED)

Storage Temperature
-30C to +70C

Material (Lens)
Polycarbonate

Sensing Method
Diffuse Reflective (convergent reflective type)

Shock Resistance
500 m/s2 (approx. 50G) in X, Y, Z directions for 3 times each

Connection Type
Pre-wired (2m cable)

Vibration Resistance
10 to 55Hz, amplitude 1.5 mm, in X, Y, Z directions for 2 hours each

Light Source
Infrared LED

Current Consumption
15mA (without load)

Ambient Humidity
35 to 85% RH

Max. Output Current
100mA

Short Circuit Protection
Available

PANASONIC PHOTOELECTRIC SENSOR EX-23-PN About

Experience the ace in industrial automation with the PANASONIC PHOTOELECTRIC SENSOR EX-23-PN-an affordable and valorous choice, highly in demand among automation experts. Its robust PBT housing and polycarbonate lens provide unwavering durability, while the dominant diffuse reflective detection ensures high-precision object sensing. Equipped with reverse polarity and short circuit protection, this premium sensor delivers consistent, reliable operation. Purchase for your system and benefit from easy installation, adjustable sensitivity, and a compact design. Its IP67 ingress rating and versatile mounting make it the ace performer for modern automation tasks.

Distinguished Features & Applications

The PANASONIC PHOTOELECTRIC SENSOR EX-23-PN is celebrated for its high reliability and compact form, making it suitable for multiple automation environments. Key features include rapid 1 ms response time, adjustable sensitivity, and visible operation indicators for user convenience. Its versatility shines in assembly lines, robotics, and material handling, thanks to side or panel mounting. Designed to withstand significant vibration and shock, this sensor is ideal for valorous application in demanding industrial settings.

Certifications, Packaging, and Sample Options

This premium PANASONIC PHOTOELECTRIC SENSOR EX-23-PN meets stringent IP67 certification standards, guaranteeing splash and dust resistance. It arrives in secure, retail-grade packaging optimized for safe transit and storage. Sample units may be requested for evaluation, with an estimated lead time provided upon inquiry. The list price remains competitive to ensure affordability for suppliers, traders, and wholesalers. Rely on Panasonic's esteemed reputation when considering your next sensor purchase from China.

FAQ's of PANASONIC PHOTOELECTRIC SENSOR EX-23-PN:

Q: How does the PANASONIC EX-23-PN Photoelectric Sensor ensure reliable performance in automation systems?

A: The sensor features reverse polarity protection, short circuit protection, a robust PBT housing, and is IP67 certified. This ensures operation remains consistent and dependable even under harsh industrial conditions.

Q: What are the main applications of the PANASONIC EX-23-PN?

A: It excels in object detection, position sensing, and automation systems, particularly in environments such as assembly lines, robotics, packaging, and material handling operations.

Q: When should I adjust the sensitivity of the PANASONIC EX-23-PN sensor?

A: Adjust the sensitivity using the built-in potentiometer when your objects vary in size, distance, or reflectivity to ensure optimal detection accuracy and minimize false triggering.

Q: Where can I mount the PANASONIC EX-23-PN sensor during installation?

A: The sensor supports both panel mount and side mount configurations, allowing for flexible integration into various automation equipment and spaces.

Q: What benefits do I get from purchasing this sensor from a supplier or wholesaler in China?

A: Purchasing through Chinese suppliers or wholesalers provides access to competitive list prices, reliable sample availability, and fast estimates on delivery, ensuring affordability and efficiency in your procurement process.
