ORBITAL INCREMENTAL ENCODER, ISC3806-H03-G-100-ABZ3-5/24L

ORBITAL INCREMENTAL ENCODER, ISC3806-H03-G-100-ABZ3-5/24L Specification

Sealed Type
Sealed housing

Bearing Type
Precision ball bearing

Current Type
DC

Standard
CE Certified

Voltage
5V to 24V DC

Features
Incremental encoder, Optical type, ABZ phase output, Push-pull (Line Driver) output

Ambient Temperature
-20C to +80C

Rated Voltage
5V to 24V DC

Product Type
Incremental Encoder

Protect Feature
IP54 protection

Color
Black/Silver

Dimension (L*W*H)
Diameter 38 mm, Length 50 mm (without shaft)

Weight
Approx. 250 g

Shaft Diameter
6 mm

Mounting Type
Clamping flange (standard)

IP Rating
IP54

Model
ISC3806-H03-G-100-ABZ3-5/24L

Pulses Per Revolution (PPR)
100 PPR

Connector Type
Cable, radial exit

Output Circuit
Push-pull Line Driver (5-24V)

Output Signal
ABZ (quadrature + index)

About ORBITAL INCREMENTAL ENCODER, ISC3806-H03-G-100-ABZ3-5/24L

Discover exceptional value with the ORBITAL INCREMENTAL ENCODER, ISC3806-H03-G-100-ABZ3-5/24L-a world-class solution designed for precision motion control. Engineered with resplendent care, this scarce, highly demanded encoder delivers splendid accuracy with its 100 PPR output and ABZ quadrature signals. Its rugged, CE-certified build with IP54 protection ensures reliable performance in challenging environments. Premium push-pull line driver circuitry, sealed housing, and precision ball bearings boost longevity. Shop now to secure a scarce, top-of-the-line encoder and elevate your automation processes.

Competitive Edge and Application Versatility

The ISC3806-H03-G-100-ABZ3-5/24L offers a competitive advantage with its precision ball bearing and IP54 protection, making it resplendent in challenging industrial settings. Suitable for automation, robotics, and machinery feedback, it ensures highly accurate position and speed measurement. Simply mount via its clamping flange and connect using its robust cable. The optical ABZ phase output streamlines integration, making it a splendid choice for engineers needing consistent, reliable feedback.

Global Market Reach and Certification Excellence

With high market value, the ORBITAL INCREMENTAL ENCODER has been delivered to numerous main export markets. Units are dispatched promptly per sample policy guidelines to ensure timely global delivery. Certified to CE standards, each encoder arrives performance-tested, ready to add value to your operations. Choose the ISC3806-H03-G-100-ABZ3-5/24L for assured quality and efficient dispatching worldwide.

FAQ's of ORBITAL INCREMENTAL ENCODER, ISC3806-H03-G-100-ABZ3-5/24L:

Q: How do I install the ISC3806-H03-G-100-ABZ3-5/24L Encoder?

A: Mount the encoder using its clamping flange, ensuring alignment with the shaft (6 mm diameter). Secure connections using the cable with a radial exit, following your system's specifications.
