OMRON TIMER 24VDC, H3BA-N8H

OMRON TIMER 24VDC, H3BA-N8H Specification

Type
Multi-Function Timer

Material
Plastic, Metal

Voltage
24VDC

Weight (kg)
0.21 kg

Dimension (L*W*H)
48mm x 48mm x 91mm

Color
Beige

Operating Temperature
-10C to +55C

Theory
Electronic Timer Relay

Usage
Industrial Automation, Process Control

Min Setting Time
0.05 sec

Design
Compact Panel Mount

Reset Method
Reset/Power OFF & Reset Switch

Contact Configuration
2 C/O (DPDT)

Time Ranges
Six selectable

Insulation Resistance
100 M minimum (at 500 VDC)

Output Contact Rating
5A at 250VAC/30VDC

Model Number
H3BA-N8H

Timing Range
0.05 seconds to 100 hours

Mounting Type
Socket / Panel Mount

Dielectric Strength
2,000 VAC, 50/60 Hz for 1 min

Power Consumption
Approx. 1.2W

Display
LED indicator

About OMRON TIMER 24VDC, H3BA-N8H

The illustrious OMRON TIMER 24VDC, H3BA-N8H stands out as a hot-selling, scarce resource in industrial automation. Remarked for its premium versatility, this compact panel mount timer delivers a heroic timing range from 0.05 seconds to 100 hours. Its 2 C/O (DPDT) configuration, six selectable time ranges, and LED indicator make it a featured product for precise process control. Engineered for durability with notable insulation resistance, this high-demand timer is ideal for traders, wholesalers, and suppliers seeking a reliable, multi-function solution.

Versatile Industrial Usage Across Applications

The OMRON TIMER 24VDC, H3BA-N8H is widely used in industrial automation and process control environments. Its robust multi-function timer relay design supports a variety of usage scenarios, including manufacturing lines, packaging plants, and control panels. With easy panel or socket mounting and reliable DPDT contacts, it ensures operational consistency in high-demand settings. The compact build and broad timing range make it a preferred choice for both new installations and upgrades in industrial circuits.

Global Trade Advantages and Premium Export Benefits

Exported primarily through major Chinese FOB ports, the OMRON TIMER 24VDC, H3BA-N8H is available for sample evaluation to minimize upfront expenditure for customers. Its remarkable reliability and hot-selling status ensure that freight costs are offset by its long-term value. Major export markets include Asia, Europe, and the Middle East, catering to buyers who seek premium, industrial-grade timer solutions with efficient distribution channels and prompt delivery.

FAQ's of OMRON TIMER 24VDC, H3BA-N8H:

Q: How is the OMRON TIMER H3BA-N8H installed in industrial setups?

A: The OMRON TIMER H3BA-N8H can be mounted via socket or panel installation, allowing flexible integration into various industrial automation and control systems with minimal effort.

Q: What are the main benefits of using this timer relay for process control?

A: This timer relay offers precise timing with six selectable ranges, high insulation resistance, and a clear LED indicator, ensuring accurate and reliable process control in demanding environments.

Q: Where is this timer typically used?

A: The OMRON TIMER H3BA-N8H is commonly used in manufacturing lines, conveyor systems, packaging equipment, and other process control applications that require reliable timing and automation.

Q: How does the reset mechanism function on the H3BA-N8H model?

A: This model features multiple reset methods, including power OFF and a dedicated reset switch, enabling quick recovery and adjustment during operation or maintenance.

Q: What is the output contact rating of the H3BA-N8H, and why is it important?

A: The output contact rating is 5A at 250VAC or 30VDC, allowing it to control a wide range of devices reliably without risk of overload, which is critical for safety and longevity in industrial use.
