OMRON TIMER 24-240VAC/DC, H3DKZ-G

OMRON TIMER 24-240VAC/DC, H3DKZ-G Specification

Voltage
24-240VAC/DC

Weight (kg)
0.13 kg

Dimension (L*W*H)
22.5 mm 90 mm 100 mm

Color
Beige

Operating Temperature
-20C to +55C

Theory
Time Relay

Usage
Industrial Automation, Control Panels

Min Setting Time
0.1 seconds

Design
Compact DIN Rail Mount

Degree of Protection
IP20 (Terminals), IP40 (Case)

Model Number
H3DKZ-G

Number of Functions
10 (Multi-Function)

Frequency
50/60Hz

Vibration Resistance
10 to 55 Hz, 0.75 mm double amplitude

Standards
CE, UL, cUL, CCC Approved

Mounting Type
DIN Rail

Signal Input
Start, Reset, and Gate Inputs

Insulation Resistance
100 M min. (at 500 VDC)

Time Range
0.1 seconds to 1200 hours

Dielectric Strength
2,000 VAC, 50/60 Hz for 1 min

Display
LED status indicator

Output Contacts
2 x SPDT (Double Pole Changeover)

Power Consumption
Approx. 1.2W at 240VAC

Storage Temperature
-25C to +65C

OMRON TIMER 24-240VAC/DC, H3DKZ-G About

Discover the exclusive OMRON TIMER 24-240VAC/DC, H3DKZ-G-a superior digital timer relay designed for extraordinary performance in demanding industrial environments. With potent functionality, including 10 multi-functions and robust SPDT contacts, it precisely manages time ranges from 0.1 sec to 1200 hours. Enjoy reliable operation with advanced LED indication, flame retardant housing, and competitive pricing. Certified by CE, UL, cUL, and CCC, this compact, DIN rail-mounted solution delivers enhanced durability, safety, and versatility for automation and control panel applications.

Optimized for Industrial Automation and Superior Ease of Use

The OMRON TIMER H3DKZ-G is tailored for industrial automation and control panels. Its DIN rail mount design ensures quick installation, and the multi-function setup offers flexible usage for various timing applications. Operators can easily set functions and time ranges using intuitive controls and benefit from the LED status indicators for real-time operation monitoring. With start, reset, and gate input signals, this unit enhances workflow efficiency in any automation system.

Efficient Supply and Secure Delivery Across Main Domestic Markets

Supplying to major domestic markets, the OMRON TIMER H3DKZ-G offers estimated delivery times based on region and demand. Customers benefit from secure shipping practices that ensure the reliable arrival of their order. With industry-recognized certifications including CE, UL, cUL, and CCC, clients receive products that meet stringent safety and quality standards, supporting a variety of commercial and industrial installations across the country.

FAQ's of OMRON TIMER 24-240VAC/DC, H3DKZ-G:

Q: How does the OMRON TIMER H3DKZ-G improve industrial automation processes?

A: The OMRON TIMER H3DKZ-G streamlines timing control in automation systems through flexible multi-function settings, precise time ranges, and reliable input functions, optimizing workflow and reducing manual intervention.

Q: What is the installation process for this timer relay?

A: Installation is straightforward thanks to the compact DIN rail mount design. Simply secure the device to the DIN rail, connect the wiring as specified in the manual, and configure desired settings using the front panel controls.

Q: When can I expect delivery for the OMRON TIMER H3DKZ-G?

A: Estimated delivery times vary depending on your location within the main domestic market, but orders typically ship securely and arrive within the timeframe agreed upon at purchase.

Q: Where can this timer relay be effectively used?

A: This versatile timer relay is ideal for industrial automation, control panels, and other electrical applications where precise timing control is essential.

Q: What are the main benefits of its certifications like CE, UL, and CCC approval?

A: These certifications confirm the timer's compliance with international safety and quality standards, ensuring peace of mind and reliable operation in a variety of industrial settings.

Q: How do operators monitor the device's status during use?

A: The built-in LED status indicator on the relay provides clear, ongoing operational feedback, helping users monitor performance and troubleshoot as needed.
