OMRON TERMINAL RELAY,G6B-4BND

OMRON TERMINAL RELAY,G6B-4BND Specification

Working Temperature
-25C to +55C

Contact Form
4 Form C (DPDT)

Contact Material
Silver alloy

Coil Voltage
24V DC

Mechanical Life
20,000,000 operations min.

Ambient Temperature
-25C to +55C

Coil Power
Approx. 0.45W

Contact Resistance
100 m max.

Protect Feature
Built-in Diode (for coil surge suppression)

Power Consumption
Approx. 0.5W per relay

Dielectiric Strength
2000VAC, 50/60 Hz for 1 min

Product Type
Terminal Relay Unit

Insulation Resistance
100 M min. (at 500V DC)

Theory
Electromagnetic Relay

Usage
Industrial Control

Contact Load
5A at 250 VAC / 30 VDC

Operate Time
10 ms max.

Terminal Type
Screw Terminal

Rated Voltage
24V DC

Supply Terminal
DIN Rail Mount

Color
Beige

Dimension (L*W*H)
73 x 99 x 40 mm

Weight
Approx. 150g

Equipment Compatibility
PLC, Electrical Panels

Relay Socket Model
P6B-4BND

Switching Voltage (Max)
250V AC / 220V DC

Package Quantity
1 Piece

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Mounting Method
DIN Rail or Panel Mounting

Response Time
Approx. 10 ms

Number of Poles
4-Pole Relay

Shock Resistance
1000 m/s

Storage Temperature
-40C to +70C

Indicator
LED Indicator for Coil ON

Release Time
5 ms max.

About OMRON TERMINAL RELAY,G6B-4BND

The OMRON TERMINAL RELAY, G6B-4BND is a superlative, cost-effective industrial relay acclaimed as a best-seller among suppliers and wholesalers. This 4-pole champion is designed for PLCs and electrical panels, featuring easy DIN rail or panel mounting. Its ravishing performance is evident in the 5A contact load, impressive shock and vibration resistance, and quick response times. Enhanced with a built-in diode for surge suppression and LED coil status indicator, this bargain relay ensures safety, reliability, and longevity for efficient electrical control solutions.

OMRON TERMINAL RELAY, G6B-4BND: Optimal Industrial Control

Engineered for industrial control applications, the OMRON TERMINAL RELAY, G6B-4BND is suitable for PLCs and electrical panels. Its 4-pole, screw terminal design ensures effortless and secure connections, while integrated LED indicators and a built-in diode enhance operational safety. This relay is tailored for demanding environments, boasting excellent shock and vibration resistance. The standard size and versatile mounting make it an outstanding fit for diverse automation, electrical, and industrial setups.

Sample Policy and Swift Order Processing

Sample availability is ensured for the OMRON TERMINAL RELAY, G6B-4BND, allowing buyers to evaluate the product before bulk orders. Clear payment terms facilitate stress-free transactions. Shipped goods are efficiently handled, with each relay handover processed quickly to minimize downtime. Order processing is transparent, making delivery straightforward and dependable. This seamless approach helps customers make informed decisions and experience efficient procurement, whether for a single unit or large-scale requirements.

FAQ's of OMRON TERMINAL RELAY,G6B-4BND:

Q: How does the OMRON TERMINAL RELAY, G6B-4BND benefit industrial control systems?

A: This relay is optimized for industrial control, providing rapid response times, high shock and vibration resistance, and reliable performance for PLC and electrical panel integration.

Q: What is the maximum contact load and switching voltage of this relay?

A: The relay is rated for up to 5A at 250 VAC or 30 VDC, with a maximum switching voltage of 250V AC or 220V DC, making it suitable for medium-power applications.

Q: Where can the OMRON G6B-4BND relay be mounted?

A: It can be mounted both on DIN rails and directly on panels, allowing flexibility in various industrial setups and electrical enclosures.

Q: What extra features enhance the safety and durability of this relay?

A: The relay includes a built-in diode for coil surge suppression, an LED indicator to signal coil activation, and silver alloy contacts for enhanced durability.

Q: Is a sample available before placing a bulk order?

A: Yes, samples of the OMRON TERMINAL RELAY, G6B-4BND are available to help buyers evaluate suitability prior to committing to larger quantities.

Q: What are the typical order processing and payment terms for this product?

A: Payment terms are straightforward, and shipped goods are processed and handed over promptly, ensuring efficient order handling and reliable delivery timelines.
