OMRON SOLID STATE RELAY, G3NA-2258

OMRON SOLID STATE RELAY, G3NA-2258 Specification

Contact Material
Semiconductor

Protect Feature
Built-in Snubber Circuit

Coil Voltage
24VDC

Coil Power
0.8W

Contact Form
SPST-NO (1 Form A)

Contact Resistance
100m

Power Consumption
0.8W (Input Side)

Working Temperature
-30C to +80C

Mechanical Life
Infinite (no moving parts)

Dielectiric Strength
2500VAC, 50/60Hz for 1 min

Ambient Temperature
-30C to +80C

Product Type
Solid State Relay

Insulation Resistance
1000 M at 500VDC

Theory
Solid State

Usage
Industrial Automation, Power Switching

Contact Load
25A at 24-480VAC

Operate Time
10ms

Rated Voltage
24-480VAC

Supply Terminal
Input (DC), Output (AC)

Size
Standard DIN Mount

Color
Light Grey

Dimension (L*W*H)
58mm x 43mm x 28mm

Weight
~110g

Package Type
Module

Dielectric Strength (Input/Output)
4000VAC, 1 min

Housing Material
Flame Retardant Plastic

Response Time (ON/OFF)
1/2 Cycle of Input

Mounting Type
Panel or DIN Rail

Input Voltage Range
9.6 to 32VDC

Shock Resistance
1000m/s2

Input Current
7.5mA at 24VDC

Storage Temperature
-30C to +100C

Output Voltage Range
24 to 480VAC

LED Indicator
Yes (Status Indicator)

Load Current
25A

Surge Withstand Voltage
6000V (1.2/50s)

Vibration Resistance
10-55Hz, 1.5-mm double amplitude

Min. Load Current
0.1A

OMRON SOLID STATE RELAY, G3NA-2258 About

Experience sizzling, instant savings and select reliability with the OMRON SOLID STATE RELAY, G3NA-2258. Crafted with noble, meritorious precision, this pristine relay incorporates cutting-edge features: an input range of 9.632VDC, output voltage range of 24480VAC, and a robust 25A load capacity. The flame-retardant plastic housing, built-in snubber circuit, and LED status indicator ensure ultimate protection and seamless monitoring. With resistance to shock and vibration, minimal maintenance, and infinite mechanical life, its the perfect solution for industrial automation and power switching needs.

Wide Industrial Application & User Suitability

OMRONs G3NA-2258 Solid State Relay is ideal for powerful and reliable switching in demanding industrial automation environments. This module is specifically designed for use in factory systems, process control setups, and automated machinery. Widely trusted by engineers, panel builders, and machine manufacturers, it is suitable for integration into panels or DIN rails. Select G3NA-2258 for meritorious performance in systems that demand precise, long-lasting switching without maintenance concerns.

Estimate Shipment, Secure Payment, and Sample Policy

Flexible payment terms are available for the OMRON G3NA-2258, tailored to suit bulk and wholesale transactions. Sample policies are available upon request, allowing you to evaluate pristine performance first-hand before finalizing your bulk shipment estimate. We ensure reliable drop-off and timely shipment, with well-established logistics for main export markets in Asia, the Middle East, Africa, and Europe. Your satisfaction and trust in every transaction are our highest priorities.

FAQs of OMRON SOLID STATE RELAY, G3NA-2258:

Q: How can the OMRON G3NA-2258 Solid State Relay be installed?

A: The G3NA-2258 can be easily installed using either panel mounting or a standard DIN rail. It is designed for straightforward integration in industrial panels and machinery.

Q: What key benefits does the built-in snubber circuit provide?

A: The built-in snubber circuit enhances the relays reliability by protecting it from voltage spikes and minimizing electrical noise, ensuring stable and safe performance for power switching applications.

Q: Where is the OMRON G3NA-2258 Solid State Relay most suitable for usage?

A: This relay is most suitable for industrial automation, process control, and power switching where durable, maintenance-free, and precise control is essential.

Q: When is it optimal to use a solid state relay like the G3NA-2258 instead of an electromechanical relay?

A: It is optimal to use the G3NA-2258 when silent, rapid, and vibration-resistant operation is required, especially in applications demanding infinite mechanical life and high switching reliability.

Q: What is the process for requesting a sample or making a bulk purchase?

A: For sample requests or bulk purchases, contact our sales team. We provide shipment estimates, sample drop-off arrangements, and guide you through secure payment procedures.
