OMRON SOCKET RELAY,PT14

OMRON SOCKET RELAY,PT14 Specification

Contact Resistance
Max. 100 m (Initial)

Working Temperature
-40C to 70C

Contact Material
Silver Alloy (Depending on Relay Used)

Coil Voltage
According to Matched Relay (Not Dedicated)

Mechanical Life
10,000,000 Operations Min.

Dielectiric Strength
2000 VAC for 1 min (Between coil and contact)

Power Consumption
Low

Protect Feature
Finger Protection Structure

Coil Power
According to Matched Relay (Not Dedicated)

Contact Form
SPDT / DPDT (Depending on Relay Used)

Ambient Temperature
-40C to 70C

Product Type
Relay Socket

Insulation Resistance
100 M min. (at 500 VDC)

Theory
Electromagnetic Relay Socket

Usage
General Purpose Relay Socket

Contact Load
10A 250VAC / 10A 30VDC Max

Operate Time
10 ms max

Terminal Type
Screw Terminal

Rated Voltage
250V AC

Supply Terminal
8 Pin and 14 Pin Versions

Size
Standard (PT14)

Color
Black

Dimension (L*W*H)
Approx. 85 mm x 35 mm x 23 mm

Weight
Approx. 70g

Number of Poles
14 Pin (PT14)

Terminal Screw Size
M3.5

Flammability Rating
UL94V-0

Mounting Type
DIN Rail or Panel Mount

Standards Approval
UL, CSA, VDE (Depending on matched relay)

Vibration Resistance
10 to 55 Hz, 1.5mm Double Amplitude

Storage Temperature
-40°C to 70°C

Body Material
High Durability Plastic

Compatible Relay Series
Omron MY and LY Series Relays

About OMRON SOCKET RELAY,PT14

Jump on this hot deal and buy online the OMRON SOCKET RELAY, PT14 for impeccable and optimum performance in industrial applications. This phenomenal relay socket boasts high durability plastic with a UL94V-0 flammability rating, ensuring maximum safety. Compatible with Omron MY and LY Series Relays, it features a 14-pin configuration, rated at 250V AC, and supports both DIN rail and panel mounting. Designed for general-purpose use, its finger protection structure, high vibration resistance, and low power consumption guarantee reliability and longevity for critical electrical setups.

Unmatched Competitive Advantages of OMRON SOCKET RELAY, PT14

The OMRON SOCKET RELAY, PT14 stands out for its mechanical life of at least 10 million operations and impeccable insulation resistance. Ideal for industrial electrical controls, automation panels, and general relay sockets, it boasts UL, CSA, and VDE approvals for optimum reliability. Its high vibration and temperature resistance make it suitable for harsh environments, while the easy screw terminal connections ensure quick and safe installation, maximizing productivity and safety in critical setups.

Sample Policy and Supply Logistics for OMRON SOCKET RELAY, PT14

OMRON SOCKET RELAY, PT14 samples are available through a straightforward proposal amount process, giving customers access before committing to bulk purchases. Transport services and transportation options are tailored to ensure timely and secure delivery. With robust supply ability from reputable Chinese suppliers, traders, and wholesalers, customers can expect rapid fulfillment and reliable inventory management, facilitating seamless integration into their manufacturing or automation systems.

FAQs of OMRON SOCKET RELAY,PT14:

Q: How can I purchase the OMRON SOCKET RELAY, PT14 online?

A: You can buy the OMRON SOCKET RELAY, PT14 through authorized online suppliers, wholesalers, or trading platforms specializing in industrial automation components.

Q: What areas of application are suitable for the PT14 socket relay?

A: The PT14 socket relay is designed for general-purpose use in industrial control panels, manufacturing setups, electrical automation systems, and relay mounting requirements.

Q: When are sample units of PT14 socket relay available for evaluation?

A: Sample units can be requested from suppliers who offer a proposal amount process, allowing you to assess the product before placing bulk orders.

Q: Where is the PT14 socket relay manufactured and supplied from?

A: The PT14 socket relay is supplied by reliable Chinese manufacturers, traders, and wholesalers, ensuring efficient global transport services and distribution.

Q: What is the process for integrating PT14 into an existing automation system?

A: Integration involves mounting the socket (DIN rail or panel), connecting relay terminals using M3.5 screws, and ensuring compatibility with Omron MY or LY series relays.

Q: How does the finger protection structure benefit users?

A: The finger protection structure reduces the risk of accidental electrical contact, enhancing safety during maintenance and installation in industrial settings.
