OMRON SENSOR REFLECTOR,E39-R1, E39-F1, E3C-LD11, E3C-LDA11

OMRON SENSOR REFLECTOR,E39-R1, E39-F1, E3C-LD11, E3C-LDA11 Specification

Response Time
250 s (E3C-LD11/LDA11 typical)

Sensitivity
Adjustable (on sensor unit)

Features
Compact size, high stability, anti-interference, precision alignment, long life

Operating Temperature
-25C to +55C

Measurement Range
Reflector: up to 4m, Sensor: up to mm-level detection (varies by model)

IP Rating
IP64 (Reflector), IP66 or higher (Sensors)

Application
Position detection, counting, industrial automation, packaging, assembly lines

Interface
Cable/Connector type

Mounting Type
Panel/Bracket/Surface Mounting

Power Consumption
30 mA max. (for E3C-LD11/LDA11 sensor units)

Signal Type
Photoelectric/Optical

Wireless
No

Cable Length
2m standard (Sensor) / N/A (Reflector)

Sensor Type
Photoelectric/Reflective/Optical Fiber Amplifier

Product Type
Sensor Reflector Unit

Material
Plastic, Acrylic, Metal

Input
N/A (Reflector type, passive)

Output
Transistor (NPN/PNP), Photoelectric Reflective Output

Function
Object detection and reflection for Omron sensors

Usage
Industrial sensing, optical detection, automation

Accuracy
High (Sensor accuracy depends on application)

Resolution
Depends on sensor model (relevant for E3C-LD11/E3C-LDA11, fine resolution optical)

Voltage
12-24V DC (for sensor types E3C-LD11, E3C-LDA11)

Weight
E39-R1: Approx. 15g; E39-F1: Approx. 5g; Sensor: Approx. 80g

Sensor Model
E3C-LD11 (NPN output), E3C-LDA11 (PNP output)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Reflector Dimensions
E39-R1: 52mm x 46mm x 8mm; E39-F1: 40mm x 7mm

Reflector Model
E39-R1 (Rectangular), E39-F1 (Round)

Connection Method
Pre-wired, connector available

Ambient Humidity
35% to 85% RH (non-condensing)

Indicator Lights
Operation, stability (sensor only)

Protective Circuitry
Polarity protection, surge suppressor, output short-circuit protection

Repeat Accuracy
0.03mm (sensor-controlled)

Light Source
Red LED

Enclosure Material
ABS, Acrylic, Brass (sensor body)

Maximum Sensing Distance
E39-R1 up to 4m (with compatible sensor); E3C-LD11/LDA11 up to 1000 mm (diffuse)

About OMRON SENSOR REFLECTOR,E39-R1, E39-F1, E3C-LD11, E3C-LDA11

Shop now for the fresh and masterful OMRON SENSOR REFLECTOR seriesE39-R1 (Rectangular), E39-F1 (Round)paired superbly with E3C-LD11 (NPN output) and E3C-LDA11 (PNP output) sensors. These pivotal automation tools feature up to 4m sensing distance with a reflector, advanced protection circuitry, and high repeat accuracy (0.03mm). Their robust enclosure of ABS, Acrylic, and Brass ensures durability. Precision alignment, adjustable sensitivity, and anti-interference guarantee flawless operation. Buy now and elevate industrial detection and automation to a masterpiece level.

Application Versatility and Surfaces

The OMRON SENSOR REFLECTOR, including models E39-R1, E39-F1, E3C-LD11, and E3C-LDA11, is designed for surface, panel, bracket, or direct mounting applications. Apply sensors easily via pre-wired connections, ensuring swift fixation on metals, plastics, or acrylic assembly line surfaces. These reflectors and sensors excel on industrial packaging and counting surfaces, making them superb for automation and object detection tasks with high stability and accuracy.

Domestic Market Outreach and Delivery

Serving the main domestic market across China, our sample policy ensures clients can review product quality before substantial outlay. Freight is calculated on transportation from FOB ports, streamlining transaction costs and logistics. Buyers benefit from flexible delivery options, minimizing outlay through efficient, secure shipping channels. The comprehensive support and product availability ensure seamless integration into industrial processes nationwide.

FAQs of OMRON SENSOR REFLECTOR,E39-R1, E39-F1, E3C-LD11, E3C-LDA11:

Q: How do I properly install the OMRON SENSOR REFLECTOR and sensor models on different surfaces?

A: Install the OMRON SENSOR REFLECTOR (E39-R1/E39-F1) and sensor units (E3C-LD11/E3C-LDA11) using panel, bracket, or surface mounting. Secure the device on flat industrial surfaces like metal, plastic, or acrylic using the provided mounting hardware and ensure proper alignment for optimal detection.

Q: What are the benefits of using these sensors and reflectors in industrial automation?

A: These Omron sensors and reflectors offer superb accuracy, fast response time, high stability, and anti-interference. They facilitate pivotal object detection, positioning, and counting on assembly lines, enhancing automation reliability and production efficiency.

Q: When should I choose the E39-R1 over the E39-F1 Reflector model?

A: Select the E39-R1 (rectangular) for broader sensing applications up to 4 meters, ideal for larger or rectangular operating surfaces. E39-F1 (round) suits more compact or circular surface requirements, both offering excellent reflectivity and durability.

Q: Where can I use E3C-LD11 and E3C-LDA11 sensor models in a facility?

A: E3C-LD11 and E3C-LDA11 sensors work flawlessly for position detection, object counting, and optical sensing on packaging lines, assembly conveyors, and automated equipment within factories, warehouses, or production plants.

Q: What is the process for ordering samples or bulk quantities of these products?

A: Clients may request samples to assess product suitability under our sample policy, then place full orders through our supplier, trader, or wholesaler channels in China. Freight and transportation details are coordinated from the nearest FOB port for efficient delivery.

Q: How does the sensor ensure accurate detection and operational safety?

A: These Omron sensors are equipped with polarity protection, surge suppressors, and output short-circuit safeguards. They feature indicator lights for both operation and stability, ensuring safe, precise object detection and high repeat accuracy during industrial use.
