OMRON ROTARY ENCODER,E6B2-CWZ1X

OMRON ROTARY ENCODER,E6B2-CWZ1X Specification

Cooling Method
Air-cooled (Natural convection)

Output Type
NPN Open Collector

Working Temperature
-10C to 70C

Phase
2-Phase (A, B plus Z) quadrature output

Application
Position and speed detection, industrial automation

Current Range
50 mA max.

Features
Compact size, high durability, metal housing

Operating Temperature
-10C to 70C

Rated Current
50 mA max.

Connector Type
Pre-wired cable

Output Current
30 mA max.

Power Supply
5~12 VDC

Product Type
Rotary Encoder

Input Voltage
5 VDC

Material
Metal and Plastic

Storage Temperature
-25C to 85C

Weight
Approx. 200 g

Housing Diameter
50 mm

Resolution
1000 P/R (Pulses Per Revolution)

Ingress Protection
IP64

Output Shaft Allowable Load
Radial 40 N, Thrust 30 N

Shaft Diameter
6 mm

Cable Length
2 m

Shaft Type
Solid Shaft

Max Response Frequency
100 kHz

Mounting Type
Flange Mount

Rotation Direction
Bi-directional

About OMRON ROTARY ENCODER,E6B2-CWZ1X

The OMRON ROTARY ENCODER, E6B2-CWZ1X, is highly recommended for industrial automation, offering exceptional positional and speed detection. With a special resolution of 1000 pulses per revolution and a robust solid shaft design, this encoder ensures unbeatable performance in demanding applications. Its IP64 ingress protection, compact metal housing, and extended 2m pre-wired cable make it both durable and versatile. The encoder's bi-directional rotation, ephemeral response frequency up to 100 kHz, and dependable NPN open collector output deliver spectacular reliability for precision tasks.

Versatile Usage & Enhanced Features

Designed for reliable position and speed detection, the OMRON ROTARY ENCODER, E6B2-CWZ1X, is ideal for a variety of industrial automation tasks. With a flange mounting type, solid 6 mm shaft, and compact 50 mm housing, it fits seamlessly into restricted installations. Its exceptional bi-directional quadrature output, high load tolerance, and durable metal and plastic construction provide special adaptability and longevity, making it suitable for demanding, continuous use settings.

Certifications, Stock, and Export Markets

This OMRON rotary encoder comes with certifications suitable for global industrial standards and is stock ready for immediate shipment. Fast freight options help minimize outlay on delivery, ensuring your project stays on track. With swift delivery times to major export markets-including Asia, Europe, and North America-suppliers, traders, and wholesalers in China and beyond can benefit from reliable stock and secure logistics to streamline operations.

FAQ's of OMRON ROTARY ENCODER,E6B2-CWZ1X:

Q: How does the OMRON E6B2-CWZ1X rotary encoder support precision in speed and position detection?

A: The E6B2-CWZ1X encoder offers 1000 pulses per revolution with bi-directional quadrature output, allowing for accurate tracking and control of movement, which is essential for applications requiring exact positioning or speed monitoring.

Q: What are the main benefits of the IP64 protection rating?

A: The IP64 ingress protection means the encoder is safeguarded against dust and splashing water, making it suitable for harsh and variable industrial environments.

Q: When is it optimal to use a bi-directional rotary encoder like this model?

A: A bi-directional rotary encoder is optimal for applications where both direction and precise count of movement are required, such as in automation positioning systems, conveyors, or robotics.

Q: Where can this encoder be installed regarding mounting and shaft requirements?

A: The E6B2-CWZ1X features a flange mount and a 6 mm solid shaft, suitable for standard industrial machinery where compact installation and rigid mounting are critical.

Q: What makes the E6B2-CWZ1X exceptionally durable for industrial use?

A: Its construction from metal and high-grade plastic, along with high load tolerance (40 N radial, 30 N thrust) and a robust, compact housing, deliver long-lasting, durable performance for continuous or repetitive operations.
