OMRON RLAY, MY4N1 24VDC

OMRON RLAY, MY4N1 24VDC Specification

Ambient Temperature
-55C to +60C

Mechanical Life
10,000,000 operations min.

Dielectiric Strength
2,000 V AC, 50/60 Hz for 1 min between coil and contacts

Coil Power
Approx. 0.9 W

Working Temperature
-55C to +60C

Power Consumption
Approx. 0.9 W

Contact Form
4PDT (4 Pole Double Throw)

Coil Voltage
24V DC

Protect Feature
With Indicator & Lockable Test Button

Contact Material
Ag Alloy (Silver Alloy)

Contact Resistance
100 m max. (initial value)

Product Type
General Purpose Power Relay

Insulation Resistance
100 M min. (at 500 VDC)

Theory
Electromagnetic Relay

Usage
General Purpose / Industrial Automation

Contact Load
5A at 250VAC / 30VDC resistive load

Operate Time
20 ms max.

Terminal Type
Plug-in

Rated Voltage
24VDC

Supply Terminal
Screw / Solder Terminal

Size
Standard MY4 Size

Color
Transparent Case with Blue Base

Dimension (L*W*H)
27.5 mm x 21.5 mm x 36 mm

Weight
About 35g

Application
Panel Mount, Machine Control, Automation Boards

Shock Resistance
1,000 m/s2 (approx. 100G)

Vibration Resistance
10 to 55 Hz, amplitude 1.0 mm

Mounting Method
Socket Mountable

Test Button
Provided (Lockable)

Indicator
LED Indicator for Coil Status

Standards Compliance
UL, CSA, VDE approved

About OMRON RLAY, MY4N1 24VDC

Order today and experience the crowning achievement in relay excellence with the OMRON RLAY, MY4N1 24VDC. This elite, socket-mountable relay is designed for demanding applications, boasting a lustrous transparent case with a blue base. Sizzling features include an LED indicator for coil status, a lockable test button, and robust resistance to both vibration and shock. With UL, CSA, and VDE compliance, plug-in terminals, and a mechanical life of over 10 million operations, this scarce relay stands out for industrial automation, ensuring uncompromising quality and reliability.

Versatile Applications and Distinguished Features

The OMRON RLAY, MY4N1 24VDC excels in panel mount, machine control, and automated systems, providing general purpose and industrial automation solutions. Features such as a lockable test button, LED indicator for coil status, and vibration resistance up to 55 Hz distinguish it from standard relays. Its elite build includes a transparent case, blue base, and plug-in terminal. Superior insulation and mechanical life ensure crowning performance in demanding environments.

Reliable Supply, Secure Packaging, and Sample Policy

This relay is available for prompt domestic market and international shipment, with supply capacity catering to both bulk traders and wholesalers. Each item is carefully packed to prevent freight damage, ensuring secure arrival. Sample policies are tailored for trusted clients-contact us for details. Efficient order processing ensures you receive your products in optimal condition, making the OMRON MY4N1 a preferred choice for consistent quality and reliable delivery.

FAQ's of OMRON RLAY, MY4N1 24VDC:

Q: How is the OMRON RLAY, MY4N1 24VDC typically mounted or installed?

A: The OMRON RLAY, MY4N1 24VDC is socket mountable, making it easy to install in panel mounts, machine control boards, or automation panels. Its plug-in, screw/solder terminals facilitate a secure and quick connection.

Q: What distinguishes the features of the OMRON MY4N1 relay for industrial use?

A: Key features include an LED coil status indicator, lockable test button, high shock and vibration resistance, and compliance with UL, CSA, and VDE standards. Its 4PDT format and Ag alloy contacts offer robust performance for industrial automation tasks.

Q: Where can this relay be used for optimal benefit?

A: This relay is ideal for use in automation boards, control panels, and general-purpose machine control, offering reliability in environments with significant electrical or mechanical demands.

Q: What is the process for obtaining a sample or a bulk shipment?

A: To request a sample or bulk order, contact the supplier or wholesaler directly. Packaging is optimized for freight security, and orders are processed for swift domestic and international shipment.

Q: How do the relay's protection features enhance safety and usability?

A: The integrated LED indicator and lockable test button allow users to monitor and test the relay safely without disassembly, improving operational safety and facilitating easy maintenance.
