OMRON RELAY, MY4IN 24VDC

OMRON RELAY, MY4IN 24VDC Specification

Mechanical Life
10,000,000 Operations Min.

Contact Material
Silver alloy

Coil Power
Approx. 0.9 W

Power Consumption
Approx. 0.9 W

Ambient Temperature
-40C to +70C

Working Temperature
-40C to +70C

Contact Resistance
100 m Max. (Initial)

Contact Form
4PDT (4 Pole Double Throw)

Protect Feature
With mechanical indicator and test button

Dielectiric Strength
2,000 VAC, 50/60 Hz for 1 min

Coil Voltage
24V DC

Product Type
General Purpose Relay

Insulation Resistance
100 M Min. (at 500 VDC)

Theory
Electromagnetic Relay

Usage
For industrial control panels, automation, general electrical switching

Contact Load
5A at 220V AC / 24V DC (Resistive load)

Operate Time
20 ms (Max.)

Terminal Type
Plug-in

Rated Voltage
24V DC

Supply Terminal
Screw / Socket type

Size
Standard

Color
Transparent with black base

Dimension (L*W*H)
27.5 x 21.5 x 36 mm (approx.)

Weight
Approx. 80g

Release Time
20 ms (Max.)

Number of Pins
14 Pin

Switching Current
5A (Max.)

Storage Temperature
-40C to +70C

Mounting
Panel mount or socket mount

Switching Voltage
250V AC / 125V DC (Max.)

Shock Resistance
1,000 m/s2 (approx. 100G)

Vibration Resistance
10-55 Hz, 1.0 mm double amplitude

OMRON RELAY, MY4IN 24VDC About

The OMRON RELAY, MY4IN 24VDC stands as a first-string component for industrial control, automation, and electrical switching. It features a remarkable switching voltage capacity of 250V AC / 125V DC and a dependable switching current up to 5A. With its splendid transparent design and mechanical indicator, users benefit from ease of status verification. This latest relay model garners favorable reviews for robust insulation resistance, swift operate/release time, and superior endurance-boasting a mechanical life of 10 million operations. Experience new levels of durability and safety with its dependable plug-in connectivity and versatile panel or socket mounting.

Versatile Usage and Application Surface

The OMRON RELAY, MY4IN 24VDC is splendidly suitable for use in general and specific applications like industrial control panels, automation systems, and broad electrical switching operations. Thanks to its standard size and flexible mounting options-panel mount or socket mount-it adapts easily to various application surfaces. Its robust build and reliability make it an ideal choice for environments requiring consistent switching performance and high mechanical endurance, from advanced industrial automation setups to general electrical tasks.

Export Markets, Supply, and Payment Terms

This remarkable relay is supplied to major export markets, including regions in Asia, Europe, and beyond. Freight is efficiently managed to secure safe and timely order completion. The supplier accepts multiple payment terms to accommodate global trading and wholesale needs. For customer confidence, sample availability is confirmed, allowing clients to review product quality before placing bulk orders. Experience streamlined supply and delivery aligned with international standards for industrial reliability and satisfaction.

FAQ's of OMRON RELAY, MY4IN 24VDC:

Q: How is the OMRON RELAY, MY4IN 24VDC typically mounted?

A: The relay can be conveniently panel mounted or socket mounted, providing flexibility for different installation requirements.

Q: What specific applications benefit from using this relay?

A: It is ideal for industrial control panels, general electrical switching, and automation processes due to its robust design and reliable performance.

Q: Where is the OMRON RELAY, MY4IN 24VDC most commonly used?

A: This relay is widely used in manufacturing plants, automation systems, and industrial electrical panels across various global markets.

Q: What advantages does the mechanical indicator and test button provide?

A: The mechanical indicator and test button allow easy status monitoring and functional testing, ensuring optimal operation and maintenance.

Q: When can I request a sample of the OMRON RELAY, MY4IN 24VDC?

A: Samples are available before bulk ordering, enabling customers to assess fit and quality prior to completing large-scale purchases.

Q: How durable is the OMRON RELAY under demanding conditions?

A: The relay demonstrates exceptional durability, designed for up to 10 million mechanical operations, with high shock and vibration resistance and a wide operating temperature range.
