OMRON, RELAY G2R-1-SND DC24(S)

OMRON, RELAY G2R-1-SND DC24(S) Specification

Ambient Temperature
25C to +70C (No icing or condensation)

Mechanical Life
10,000,000 operations minimum

Coil Power
Approx. 0.53 W

Contact Material
Silver Alloy

Power Consumption
Approx. 0.53 W

Protect Feature
Beware of the Coil Polarity

Working Temperature
25C to +70C

Contact Resistance
Maximum 100 m

Coil Voltage
DC24

Contact Form
SPDT (Single Pole Double Throw)

Product Type
Relay

Insulation Resistance
Minimum 1000 M at 500 VDC

Theory
Electromagnetic Relay

Usage
Electronic Equipment, Automation Panels, Industrial Controls

Contact Load
10A at 250VAC / 30VDC (Resistive Load)

Operate Time
Approx. 10 ms

Terminal Type
Plug-in Type

Rated Voltage
DC24

Size
Standard DIN size

Color
Transparent (Cover) / Black (Base)

Dimension (L*W*H)
Approx. 29 x 13 x 38 mm

Weight
Approx. 35 g

Storage Temperature
25C to +70C

Additional Product Specifications

Number of Pins
5

Model Number
G2R-1-SND DC24(S)

Release Time
Approx. 5 ms

Contact Gap
0.5 mm

Operating Position
Any

Shock Resistance
1000 m/s2 (Approx. 100 G)

Series
G2R-1-SND

Electrical Life
100,000 operations minimum (at rated load)

Approval Standards
UL, CSA, IEC

Dielectric Strength
5000VAC between coil and contacts

Mounting Method
PCB or Socket

Vibration Resistance
10 to 55 Hz, 1.0 mm double amplitude

Humidity Range
5% to 85% RH

About OMRON, RELAY G2R-1-SND DC24(S)

Spotlight on the OMRON RELAY G2R-1-SND DC24(S): a first-class, famed choice for those seeking reliability in industrial automation and electronic equipment. Marvelous dielectric strength of 5000VAC between coil and contacts, and impressive 10,000,000 minimum mechanical life ensure enduring performance. Its transparent cover and standard DIN size make monitoring and replacement a breeze. Jump on this bargain for your automation panelsthis plug-in relay handles 10A loads at 250VAC/30VDC, offers rapid operate/release times, and excellent shock and vibration resistance. The OMRON relay exemplifies top-tier value for forward-thinking engineers.

Extra Features, Advantages, Usage & Applications

The OMRON RELAY G2R-1-SND DC24(S) boasts a host of extra features, including robust vibration and shock resistance, a protective transparent cover, and versatile mounting methods. Its 100,000-cycle electrical life and mechanical endurance up to 10 million operations guarantee longevity. This relay is ideal for automation panels, industrial control systems, and various electronic equipment, providing unmatched stability and swift operation where reliability is essential. Benefit from advanced insulation, compact design, and adaptable operating positions in diverse environments.

Sample Availability, Packaging Details & Certifications

Experience seamless logistics with readily available OMRON G2R-1-SND DC24(S) relay samples for swift product valuation. Packaging is secure and tailored for optimal drop-off, ensuring the relay reaches you in perfect condition. Certifications include UL, CSA, and IEC approval, giving you confidence in quality and compliance for global applications. When you require first-rate performance and certified assurance, this relay is designed for dependable delivery, suitable for suppliers, traders, and wholesalers.

FAQs of OMRON, RELAY G2R-1-SND DC24(S):

Q: How does the OMRON RELAY G2R-1-SND DC24(S) ensure reliable performance?

A: The relay offers a marvelous dielectric strength of 5000VAC, robust vibration and shock resistance, and an electrical life of a minimum 100,000 operations, making it highly reliable for industrial and automation uses.

Q: What is the recommended usage and main application for this relay?

A: The G2R-1-SND DC24(S) is ideal for integration into electronic equipment, automation panels, and industrial controls, handling resistive loads of up to 10A at 250VAC or 30VDC with steady performance.

Q: When should I choose this relay for my projects?

A: Select this relay when your setup requires first-class insulation, rapid switching, compact DIN-sized components, and compliance with recognized certifications such as UL, CSA, and IEC.

Q: Where does this relay excel in terms of environmental conditions?

A: This relay functions reliably in environments with temperatures from 25C to +70C and humidity levels between 5%% and 85%% RH, regardless of operating position.

Q: What is the process to order samples or bulk quantities?

A: Samples are readily available through streamlined logistics. Simply contact your local supplier or wholesaler; secure packaging ensures safe drop-off at your location.

Q: What benefit does the transparent cover provide?

A: The transparent cover allows for easy visual inspection and status checks, enabling quick assessment and maintenance without requiring removal from its mounting.
