OMRON PROXIMITY SWITCH, E2EF-X3D1-M1TGJ

OMRON PROXIMITY SWITCH, E2EF-X3D1-M1TGJ Specification

Temperature Range
-25C to +70C

Number of Module
Single

Rated Voltage
12-24 VDC

Protection Level
IP67

Response Time
1 ms

Mechanical Life
Over 10,000,000 operations

Circuit Type
NPN, Normally Open (NO)

Automation Grade
Automatic

Max. Current
200 mA

Finish Type
Nickel Plated

Product Type
Proximity Switch

Material
Brass (Nickel plated), PBT (Polybutylene Terephthalate)

Insulation Resistance
50 M min. (at 500 VDC)

Contact Resistance
200 m max.

Max. Voltage
30 VDC

Operating Temperature
-25C to +70C (with no icing or condensation)

Size
M12 1, 36 mm length (cylindrical)

Color
Metallic (Body), Black (Cable)

Weight
Approx. 50g

Mounting Type
Flush/Embedded

Current Rating
200 mA

No Of Poles
3-Wire

Indicator
Operation indicator (Red LED)

Environment Resistance
Oil-resistant, Water-resistant

Standards
Conforms to IEC60947-5-2

Sensing Distance
3 mm

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Model Number
E2EF-X3D1-M1TGJ

Shock Resistance
500 m/s², 3 times each in X, Y, and Z directions

Application
Industrial Automation (Detection of metallic objects)

Cable Type
Pre-wired (Connector Type)

Output Type
NPN NO (Normally Open)

Connection Type
M12 connector

Frequency
1,500 Hz

About OMRON PROXIMITY SWITCH, E2EF-X3D1-M1TGJ

Find an exclusive solution for industrial automation with the OMRON PROXIMITY SWITCH, E2EF-X3D1-M1TGJ. Personalise your machinerys performance with its NPN NO output and heroic resilience against harsh environments. The lustrous, nickel-plated brass housing delivers lasting durability, while the pristine detection sensitivity of 3 mm enhances precision in metallic object sensing. With oil and water resistance, IP67 protection, and a rugged M12 connector, this switch is engineered for demanding applications. The operation indicator ensures effortless status tracking for seamless system integration.

Optimised Usage and Application

The OMRON PROXIMITY SWITCH, E2EF-X3D1-M1TGJ is tailored for automatic industrial environments, designed specifically for detecting metallic objects. Ideal for flush or embedded mounting, it operates efficiently with a simple pre-wired connector. To use, install the sensor in line with the target object and ensure it remains within the 3 mm sensing zone for reliable operation. Its robust construction allows for application in high-vibration and high-shock settings, making it suitable for demanding automation processes.

Domestic Market and Fast Shipping Policies

Serving the main domestic market across China, we support a streamlined order processing system for the OMRON PROXIMITY SWITCH E2EF-X3D1-M1TGJ. Express shipping options are available, ensuring that units are shipped promptly to minimize downtime. Certified to standard IEC60947-5-2, this model meets rigorous industry specifications. We offer sample policies tailored to your business needs, providing confidence and assurance with every order fulfilled.

FAQs of OMRON PROXIMITY SWITCH, E2EF-X3D1-M1TGJ:

Q: How does the OMRON E2EF-X3D1-M1TGJ proximity switch enhance automation processes?

A: This proximity switch detects metallic objects with high precision, enabling automated systems to perform reliable position sensing and object detection in industrial environments, thus boosting productivity and reducing manual intervention.

Q: What is the process for installing the E2EF-X3D1-M1TGJ proximity switch?

A: Installation is straightforward: mount the switch using the embedded or flush method, connect the pre-wired M12 connector to your system, and ensure the sensor tip faces the detection target within a 3 mm range.

Q: Where can this proximity switch be effectively used?

A: The E2EF-X3D1-M1TGJ is ideal for industrial automation, particularly in detecting metallic components on assembly lines, machinery safety interlocks, and automated sorting equipment.

Q: What benefits does the operation indicator provide?

A: The inbuilt red LED operation indicator offers instant visual feedback of the switchs status, simplifying diagnostics and reducing maintenance time.

Q: How does the device perform under extreme conditions?

A: Engineered with oil and water resistance, IP67 protection, and high vibration and shock tolerance, this proximity switch remains operational in tough industrial environments, ensuring longevity and reliable function.
