OMRON PROXIMITY SENSOR,E2E-X1R5F1

OMRON PROXIMITY SENSOR,E2E-X1R5F1 Specification

Sensitivity
Adjustable via target approach

Mounting Type
Shielded, M12 threaded

Signal Type
DC 3-wire, NPN output

Sensor Type
Inductive Proximity Sensor

IP Rating
IP67

Interface
Lead wire (pre-wired), 3-wire

Application
Detecting metal targets in factory automation

Wireless
No

Measurement Range
1.5 mm (sensing distance)

Response Time
Under 1 ms

Cable Length
2 meters

Operating Temperature
-25C to +70C (no icing or condensation)

Power Consumption
Under 15 mA max.

Features
Short body, high noise immunity, reverse polarity and surge protection

Product Type
Proximity Sensor

Material
Nickel-plated brass housing

Input
12 to 24 V DC

Output
NPN Normally Open (NO)

Function
Sensing/Detection of metallic objects

Usage
Industrial automation, positioning, counting

Accuracy
High accuracy, reliable operation

Resolution
Sub-millimeter detection capability

Voltage
12-24 VDC

Weight
Approx. 45 g

Allowable Residual Voltage
1 V max. at 100 mA load current

Vibration Resistance
10 to 55 Hz, 1.5 mm double amplitude

Shock Resistance
1000 m/s2, 6 directions, 3 times each

Protection Circuitry
Reverse polarity, surge protection, load short-circuit protection

Connection Method
Pre-wired cable

Shell Diameter
M12 x 1 mm thread

Switching Frequency
1 kHz max.

Material (Sensing Face)
PBT resin

Hysteresis
Less than 10% of sensing distance

Indicator
Red LED (operation indicator)

Standard
IEC compliance

About OMRON PROXIMITY SENSOR,E2E-X1R5F1

Discover the OMRON PROXIMITY SENSOR, E2E-X1R5F1-an extraordinary classic in industrial automation. Grab this hot deal at the lowest price for a limited time! Engineered for monumental reliability, it features a rugged nickel-plated brass housing and IP67 rating, making it ideal for challenging environments. Enjoy precision with sub-millimeter detection, high switching frequency (up to 1 kHz), and robust protection circuitry, including reverse polarity and surge protection. Its compact design, adjustable sensitivity, and 2-meter pre-wired cable ensure easy installation and extraordinary flexibility. Don't miss this limited-time offer from China's top supplier and wholesaler!

Exceptional Performance in Industrial Automation

The OMRON PROXIMITY SENSOR, E2E-X1R5F1 is tailored for high-precision usage in factory automation, positioning, counting, and metallic object detection. Designed for shielded, M12-threaded mounting, its short body and high noise immunity deliver reliable, accurate operation. This sensor is frequently used by industrial engineers, machine builders, and plant automation specialists who demand accuracy, robust protection, and long-term dependability in harsh environments.

Secure Packaging, Certified Quality, Wide Availability

Each OMRON PROXIMITY SENSOR, E2E-X1R5F1 is securely packaged to ensure flawless handover and smooth transportation. The product adheres to IEC standards, offering certified reliability for diverse industrial applications. We offer swift delivery to the main domestic markets and beyond, facilitated by trusted logistics partners, guaranteeing that customers receive genuine, factory-tested sensors promptly and in perfect working condition-backed by Omron's reputation for quality and support.

FAQ's of OMRON PROXIMITY SENSOR,E2E-X1R5F1:

Q: How does the OMRON E2E-X1R5F1 Proximity Sensor benefit industrial automation?

A: This sensor provides high-accuracy, sub-millimeter detection of metallic objects, ensuring efficient positioning, counting, and automation with robust surge, reverse polarity, and short-circuit protections.

Q: What is the typical usage process for installing this proximity sensor?

A: Mount the sensor using its M12 x 1 mm thread, connect the pre-wired 3-wire cable to your control system, and adjust the sensitivity as needed to optimize performance for your specific application.

Q: Where can the OMRON E2E-X1R5F1 Proximity Sensor be used?

A: It is ideal for use in factory automation, machinery positioning, counting applications, and any environment requiring reliable metal detection under harsh conditions.

Q: When should I consider using the OMRON E2E-X1R5F1 over other sensors?

A: Choose this model when you require a compact, highly accurate, and durable inductive proximity sensor, especially where high switching frequency and resistance to shock, vibration, or moisture are critical.

Q: What certifications and protections ensure its reliability?

A: The sensor meets IEC compliance, features reverse polarity and surge protection, and boasts an IP67 rating, ensuring operation in demanding industrial environments.

Q: How does this sensor handle transportation and delivery?

A: Each unit is carefully packaged for safe handover and rapid transportation, ensuring it arrives intact and ready for use in the main domestic and international markets.
