OMRON PROXIMITY SENSOR , E2E-X18MY1, E2E-X18MY2, E2E-X18MY2-M1, E2E-X20MD1L18-T, E2E-X20MD1-M1TGJ, E2E-X20MD1-M1GJ E2E-X20MD1-M1G, E2E-X20MD2L18, E2E-X1R5E1, E2E-X1R5E1-M1, E2E-X1R5E2,

OMRON PROXIMITY SENSOR , E2E-X18MY1, E2E-X18MY2, E2E-X18MY2-M1, E2E-X20MD1L18-T, E2E-X20MD1-M1TGJ, E2E-X20MD1-M1GJ E2E-X20MD1-M1G, E2E-X20MD2L18, E2E-X1R5E1, E2E-X1R5E1-M1, E2E-X1R5E2, Specification

Operating Temperature
-25C to +70C

Cable Length
2 m standard (may vary by model)

Response Time
1 ms

Sensor Type
Inductive

Sensitivity
High

Wireless
No

Interface
3-wire or 2-wire connection, depending on type

IP Rating
IP67

Signal Type
Digital

Measurement Range
Sensing distance: 1.5 mm (E2E-X1R5E1 series), 18 mm/20 mm (E2E-X18MY/E2E-X20MD series)

Mounting Type
Shielded/Unshielded, cylindrical, M18/M20 threaded

Power Consumption
10 mA (no load)

Application
Position sensing, metal object detection

Features
Short-circuit protection, reverse polarity protection

Product Type
Inductive Proximity Sensor

Material
Nickel-plated brass housing

Input
DC 3-wire, DC 2-wire (depending on model)

Output
PNP/NPN open collector (varies by model), relay output for some types

Function
Non-contact object detection

Usage
Industrial automation and machine safety

Accuracy
High accuracy, repeatability 1% of sensing distance

Resolution
0.1 mm

Voltage
DC 10 to 30V

Weight
Approx. 160 g (varies by type)

Ambient Humidity
35% to 95%RH

Model Numbers Covered
E2E-X18MY1, E2E-X18MY2, E2E-X18MY2-M1, E2E-X20MD1L18-T, E2E-X20MD1-M1TGJ, E2E-X20MD1-M1GJ, E2E-X20MD1-M1G, E2E-X20MD2L18, E2E-X1R5E1, E2E-X1R5E1-M1, E2E-X1R5E2

Shock Resistance
500 m/s2 (approx. 50G)

Protection Circuits
Load Short-circuit, Surge Absorber, Reverse Polarity

Sensing Object
Ferrous Metal (Iron, Steel)

Insulation Resistance
50 M min. (at 500 VDC)

Applicable Standards
CE, RoHS Compliant

Connector Type
Pre-wired Cable or M12 Connector

Control Output Load
Max 200 mA (typical)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Withstand Voltage
1,000 VAC, 50/60 Hz for 1 min

Case Diameter
M18 (E2E-X18MY Series), M20 (E2E-X20MD1 Series)

Indicator
Operation LED (Red/Yellow, Depending on Model)

OMRON PROXIMITY SENSOR , E2E-X18MY1, E2E-X18MY2, E2E-X18MY2-M1, E2E-X20MD1L18-T, E2E-X20MD1-M1TGJ, E2E-X20MD1-M1GJ E2E-X20MD1-M1G, E2E-X20MD2L18, E2E-X1R5E1, E2E-X1R5E1-M1, E2E-X1R5E2, About

Buy online the trending and featured OMRON Proximity Sensors, including the formidable E2E-X18MY1, E2E-X18MY2, E2E-X18MY2-M1, E2E-X20MD1L18-T, and more. These immaculate, world-class sensors are engineered for industrial automation and machine safety, providing non-contact detection of ferrous metals with high accuracy and rapid response. Models offer robust performance: IP67 rating, advanced protection circuits, and shock-resistant nickel-plated brass housings. Choose from pre-wired cable or M12 connectors, ensuring remarkable repeatability and device longevity. Trusted by suppliers and wholesalers worldwide.

Suitable Applications and Features

OMRON Proximity Sensors, including E2E-X18MY and E2E-X20MD series models, are suitable for industrial automation, machine protection, and metal object detection. With formidable sensitivity, high resolution, and an immaculate nickel-plated brass housing, these sensors incorporate extra features like built-in operation LED indicators (red/yellow), advanced protection circuits, and outstanding resistance to vibration and shock. Their world-class design ensures reliable performance even in challenging environments, complementing M18/M20 cylindrical mounting and IP67 waterproof protection.

Export Markets, Payment, and Sample Information

These OMRON sensors are shipped to major export markets such as China, Europe, and North America. List price options cater to various budgets and payment terms, including exchange and advance payment, ensuring flexibility for traders and wholesalers. Samples are available to assess product suitability before bulk purchase, streamlining the buying process. With rapid shipping and secure transactions, customers are guaranteed an efficient sourcing experience for world-class inductive sensors.

FAQs of OMRON PROXIMITY SENSOR , E2E-X18MY1, E2E-X18MY2, E2E-X18MY2-M1, E2E-X20MD1L18-T, E2E-X20MD1-M1TGJ, E2E-X20MD1-M1GJ E2E-X20MD1-M1G, E2E-X20MD2L18, E2E-X1R5E1, E2E-X1R5E1-M1, E2E-X1R5E2,:

Q: How do I install an OMRON Proximity Sensor in an industrial automation setup?

A: Installation is straightforward: mount the sensor using the designated threaded M18 or M20 casing, connect via pre-wired cable or M12 connector, and configure based on the required output (PNP/NPN). Shielded or unshielded types are available to suit your environment.

Q: What objects can be detected by these OMRON proximity sensors?

A: These sensors are specialized for detecting ferrous metals such as iron and steel, making them ideal for position sensing and metal object detection in automated machinery and safety systems.

Q: When should I consider using the E2E-X18MY1 or E2E-X20MD series models?

A: Use these models when high accuracy, robust environmental resistance, and high-speed response are requiredespecially in metal detection for industrial manufacturing or machine protection tasks.

Q: Where are OMRON proximity sensors mainly exported?

A: OMRON proximity sensors are primarily shipped to export markets in China, Europe, and North America, catering to the needs of suppliers, traders, and wholesalers worldwide.

Q: What is the process to request a sample before bulk purchasing?

A: To obtain a sample, contact your supplier or trader, select the model required, and arrange payment via accepted terms. Samples are dispatched promptly, allowing for product evaluation before making a larger investment.

Q: What are the main benefits of using OMRON Proximity Sensors in automation?

A: These sensors offer high sensitivity, rapid response time, and formidable environmental durability, ensuring accurate and reliable metal object detection for improved safety and operational efficiency in automated systems.
