OMRON PROXIMITY SENSOR, E2B-M18LS08-WP-B2

OMRON PROXIMITY SENSOR, E2B-M18LS08-WP-B2 Specification

Power Consumption
<15 mA

Sensor Type
Inductive Proximity Sensor

Sensitivity
Metal Object Dependent

Response Time
1 ms

IP Rating
IP67

Mounting Type
Flush, M18 Threaded Barrell Mount

Operating Temperature
-25C to +70C

Interface
Pre-wired, 3-wire cable

Signal Type
Digital

Wireless
No

Application
Position Sensing, Object Detection, Automation Systems

Cable Length
2 m Pre-wired Cable

Measurement Range
0 to 8 mm (Sensing Distance)

Features
Short body, Robust Structure, Reverse Polarity Protection, Shock and Vibration Resistant

Product Type
Proximity Sensor

Material
Nickel-plated Brass Housing

Input
3-Wire DC

Output
PNP NO (Normally Open)

Function
Detection of Metal Objects

Usage
Industrial Automation

Accuracy
High - Standard for Inductive Sensors

Resolution
0.01 mm

Voltage
10-30V DC

Weight
Approx. 70 g

Connection Type
Pre-wired

Storage Temperature
-40C to +85C

Switching Frequency
500 Hz

Sensing Object
Ferrous Metals (e.g. Iron, Steel)

Compliance
CE, RoHS Certified

Mechanical Life
30,000 hours or more

Shock Resistance
500 m/s2, 3 times each in X, Y, Z directions

LED Indicator
Yes (Operation Indicator)

Vibration Resistance
10 to 55 Hz, 1.5-mm double amplitude

Protection Circuit
Reverse Polarity, Surge, Output Short-circuit Protection

Diameter
18 mm

Enclosure Material
Nickel-plated Brass

About OMRON PROXIMITY SENSOR, E2B-M18LS08-WP-B2

Experience the acclaimed OMRON PROXIMITY SENSOR, E2B-M18LS08-WP-B2, now at a reduced price, featuring a spectacular nickel-plated brass enclosure and a highly accurate 8 mm sensing range. This gorgeous inductive sensor delivers terrific reliability, making it the highlighted choice for critical industrial automation applications. With a robust IP67 construction, reverse polarity protection, a PNP NO output, and high switching frequency of 500 Hz, it's engineered for high-performance object detection. Enjoy superior durability-over 30,000 hours of mechanical life-plus an operation LED for instant status indication. CE and RoHS certified for your assurance.

Versatile Performance and User Adaptability

The OMRON E2B-M18LS08-WP-B2 proximity sensor stands out with its short yet robust structure, shock and vibration resistance, and flush M18 threaded barrel mount for easy installation. Ideal for industrial automation, it is widely used by machinery manufacturers and industrial system integrators, providing reliable position sensing and metal object detection. Tailored for both new projects and upgrades, this sensor suits demanding environments, ensuring accurate, real-time monitoring during high-speed, repetitive usage cycles.

Sample Availability, Supply and Export Readiness

Samples of the E2B-M18LS08-WP-B2 are available upon request for preliminary testing. We offer quick dispatch and rapid quotations to meet urgent project demands. With strong supply ability and a flexible sample policy for qualified buyers, we support bulk orders as a trusted supplier, trader, and wholesaler in China. Serving the global export market, our responsive service ensures smooth delivery and technical assistance for clients engaging in automation system upgrades or new installations.

FAQ's of OMRON PROXIMITY SENSOR, E2B-M18LS08-WP-B2:

Q: How does the OMRON E2B-M18LS08-WP-B2 proximity sensor operate in challenging industrial environments?

A: This sensor is engineered with a nickel-plated brass housing, IP67 protection, and is resistant to both vibration and shock. These features ensure dependable performance even in harsh industrial settings.

Q: What types of objects can the E2B-M18LS08-WP-B2 detect effectively?

A: The E2B-M18LS08-WP-B2 is designed specifically for ferrous metals such as iron and steel, delivering high-precision detection up to 8 mm sensing distance.

Q: Where can I use the E2B-M18LS08-WP-B2 sensor?

A: This sensor is highly suitable for automation systems, industrial machinery, and manufacturing lines, particularly for position sensing or metal object detection.

Q: What are the main benefits of selecting this proximity sensor?

A: Choosing this sensor offers users a long mechanical life, high accuracy (0.01mm resolution), robust protection features, and compliance with CE and RoHS standards for safe operation.

Q: How can I request a sample or receive a quotation for the sensor?

A: You can request a sample or a quotation by contacting our sales team directly. We provide quick dispatch and competitive quotations for both single units and bulk orders.

Q: What is the supply process for international orders?

A: We support export to numerous countries and streamline the supply process for global clients with efficient order handling, technical advice, and responsive customer support.
